- Page 1 Fire damper EKO-SRBG1 & SRBG2 (incl, -R -C) Installation- and maintenance instructions 2022-03...
-
Page 2: Table Of Contents
Product management .........3 Assembly instructions ......6-12 General assembly ........4 Operation and maintenance .....13 Mounting accessories ........5 Declaration of Performance....14-15 Owner of manufacturing site: EKOVENT AB, Vellinge Certification by RISE Certifiering 0402 Product type description: EKO-SRBG1, -R, -C EKO-SRBG2, -R, -C... -
Page 3: Product Management
Furthermore, they must be handled so that no mechanical damage occurs to them. EKOVENT AB hereby disclaims all responsibility for: – Damage due to incorrect transport, –... -
Page 4: General Assembly
Installation- and maintenance instructions Mounting Wiring diagram EKO-SRBG1 For the P and CE marking to apply assembly must always be carried out according to the supplied assembly instructions. The facility must be equipped with a smoke detector which indicates alarm and which activates closing the fire damper. -
Page 5: Mounting Accessories
Wire mesh grille EKO-NRS Extension adapter EKO-FNS with wire mesh grille Used for EKO-SRBG1 100–250 mm Used for EKO-SRBG1 250–400 mm and for all sizes when mounting to sleeve in wall. EKOVENT AB The right to changes is reserved 2022-03... -
Page 6: Assembly Instructions
• Supporting construction, wall or floor of concrete, brick or aerated con- crete with fire resistance EI 60 Ød +10 mm Wall opening for fire damper installation: Duct size Ød +10 mm. SRBG2 SRBG1 SRBG2 EKOVENT AB The right to changes is reserved 2022-03... - Page 7 Ø 10 mm locationdoes not obstruct the movement of the damper blade. • Suspension device for dampers and ducts must correspond to the perforated fire technical class of the building part. EKOVENT AB The right to changes is reserved 2022-03...
- Page 8 B Supporting construction, wall/ cealing or floor of concrete, brick or concrete block with fire resistance EI 60/ EI 120. Ød +55 mm Wall opening for fire damper installation: Duct size Ød +55 mm. SRBG2 SRBG1 SRBG2 EKOVENT AB The right to changes is reserved 2022-03...
- Page 9 Note! The fire damper can be mounted with damper shaft in any position. Use damper caulking between duct and wall EKO-KER or corresponding. Seal with fire protection sealant. EKOVENT AB The right to changes is reserved 2022-03...
- Page 10 Important! Check that the movement of the damper blade is not obstructed. • Suspension device for dampers and ducts must correspond to the perforated fire technical class of the building part. EKOVENT AB The right to changes is reserved 2022-03...
- Page 11 Important! Check that the movement of Important! Check that the sensor the damper blades is not obstructed. location does not obstruct the movement of the damper blade. EKOVENT AB The right to changes is reserved 2022-03...
- Page 12 • Fireproofing is carried out according to an approved method that meets the fire resistance class for example EKO-KER, EKO-GIS and fire protection sealant. EKOVENT AB The right to changes is reserved 2022-03...
-
Page 13: Operation And Maintenance
• the fire damper closes completely • the fire damper opens fully • the fire damper closes completely in the event of a power failure. EKOVENT AB The right to changes is reserved 2022-03... -
Page 14: Declaration Of Performance
EC Certificate of Conformity 0402-CPR-SC0845-13 The performance of SRBG1 is in conformity with the declared performance above. This declaration of performance is issued under the sole responsibility of EKOVENT AB. Signed for and on behalf of the manufacturer by: Vellinge 2018-01-12, Michael Brändström R&D Manager... - Page 15 EC Certificate of Conformity No 0402-CPR-SC0397-13. The performance of SRBG2 is in conformity with the declared performance above. This declaration of performance is issued under the sole responsibility of EKOVENT AB. Signed for and on behalf of the manufacturer by: Vellinge 2018-06-19, Michael Brändström R&D Manager.
- Page 16 Boråsvägen 5, 435 31 Mölnlycke Tel +46 31 23 07 40 HEAD OFFICE Mejselgatan 7, 235 32 Vellinge REGIONAL OFFICE STOCKHOLM Tel +46 40 42 16 00 Vallgatan 9, 170 67 Solna www.ekovent.se info@ekovent.se Tel +46 8 508 613 00...
