The following figure shows the HCS6150R front panel. Back panel features are described
on pages 8 to 9.
206-4138
Front Panel Overview / Ventilation
Front
Ventilation Holes
Air flow must not be obstructed. To ventilate the system normally and avoid
overheating, leave at least 1 inch (2.5 cm) on each side of the HCS6150R unit.
Do NOT stack other equipment on the top of the HCS6150R unit.
Top
Bottom
Back
11
