Register Your Product Register your TCL Sound Bar to receive the latest news on product releases, promotional offers, and more!* Text to Register Text a photo of the camera icon to 71403 Or register online at register.tcl.com Need help? Visit photoregister.com/help...
What's in the box Make sure you read all the safety information before you use this product. User Manual can be found at www.tcl.com/us Sound bar Subwoofer Surround Sound Speakers on the specific product page in the “Download” (Cable length: 26 ft. 2.96") section.
Page 5
Overview AC input power connector AUX VA input connector AUX input connector IR input connector USB Type A connector Optical input connector HDMI ARC connector Source button: Short press: Switch input sources Volume buttons: (HDMI-ARC/Optical/AUX/AUX VA/USB/Bluetooth) Press to increase or Long press: Enter subwoofer pairing decrease the volume level.
Page 6
Overview The subwoofer will pair automatically with sound bar upon first use. In case of a problem, take the following steps to manually pair: Press and hold the button on the subwoofer for 3 seconds until an amber light begins flashing above the pair button. Press and hold the button on the sound bar until a yellow LED indicator flashes on the...
Page 7
Install or replace the remote batteries Battery type: 1.5V AAA battery x 2 Short press: power on / sleep Long press: power off Short press: mute / unmute the sound Use the Remote Short press: Switch input sources HDMI-ARC/Optical/AUX/AUX VA/USB Long press: Bluetooth Pairing /Bluetooth Short press: select Bluetooth mode...
Page 8
Remote Control Sound bar Action LED Behavior on Sound bar Sound Bar LED Display Power Off: All LEDs light turn on and turn off from the sides to Power off/Sleep the center. Power On Power On: LEDs will turn on from the center to the sides. Mute On: Center LED will flash several times.
Sound Bar on the table Top View Place your Sound Bar and Subwoofer The ideal place to position the Sound Bar is centered underneath your TV. Note: Do not place your sound bar in a location exposed to direct sunlight, heat, fire, or moisture. Note: It’s recommended to keep the distance within 9.8 feet between the Surround Sound Speakers and the sound bar.
Page 10
Wall mount your Sound Bar Required tools: Insert the wall anchors in the holes on the wall. Insert the included screws with the brackets into the hole of the wall anchors. Fix and tighten the wall brackets and screws on the sound bar. Replace the screws with the included long wall mount screws.
Page 11
Wall mount Your Surround Sound Speakers Notes: Only suitable for mounting at heights: < 6 ft. 6.7". M6 x 12 Wall-mount bracket is not included. (not included) Wall-mount bracket is not included. Cable length: 26 ft. 2.96"...
Connect to your TV There are 2 ways to connect your sound bar to the TV (listed in order that we recommend): HDMI ARC (refer to 7a), and Optical (refer to 7b). If you have a Roku TV , simply plug in the HDMI cable to the ARC ports and follow the Roku TV Ready on-screen instructions.
Page 13
Connect HDMI cable from the HDMI (ARC) interface on the sound bar to the HDMI (ARC/eARC) interface on the TV. Enable the CEC function in the settings of the TCL (See TV User Manual for instructions) Enable CEC function on other brand TV.
Page 14
Optical Connect the Sound Bar to the TV with an Optical cable. Connect the Sound Bar to the power outlet with the included power cord. Warning: Do not bend or kink the optical cable (SPDIF) as it is fragile and can easily get damaged and broken.
Page 15
> The Sound Bar is ready to pair. 4. Power on your Bluetooth device and activate its Bluetooth function. 5. Select TCL S510W. > You will see the blue light on for 3 seconds. > Pairing is successful. 6. If you want to pair another device, please repeat step 3.
Other connections - USB Supported audio files: MP3, WMA, FLAC, WAV.
Page 17
Other connections - AUX Cables are not included.
Page 18
Other connections - AUX VA Your sound bar can connect to a Voice Assistant (VA) device through an AUX VA connection. Once connected, your sound bar will now act as the VA speaker. Features and Benefits: • Voice Assistant Dedicated Input: VA is active on the sound bar even if the sound bar is set to a di erent input with audio playing.
IR Pass-through If the sound bar blocks the IR receiver of the TV TV Sensor when placed directly in front of it. You can use the included IR pass-through cable to send IR commands to your TV using the sound bar. First connect one end of the IR pass-through cable to the IR connector on your sound bar.
Page 20
Trademarks Roku, the Roku logo, Roku TV, Roku TV Ready, and the Roku TV Ready logo are trademarks and/or registered trademarks of Roku, Inc. This product is Roku TV Ready-supported in the United States. Countries are subject to change. For the most current list of countries in which this product is Roku TV Ready-supported, please email rokutvready@roku.com.
Page 22
Notice for US User Manual can be found at www.tcl.com/us on the specific product page in the “Download” section. objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Page 23
User Manual can be found at www.tcl.com/us on the specific product page in the “Download” section. FCC Information not operate normally, or has been dropped.
