- Page 1 EKOVENT Fire System Pro Commissioning instructions 2022-12...
-
Page 2: Table Of Contents
3.5 Access rights ...................... 24 Caution! Read and understand the instruction before using the Ekovent Fire System Pro and ensure that the installation complies with local safety regulations. Installation and maintenance of the system should only be carried out by qualified personnel. -
Page 3: Overview
1.1 Introduction evacuation fan with a duct pressure differential transmitter (PRO-PDT). Ekovent Fire System Pro is a complete fire protection steering system that allows to feed, monitor and test up The main function of the PRO-M is to continuously check to 60 fire and/or smoke control dampers. -
Page 4: System Setup
Commissioning instructions EKO-Fire System Pro 1.3 System setup Fire System Pro is a flexible steering system that gives full automatic fire and smoke protection, and can be customized and designed to handle various buildings and different scenarious. Modbus Bacnet PRO-M... -
Page 5: Pro-M Push Buttons
Commissioning instructions EKO-Fire System Pro 1.4 PRO-M push buttons The Pro-M master unit has a pre-programmed controller with a backlit internal display. The different menus and settings are easily accessible and controlled by push buttons on the front of the unit. -
Page 6: Pro-S Light Indications
Commissioning instructions EKO-Fire System Pro 1.6 PRO-S light indications 1.7 ProLink application The PRO-S damper unit has two different LED lights to The ProLink application is available on Android and iOS indicate status for communication and identification, see and can be used to find a PRO-S unit, to change ModBus table 1.1. -
Page 7: Menu Structure
Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 7 (25) www.ekovent.se... -
Page 8: Quick Start Guide
Commissioning instructions EKO-Fire System Pro 2.0 Quick start guide This section provides you with guidlines to common settings and configurations to get the Fire System Pro running. Note! Each guide starts from the main menu. To go back, press “back” button until you reach the main menu. -
Page 9: Activate Local Fire Dampers
Commissioning instructions EKO-Fire System Pro 2.5 Add PRO-S damper units to PRO-M 2.3 Activate local fire dampers 1. Press ”down” to find ”System Setup” 1. Press ”down” to find ”System Setup” 2. Press ”forward” to access ”System Setup” 2. Press ”forward”... -
Page 10: Add Pro-S Damper Units Via Prolink
Commissioning instructions EKO-Fire System Pro 2.5 Add PRO-S damper units (cont.) 2.6 Add PRO-S damper units via ProLink 10. Start running by pressing the ”push-button” on all suitable damper units (PRO-S). LED lights up in color ”Magenta” meaning that the unit is still offline. - Page 11 Commissioning instructions EKO-Fire System Pro 4. Access ”communication” and set modbus address 6. Confirm changes according to requirements. Note! Lowest modbus address for PRO-S is four (4) Attention! Repeat the steps for other PRO-S damper unit. When all units are identified and addressed, go to...
-
Page 12: Set Section Funcionality In Pro-M
Commissioning instructions EKO-Fire System Pro 5. Press ”down” to find 12. Press ”OK” to edit ”Section containment” ”Start” status (Yes/No) 13. Press ”up” to change 6. Press ”forward” to enter status to YES ”Section containment” 14. “OK” to confirm status 7. -
Page 13: Section Setup In Pro-M
Commissioning instructions EKO-Fire System Pro 2.8 Section setup in PRO-M 1. Press ”down” to find 12. Press ”OK” to confirm ”System Setup” ”Stop” number 13. Use ”up” and ”down” 2. Press ”forward” to ac- arrows to change number cess ”System setup”... -
Page 14: Activate Sef Mode
Commissioning instructions EKO-Fire System Pro Section setup in PRO-M (cont.) 11. Press ”OK” to confirm 5. Press ”OK” to start edit setup for damper and set ”Select slave number” section for damper 12. Use ”up” and down” 6. Use ”up” and ”down”... -
Page 15: Activate The Fire System Pro
”Activate System” 15. Press ”up” to change status for ”Pressure sensor enabled” to YES The Fire System Pro is now activated and running 16. Press ”OK” to confirm AFA system activation SEF mode is now setup EKOVENT AB Rätt till ändringar förbehålles... -
Page 16: Complete List Of Menu Functions
Commissioning instructions EKO-Fire System Pro 3.0 Complete list of menu functions Following is a complete list of menu options, including a function description 3.1 Status Overview The status overview menu (1.0) shows status for different components of the system EKOVENT AB Rätt till ändringar förbehålles... - Page 17 Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 17 (25) www.ekovent.se...
- Page 18 Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 18 (25) www.ekovent.se...
-
Page 19: System Setup
Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 19 (25) www.ekovent.se... - Page 20 Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 20 (25) www.ekovent.se...
- Page 21 Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 21 (25) www.ekovent.se...
-
Page 22: Settings
Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 22 (25) www.ekovent.se... -
Page 23: Manual/Auto
Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 23 (25) www.ekovent.se... -
Page 24: Access Rights
Commissioning instructions EKO-Fire System Pro EKOVENT AB Rätt till ändringar förbehålles 2022-12 24 (25) www.ekovent.se...
