- Page 1 Firedamper EKO-RBG1 (incl, -R -C) Installation- and maintenance instructions 2022-06...
-
Page 2: Table Of Contents
Assembly instructions ......6-10 General assembly ........4 Operation and maintenance .....11 Mounting accessories ........5 Declaration of performance ....12-13 Owner of manufacturing site: EKOVENT AB, Vellinge Certification by: RISE Certifiering 0402 Product type description: EKO-RBG1, -R, -C Approval number :... -
Page 3: Product Management
Furthermore, they must be handled so that no mechanical damage occurs to them. EKOVENT AB hereby disclaims all responsibility for: – Damage due to incorrect transport, – Personal injury or property damage as a handling or storage. -
Page 4: General Assembly
Installation- and mainenance instructions Mounting Wiring diagram EKO-RBG1 For the P and CE marking to apply assembly must always be carried out according to the supplied assembly instructions. The facility must be equipped with a smoke detector which indicates alarm and which activates closing the fire damper. -
Page 5: Mounting Accessories
ØD 100 - 500 mm Ingen förlängningsst Mounting accessories Mounting frame EKO-MOP* Connection socket EKO-ANS Anslutningsstos Förlän * Included in the EKO-RBG1-1 delivery. EKO-ANS EKOVENT AB The right to changes is reserved 2022-06... -
Page 6: Assembly Instructions
For correct positioning unfold the help arrows in the corners. Fold them back before installation of the damper. Note! The fire damper must always be mounted with damper shafts horizontal. EKOVENT AB The right to changes is reserved 2022-06... - Page 7 Attach the fire damper to the EKO-MOP mounting frame by bend up the attachment ears. Important! Check that the movement of the damper blades is not obstructed. Note! The fire damper must always be mounted with the damper shafts horizontal. EKOVENT AB The right to changes is reserved 2022-06...
- Page 8 • When installing in a plaster wall, reinforcement must be in sheet metal 45x45 mm or larger mounted as a frame in the wall construction. EKOVENT AB The right to changes is reserved 2022-06...
- Page 9 Wall opening for the fire installation: Duct dimension B+30 mm × H+30mm. Attach the fire damper with guide or flange connection. Important! Ensure that the hole diagonal measures are equal. EKOVENT AB The right to changes is reserved 2022-06...
- Page 10 Suspension device for dampers and ducts must correspond to the perforated fire technical class of the building part. • The fire damper must always be mounted with the damper shafts horizontal. EKOVENT AB The right to changes is reserved 2022-06...
-
Page 11: Operation And Maintenance
• the fire damper closes completely • the fire damper opens fully • the fire damper closes completely in the event of a power failure. EKOVENT AB The right to changes is reserved 2022-06... -
Page 12: Declaration Of Performance
Typnummer och specifikationer framgår av produktens etikett. Avsedd användning: Brand-/Brandgasspjäll med ett brandskydd av minst 60 min i enlighet med den harmoniserade Europastandarden EN 15650:2010. Tillverkare: EKOVENT AB, Mejselgatan 7, 23532 Vellinge, www.ekovent.se Produktcertifiering: RISE, nr 0402, har utfört typprovning samt inledande granskning av tillverkningsstället och tillverkningskontrollen enligt system 1. - Page 13 Typnummer och specifikationer framgår av produktens etikett. Avsedd användning: Brand-/Brandgasspjäll med ett brandskydd av minst 60 min i enlighet med den harmoniserade Europastandarden EN 15650:2010. Tillverkare: EKOVENT AB, Mejselgatan 7, 23532 Vellinge, www.ekovent.se Produktcertifiering: RISE, nr 0402, har utfört typprovning samt inledande granskning av tillverkningsstället och tillverkningskontrollen enligt system 1.
- Page 14 Installation- and mainenance instructions Notes: EKOVENT AB The right to changes is reserved 2022-06...
- Page 15 Notes: EKOVENT AB The right to changes is reserved 2022-06...
- Page 16 REGIONAL OFFICE GÖTEBORG Boråsvägen 5, 435 31 Mölnlycke Tel +46 31 2307 40 HEAD OFFICE Mejselgatan 7, 235 32 Vellinge REGIONAL OFFICE STOCKHOLM Tel +46 40 42 16 00 Vallgatan 9, 170 67 Solna www.ekovent.se info@ekovent.se Tel +46 8 508 613 00...
