Segment 2
1. Zone and box tamper and tamper restore.
2. Auxiliary power over current, ground fault, and restore for
both.
3. Wireless sensor missing and restore.
4. Wireless sensor low battery and restore.
5. Expander trouble and restore.
6. Fail to communicate.
7. Zone activity monitor.
8. Reserved
Location 18 - Custom communicator format
Location 18 has four segments of feature selection data. Use
this location to program the communicator format used to
transmit to the receiver connected to phone 3. Refer to your
central station receiver documentation to determine which
format is compatible. Select a format from
a format other than those listed, review the override options
described in this location to build the appropriate format.
Segment 1
1. On for 1800 Hz transmit; off for 1900 Hz.
2. On for 2300 Hz handshake; off for 1400 Hz.
3. On for cksum parity; off for double round parity.
4. On for two-digit event code; off for one-digit event code.
5. Reserved.
6. Reserved.
7. On for 20 pps; off for 10 or 40 pps.
8. On for 10 pps; off for 20 or 40 pps.
Segment 2
1. On for pager format (no handshake required).
2. On for 1400/2300 handshake.
3. Reserved.
4. Reserved.
5. On for contact ID.
6. On for SIA.
7. On for contact ID or 4+3.
8. On for DTMF.
NX-6V2 Control Panel Installation Instructions
Segments 3 and 4 - Reserved
Location 25 - Zones 1 to 8 zone type
Location 25 has eight segments of numerical data. Use this
location to program the zone type for zones 1 to 8. Use
segment 1 for zone 1, segment 2 for zone 2, etc. The segment
defaults are 3, 5, 6, 6, 6, 6, 6, 6.
Zones are programmed to be one of thirty different types. Use
zone types 17 through 20 for wireless, or for hardwired zones
using European double EOL configuration
Table 5
Table 5. Zones types
Zone Type
1. Day zones
2. 24-hour
audible
3. entry/exit
Table
4. If you need
delay
4. Follower with
autobypass
disabled
5. Interior
follower with
autobypass
6. Instant
7. 24-hour
silent
8. Fire
9. Entry/exit
delay 2
10. 24-hour
silent
supervised
11. Reserved
12. Interior
follower with
cross zone
13. Instant
entry guard
describes the zone types.
Description
This zone is instant when the system is armed;
trouble zone when the system is disarmed.
This zone creates an instant yelping siren alarm
regardless of the armed state of the control panel.
A trip starts entry delay 1. The lack of a trip during
exit delay enables the automatic bypass or instant
mode if programmed.
This zone is instant when the system is armed and
no entry or exit delays are being timed. It is delayed
1 time during entry and exit. This zone does not
automatically bypass even if enabled in segment 1.
This zone is instant when the system is armed and
no entry or exit delay is being timed. It is delayed 1
time during entry and exit. This zone automatically
bypasses if enabled in segment 1.
This zone creates an instant alarm whenever it is
tripped and the armed LED is on.
This zone creates an instant silent alarm regardless
of the armed state of the control panel. It does not
display on the keypad.
This zone illuminates the fire LED and sounds the
temporal siren each time the zone is shorted. The
fire LED flashes rapidly indicating a problem if the
zone is open.
A trip starts entry delay 2. The lack of a trip during
exit delay enables the automatic bypass or instant
mode if programmed.
This zone creates an instant silent alarm regardless
of the armed state of the control panel. It displays
on the keypad.
This zone is instant when the system is armed and
no entry or exit delay is being timed. It is delayed
during entry and exit delay times. If a
not being timed, it starts a
zone
is being timed, it creates an instant alarm. This
zone automatically bypasses when enabled in
segment 1.
This zone creates on instant alarm whenever it is
tripped and the stay LED is off. It starts an entry
delay type 2 if it is tripped, the system is armed,
and the stay LED is on.
cross zone
is
cross zone
cross
timer. If a
5
