chipKIT Max32 Reference Manual
Pinout Table by Microcontroller Pin
PIC32 Connector chipKIT
Pin Pin # Pin #
1 J9-10 28
2
3 J9-06 32
4 J9-07 31
5 J9-08 30
6 n/c n/c
7 J9-16 22
8 J9-15 23
9 J3-07 11
10 J8-02 52
11 J9-09 29
12 J8-11 43
13 J10-01
14 J8-01 53
15
16
17 J14-02 70
18 J14-05 2
19 J14-15 7
20 J5-06 59
21 J5-05 58
22 J5-04 57
23 J5-03 56
24 J5-02 55
25 J5-01 54
26 J5-7 60
www.digilentinc.com
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
PIC32 Signal
AERXERR/RG15
VDD
PMD5/RE5
PMD6/RE6
PMD7/RE7
T2CK/RC1
T3CK/AC2TX/RC2
T4CK/AC2RX/RC3
T5CK/SDI1/RC4
ECOL/SCK2A/U2BTX/U2ARTS/PMA5/CN8/RG6
ECRS/SDA2/SDI2A/U2ARX/PMA4/CN9/RG7
ERXDV/AERXDV/ECRSDV/AECRSDV/SCL2A/SDO2A/U2ATX/PMA3/CN10/RG8
MCLR
ERXCLK/AERXCLK/EREFCLK/AEREFCLK/SS2A/U2BRX/U2ACTS/PMA2/CN11/RG9
VSS
VDD
TMS/RA0
AERXD0/INT1/RE8
AERXD1/INT2/RE9
AN5/C1IN+/VBUSON/CN7/RB5
AN4/C1IN-/CN6/RB4
AN3/C2IN+/CN5/RB3
AN2/C2IN-/CN4/RB2
PGEC1/AN1/CN3/RB1
PGED1/AN0/CN2/RB0
PGEC2/AN6/OCFA/RB6
Notes
Also J13-03
Also JP3, JP4
Also JP3, JP4
Also J13-05
Also A5
Also A4
Also A3
Also A2
Also A1
Also A0
Also A6
