- Page 1 User Guide for Intel® NUC 8 NUC8i7HVKVAW Intel® NUC 8 Enthusiast, a Mini PC with Windows® 10 – NUC8i7HVKVAW User Guide...
-
Page 2: Before You Begin
If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Installation Precautions When you install and test the Intel NUC, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: ... - Page 3 • Operating System Recovery • Open the Intel NUC Chassis To open the Intel NUC chassis, follow these steps: 1. Using the included hex wrench, unscrew the six screws on the top cover of the chassis and lift the cover.
- Page 4 User Guide for Intel® NUC 8 NUC8i7HVKVAW 2. Detach the cable from the top of the NUC. 3. Unscrew the single screw to release the top plate.
-
Page 5: Installing And Removing Memory
User Guide for Intel® NUC 8 NUC8i7HVKVAW Installing and Removing Memory The Intel NUC 8 Enthusiast - NUC8i7HVKVAW has two 260-pin DDR4 SO-DIMM sockets. Although this NUC comes with both memory slots filled, follow these steps if memory is removed or installed. -
Page 6: Installing An M.2 Ssd
8. Replace the computer’s cover and reconnect the AC power cord. Installing an M.2 SSD The Intel NUC 8 Enthusiast - NUC8i7HVKVAW supports both 80mm and 42mm SSDs. Find compatible M.2 SSDs at the Intel® Product Compatibility Tool for: ... -
Page 7: Closing The Chassis
User Guide for Intel® NUC 8 NUC8i7HVKVAW Closing the Chassis After all the components have been installed, close the Intel NUC chassis. Intel recommends this be done by hand with a screwdriver to avoid over-tightening and possibly damaging the screws. - Page 8 User Guide for Intel® NUC 8 NUC8i7HVKVAW 2. Reattach the cable and secure the top plate with a screwdriver. 3. Place the top lid on the NUC and use the hex tool to tighten all the screws.
- Page 9 1. Using the four small black screws that were included in the box, attach the VESA bracket to the back of the monitor or TV. 2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC.
- Page 10 User Guide for Intel® NUC 8 NUC8i7HVKVAW 3. Slide the Intel NUC onto the VESA mount bracket.
-
Page 11: Set Up Microsoft Windows
Connect the power cord to the adapter (A). Plug the power adapter into the wall (B). Lastly, plug the power into the NUC (C). Set Up Microsoft® Windows® 10 Microsoft Windows 10 is already installed on the Intel NUC. The first time you start the computer, you are guided through the Windows 10 setup steps, including: ... - Page 12 Download Center: Intel® NUC 8 Enthusiast, a Mini PC with Windows® 10 – NUC8i7HVKVAW This NUC requires both the Intel® Graphics driver and the Radeon™ RX Vega M Graphics driver NOTE to be installed. Drivers are available for the following features: ...
-
Page 13: Operating System Recovery
User Guide for Intel® NUC 8 NUC8i7HVKVAW Operating System Recovery There’s a Windows recovery partition on the Intel NUC. You can use this partition to Refresh, Reset, or Restore Windows. Here is what each of these actions do: Refresh If your PC isn't performing as well as it once did, and you don't know why, you can refresh your PC.
