chipKIT Max32 Reference Manual
23 J9-15 8
24 J9-14 54
25 J9-13 51
26 J9-12 56
27 J9-11 57
28 J9-10 1
29 J9-09 11
30 J9-08 5
31 J9-07 4
32 J9-06 3
33 J9-05 100
34 J9-04 99
35 J9-03 98
36 J9-02 94
37 J9-01 93
38 J8-16 70
39 J8-15 82
40 J8-14 35
41 J8-13 42
42 J8-12 41
43 J8-11 12
44 J8-10 29
45 J8-09 87
46 J8-08 88
47 J8-07 83
48 J8-06 68
49 J8-05 71
50 J8-04 11
51 J8-03 12
52 J8-02 10
www.digilentinc.com
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
T4CK/AC2RX/RC3
VBUS
USBID/RF3
D-/RG3
D+/RG2
AERXERR/RG15
ECRX/SDA2/SDI2A/U2ARX/PMA4/CN9/RG7
PMD7/RE7
PMD6/RE6
PMD5/RE5
PMD4/RE4
PMD3/RE3
PMD2/RE2
PMD1/RE1
PMD0/RE0
SCK1/IC3/PMCS2/PMA15/RD10
PMRD/CN14/RD5
AN11/EREXERR/AETXERR/PMA12/RB11
AN13/ERXD1/AECOL/PMA10/RB13
AN12/ERXD0/AECRS/PMA11/RB12
ERXDV/AERXDV/ECRSDV/AECRSDV/SCL2A/SDO2A/U2ATX/PMA3/CN10/RG8
VREF+/CVREF+/AERXD3/PMA6/RA10
C1RX/ETXD1/PMD11/RF0
C1TX/ETXD0/RMD10/RF1
ETXEN/PMD14/CN15/RD6
RTCC/EMDIO/AEMDIO/IC1/RD8
EMDC/AEMDC/IC4/PMCS1/PMA14/RD11
ECRX/SDA2/SDI2A/U2ARX/PMA4/CN9/RG7
ERXDV/AERXDV/ECRSDV/AECRSDV/SCL2A/SDO2A/U2ATX/PMA3/CN10/RG8
ECOL/SCK2A/U2BTX/U2ARTS/PMA5/CN8/RG6
Also J7-04(65)
Also J7-06(66)
Also J7-05(67)
Also JP3,JP4
also J3-15
Also JP3,JP4
Also JP3,JP4
Also J13-03
