Output Format
Dest Address
Dest Port
Output Device
File Prefix
Max File Size
Video PID*
(UDP/TSRTP/TSFILE
Only)
PCR PID*
(UDP/TSRTP/TSFILE
Only)
PCR Interval*
(UDP/TSRTP/TSFILE
Only)
PMT PID*
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
RTP
RTSP
UDP
TSRTP
TSFILE
RTMP
RTMPS
SRT
192.168.x.y
(192.168.0.6)
0 – 9999 (8600)
MOV1_%F_%T_
(1024M)
0 – 8191 (221)
0 – 8191 (521)
(50)
0 – 8191 (31)
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
Output format of the encoded IP stream.
RTP requires an SDP file for the receiver that
corresponds to the video codec used.
TSRTP streams TS over RTP.
RTMP is only supported with H264(AVC) selected as
the Video Codec.
The IP address of the destination of the encoded
stream.
The destination port that the encoder is streaming
to.
Click this field to select the detected storage
device for output file destination.
Textbox to enter desired file name for output file.
Entered
text will be followed by a number starting with
zero in the recorded file name.
%F will pull the current date, in year/month/day
format, into the file name.
%T will pull the current time, in 24-hour notation,
into the file name.
Sets the file size at which a new .ts file is started.
PID assigned to video in the TS stream.
PID assigned to PCR in the TS stream.
Interval assigned to PCR in the TS stream in
milliseconds.
PID assigned to PMT in the TS stream.
