chipKIT Max32 Reference Manual
57 J9-11 27
58 J3-09 12
59 J3-11 13
60 J14-06 72
61 J14-08 73
62
63
64
65
66 J4-01 21
67 J4-02 20
68 J8-06 48
69 J14-10 74
70 J8-16 38
71 J8-05 49
72 J14-07 3
73 J14-12 75
74 J14-09 4
75
76 J14-11 5
77 J14-13 6
78 J3-03 9
79 J3-01 8
80 J14-14 76
81 J3-05 10
82 J8-15 39
83 J8-07 47
84 J14-16 77
85
www.digilentinc.com
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
D+/RG2
SCL2/RA2
SDA2/RA3
TDI/RA4
TDO/RA5
VDD
OSC1/CLKI/RC12
OSC2/CLKO/RC15
VSS
AETXCLK/SCL1/INT3/RA14
AETXEN/SDA1/INT4/RA15
RTCC/EMDIO/AEMDIO/IC1/RD8
SS1/IC2/RD9
SCK1/IC3/PMCS2/PMA15/RD10
EMDC/AEMDC/IC4/PMCS1/PMA14/RD11
SDO1/OC1/INT0/RD0
SOSCI/CN1/RC13
SOSCO/T1CK/CN0/RC14
VSS
OC2/RD1
OC3/RD2
OC4/RD3
ETXD2/IC5/PMD12/RD12
ETXD3/PMD13/CN19/RD13
OC5/PMWR/CN13/RD4
PMRD/CN14/RD5
ETXEN/PMD14/CN15/RD6
ETXCLK/PMD15/CN16/RD7
VCAP/VDDCORE
X1, system clock
oscillator
X1, system clock
oscillator
RTCC clock input
