chipKIT Max32 Reference Manual
53
J8-01
14
54
J5-01
25
55
J5-02
24
56
J5-03
23
57
J5-04
22
58
J5-05
21
59
J5-06
20
60
J5-7
26
61
J5-8
27
62
J7-01
32
63
J7-02
33
64
J7-03
34
65
J7-04
35
66
J7-06
42
67
J7-05
41
68
J7-07
43
69
J7-08
44
70
J14-02
17
71
J14-04
38
72
J14-06
60
73
J14-08
61
74
J14-10
69
75
J14-12
73
76
J14-14
80
77
J14-16
84
78
J3-02
89
79
J3-04
90
80
J3-06
91
81
J3-08
92
82
J3-10
95
www.digilentinc.com
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
ERXCLK/AERXCLK/EREFCLK/AEREFCLK/SS2A/U2BRX/U2ACTS/PMA2/CN11/RG9
PGED1/AN0/CN2/RB0
PGEC1/AN1/CN3/RB1
AN2/C2IN-/CN4/RB2
AN3/C2IN+/CN5/RB3
AN4/C1IN-/CN6/RB4
AN5/C1IN+/VBUSON/CN7/RB5
PGEC2/AN6/OCFA/RB6
PGED2/AN7/RB7
AN8/C1OUT/RB8
AN9/C2OUT/RB9
AN10/CVREFOUT/PMA13/RB10
AN11/EREXERR/AETXERR/PMA12/RB11
AN13/ERXD1/AECOL/PMA10/RB13
AN12/ERXD0/AECRS/PMA11/RB12
AN14/ERXD2/AETXD3/PMALH/PMA1/RB14
AN15/ERXD3/AETXD2/OCFB/PMALL/PMA0/CN12/RB15
TMS/RA0
TCK/RA1
TDI/RA4
TDO/RA5
SS1/IC2/RD9
SOSCI/CN1/RC13
ETXD3/PMD13/CN19/RD13
ETXCLK/PMD15/CN16/RD7
C2TX/ETXERR/PMD9/RG1
C2RX/PMD8/RG0
TRCLK/RA6
TRD3/RA7
TRD2/RG14
Also J13-05
Also A0
Also A1
Also A2
Also A3
Also A4
Also A5
Also A6
Also A7
Also A8
Also A9
Also A10
Also A11,J8-14(40)
Also A12,J8-13(41)
Also A13,J8-12(42)
Also A14
Also A15
page 14 of 23
