Intex Krystal Clean Poolwater 8220 Owner's Manual page 7

Set Up Instructions (cont.)
For connection to filter pumps with 1-1/2" (38mm) hose size:
(Do not use adapter A or B, 05CG-11 or 05CG-12)
Drawing #2
WATER TO
POOL
1-1/2"(38mm) HOSE
SALTWATER SYSTEM
1. If your above-ground-pool is filled with water, close the plunger valves before Saltwater System
installation. Go to step 2 directly if your pool is empty.
2. Disconnect the water return (to the pool) hose from the filter pump connection, and connect it to the
Saltwater System outlet.
3. Connect the connector hose (05CG-10) to the filter pump outlet connection.
4. Open plunger valves to allow water to flow.
(102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5" X 10.5" 10/11/2006
SWIMMING POOL
05CG-10
SAVE THESE INSTRUCTIONS
Page 7
FILTER
PUMP
1-1/2"(38mm) HOSE
102
PLUNGER
VALVE
WATER FROM
POOL
