- Page 1 Fire damper EKO-SRB1 Installation, operating and maintenance instructions 2021-03...
-
Page 2: Table Of Contents
Product handling ........3 General assembly ........4 Mounting accessories ........5 Installation instructions ......5-6 Operation and maintenance .......7 Declaration Of Performance .......8 Owner of place of manufacture: EKOVENT AB, Vellinge Certification: 0402 SP Certification Product type description: EKO-SRB1 Aproval number: SC0848-13 Fire classification: E 60 (ve i<... -
Page 3: Product Handling
Products with defects or defects must not be installed. Contact the supplier immediately. EKOVENT AB hereby disclaims all responsibility for: – Damage due to incorrect transport, EKOVENT:s liability shall be limited to repair handling or storage. -
Page 4: General Assembly
Installation, operating and maintenance instructions EKO-SRB1 General assembly Why Fire dampers? Fire dampers are one of several factors in a building that together must provide good fire protection in the event of a fire. The fire protection requirements are mainly affected by building class, fire load, heat output, air supply, the rescue service’s... -
Page 5: Mounting Accessories
Mounting accessories EKO-SRB1 Flexible wall sleeve EKO-GIS Installation Mounting instructions EKO-SRB1 Installation in flexible wall sleeve EKO-GIS Gipsväggstos EKO-GIS_mellanvägg 2013 Plåtskruv eller popnit av stål 1. Squeeze the wall sleeve EKO-GIS and insert it into the hole. 2. Lock the wall sleeve with a sheet metal screw or pop rivets in the overlap. - Page 6 Installation, operating and maintenance instructions EKO-SRB1 Assembly instruction EKO-SRB1 Supporting construction - wall or floor in fire resistance class EI 60. P-approval SC0848-13 Suspension Duct EKO- SRB1 Duct Duct EKO- SRB1 Fire sealant * Duct Fire sealant * Important! The smoke damper should always be installed with the blade EKO-SRB1 Mont schakt 2014 shaft horizontal..
-
Page 7: Operation And Maintenance
Operation check which is located on the front of the monitoring unit (applies to EKO-KE). Fire damper EKO-SRB1 is a P- and CE Powerless damper closes. Check that marked damper for fire separation of hea- the damper is fully open during opera-... -
Page 8: Declaration Of Performance
Installation, operating and maintenance instructions EKO-SRB1 Declaration Of Performance EKOVENT AB EKOVENT AB We reserve the right to make changes We reserve the right to make changes 2021-03 2021-03... - Page 9 Notes: EKOVENT AB We reserve the right to make changes 2021-03...
- Page 10 REGIONAL OFFICE GÖTEBORG Boråsvägen 5, 435 31 Mölnlycke Tel 031-23 07 40 HEAD OFFICE Mejselgatan 7, 235 32 Vellinge REGIONAL OFFICE STOCKHOLM Tel 040-42 16 00 Vallgatan 9, 170 67 Solna www.ekovent.se info@ekovent.se Tel 08-508 613 00...
