AME 85, AME 86
➌
Wiring for modulating mode
Proportional 3 point/RL
Wiring for 3-point floating mode
Controller with relay output
Proportional 3 point/RL
Wiring for 3-point floating mode
Controller with triacs output
Proportional 3 point/RL
VI.AC.O4.2V
①
②
SN
0 V
SP 24 VAC
0(2)-10 V
Y
0(4)-20 mA
1
0 V
3
X
0(2)-10 V
SN V
0
SP 24 VAC
1
24 VAC
3
X 0(2)-10 VDC
SN 24 VAC
SP
0 V
1
24 VAC
3
X 0(2)-10 VDC
Neutral
Power supply
Input
Input
Output
Neutral
Power supply
Input
Output
Neutral
Power supply
Input
Output
