- Page 1 The Original Storage and Organization Store ® Assembly Instructions Hudson File Cabinet PRODUCT INFO PAGE 1 OF 10...
-
Page 2: Drawer Front Panel
Right Panel Back Panel Top Panel Bottom Panel Left Panel Bottom Rail Drawer Back Panel Drawer Right Panel Drawer Left Panel Drawer Bottom Drawer Front Panel Please review the hardware listed on the next page as well as individual components of this product. -
Page 3: Hardware & Tools
H1 x 20 H2 x 8 H3 x 12 H4 x 8 CAM BOLT SMALL CAM SMALL DOWEL H5 x 12 H8 x 1 H6 x 4 H7 x 8 LARGE DOWEL ALLEN SMALL BOLT LARGE BOLT WRENCH TOOLS REQUIRED: PHILLIPS SCREWDRIVER HARDWARE &... - Page 4 180º HOW TO USE CAM LOCK SYSTEM PAGE 4 OF 10...
- Page 5 STEP 1 STEP 2 H1 x 4 H4 x 4 H2 x 4 CAM BOLT SMALL DOWEL SMALL CAM ASSEMBLY PAGE 5 OF 10...
- Page 6 STEP 3 STEP 4 H1 x 4 H1 x 2 H4 x 4 H5 x 2 H2 x 4 H3 x 2 CAM BOLT CAM BOLT SMALL DOWEL LARGE DOWEL SMALL CAM LARGE CAM ASSEMBLY PAGE 6 OF 10...
- Page 7 STEP 5 STEP 6 H1 x 2 H1 x 2 H5 x 2 H5 x 2 H3 x 2 H3 x 2 CAM BOLT CAM BOLT LARGE DOWEL LARGE DOWEL LARGE CAM LARGE CAM ASSEMBLY PAGE 7 OF 10...
- Page 8 STEP 7 STEP 8 FRONT OF BOTTOM RAIL HAS LONGER METAL PRONGS FRONT ARROW H8 x 1 H7 x 4 H1 x 6 H5 x 6 ALLEN H3 x 6 LARGE BOLT CAM BOLT WRENCH LARGE DOWEL LARGE CAM ASSEMBLY PAGE 8 OF 10...
- Page 9 STEP 9 STEP 10 ADJUSTABLE GLIDES H8 x 1 H6 x 4 H7 x 4 ALLEN SMALL BOLT LARGE BOLT WRENCH ASSEMBLY PAGE 9 OF 10...
- Page 10 30 lbs 15 lbs WARNING: Do not exceed the recommended weight limits on the designated panels. Exceeding these limits could cause sagging, possibly resulting in failure of product or bodily injury. Severe injury may occur if furniture tips over. Never allow children to climb or play on this product. Place heaviest items on lower shelves and as far back as possible, never overload product.
