Masterzen XPR W20D Instruction Manual

Hide thumbs Also See for XPR W20D:
Table of Contents

Advertisement

Quick Links

Download this manual
Συντηρητές Κρασιών
INSTRUCTION MANUAL
XPR W7S models
XPR W20S/D models
XPR W35D models
XPR W24S models
XPR W30D models
Milos / Mykonos / Santorini models
XPR W48DT models
XPR W40S/DT models
XPR W46S/DT models
XPR W88S/DT models
PRM 88, PRM 180 models
XPR W120DT models
XPR W180S/DT models
XPR W300S/DT models
XPR W122DT models
XPR F180
XPR 46 Outdoor
XPR W106DT models
Décor Panel Models
User Manual
0
Συντηρητές Κρασιών XPR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPR W20D and is the answer not in the manual?

Questions and answers

Related Manuals for Masterzen XPR W20D

Summary of Contents for Masterzen XPR W20D

  • Page 1 Συντηρητές Κρασιών INSTRUCTION MANUAL XPR W7S models XPR W20S/D models XPR W35D models XPR W24S models XPR W30D models Milos / Mykonos / Santorini models XPR W48DT models XPR W40S/DT models XPR W46S/DT models XPR W88S/DT models PRM 88, PRM 180 models XPR W120DT models XPR W180S/DT models XPR W300S/DT models...
  • Page 2 Σας ευχαριστούμε που επιλέξατε το Συντηρητή Κρασιών Masterzen. Η τέχνη του Ευ Ζην. Το πάθος μας είναι το κρασί. Το κρασί τοποθετείται στους συντηρητές Μasterzen και αναδεικνύεται ως έργο τέχνης. User Manual Συντηρητές Κρασιών XPR...
  • Page 3 ΤΟΥ ΣΥΝΤΗΡΗΤΗ Σκανάρετε με το κινητό σας τηλέφωνο και βρείτε συγκεντρωμένες όλες τις οδηγίες χρήσης και ασφαλείας Εναλλακτικά μπορείτε να επισκεφτείτε το site μας στο ακόλουθο σύνδεσμο: https://www.masterzen.gr/content/115/start- ή www.masterzen.gr Τοποθετείστε το συντηρητή στην τελική του θέση. Πριν τη σύνδεση του...
  • Page 4 ΠΡΙΝ ΑΡΧΙΣΕΤΕ ΝΑ ΓΕΜΙΖΕΤΕ ΚΑΙ ΝΑ ΘΕΤΕΤΕ ΣΕ ΛΕΙΤΟΥΡΓΕΙΑ ΤΟΝ ΣΥΝΤΗΡΗΤΗ ΠΡΟΣΟΧΗ: • Τα μοντέλα XPR W7, W24, W30, W48, W106 είναι αποκλειστικά για εγκατάσταση πλήρους εντοίχισης. Παρακαλούμε να ακολουθήσετε πιστά τις οδηγίες για την σωστή εγκατάσταση και εξαερισμό του συντηρητή. Αποτυχία να προβλεφθεί εξαερισμός...
  • Page 5 • Τα μοντέλα XPR W20, W35, W46, W88, W120, W180, W122, F180,46 Outdoor μπορούν είτε να εντοιχιστούν είτε να χρησιμοποιηθούν σε ελεύθερη εγκατάσταση • Τα μοντέλα XPR W40, W300, Milos, Mykonos, Santorini είναι αποκλειστικά και ΜΟΝΟ ελεύθερης εγκατάστασης. Όλα τα μοντέλα (XPR W40, W300, Milos, Mykonos, Santorini) που...
  • Page 6 ΕΓΚΑΤΑΣΤΑΣΗ ΤΟΥ ΣΥΝΤΗΡΗΤΗ • Αφαιρέστε όλη τη συσκευασία και τα προστατευτικά μέρη (εσωτερικά και εξωτερικά του συντηρητή) που χρησιμοποιούνται κατά την μεταφορά. • Ο συντηρητής πρέπει να τοποθετηθεί σε τέτοια θέση ώστε να είναι εύκολη η πρόσβαση σε μπρίζα ρεύματος. Ελευθερώστε το καλώδιο ρεύματος. Μετακινείστε και τοποθετείστε...

  • Page 7: Οδηγιεσ Χρησησ

    ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ • Μην τοποθετείτε καλύμματα ή εμπόδια πάνω στα ράφια που αποτρέπουν την σωστή κυκλοφορία του αέρα ανάμεσα από τα ράφια • Το φίλτρο ενεργού άνθρακα να αλλάζεται μια φορά το χρόνο • Αν ο συντηρητής μείνει αρκετό διάστημα εκτός χρήσης, θα πρέπει να καθαριστεί με επιμέλεια...
  • Page 8 Thank you for purchasing a Masterzen Wine Cooler Wine is our passion. Zen. Masterzen. BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Scan with your mobile phone to get access to all the operating instructions Alternatively you can find all the necessary information on the following link https://www.masterzen.gr/content/115/start-...

  • Page 9: Important Safety Instructions

    WARNING The information in this document is subject to modification without any prior notice. IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions. Before connecting the wine cooler to power source, let it stand upright for approximately 6 hours.
  • Page 10 Masterzen offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed. We cannot be held responsible for any error in this manual. Masterzen is not responsible or liable for any spoilage or damage to wines or any other contents incidental or consequential to possible defects of the wine cellar.
  • Page 11 Climate pattern is the room temperature in which you can operate the device to maximum the cooling function. Lower or higher room temperature may influence the device performance resulting in temperature fluctuation and failure to reach the desired temperature. 32ºC±2ºC on appliances of climatic class 0,1,2,3,4, 6 or 8; 43ºC±2ºC on appliances of climatic class 5 or 7 Climate rating Room temperature...
  • Page 12 BEFORE LOADING & PLUGGING IN THE WINE CELLAR Important: All models without front venting (air opening) are strictly for free standing only. (See technical chart) Before connecting the wine cooler to power source, let it stand upright for approximately 6 hours. This will reduce risk of a malfunction in the cooling system from handling during transportation Recommendations: The location you have selected for your wine cellar should:...

  • Page 13: Installing Your Wine Cellar

    Grounding instructions: The wine cellar must be grounded in case of wire leakage. Grounding reduces the risk of electrical shock. The wine cellar is equipped with a power cord having a grounding wire and plug. The wine cellar plug must be plugged into a properly affixed and grounded electrical outlet.
  • Page 14 Leveling your wine cellar Wine cellar must be leveled BEFORE loading your wines. Your wine cellar is equipped with 4 adjustable feet to facilitate easy leveling. We recommends that you tighten the back feet to the maximum and adjust the front feet to level the wine cellar.
  • Page 15 INSTALLATION INSTRUCTIONS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY. XPR W40, XPR W300, Milos, Mykonos, Santorini models are free standing only. Any built in voids the warranty 1. “Built in” wine cellars are front venting but are not designed to be fully integrated behind a joinery door.
  • Page 16 For XPR 46 Outdoor Precautions for use of outdoor unit: 1. The normal operating environment is 0-35 ℃ (the ideal operating environment temperature). It is forbidden to use it in an environment more than 43 ℃ or lower than - 20 ℃.

  • Page 17: Dimensional Drawings

    INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY Note: The appliance must be positioned so that the plug is accessible after installed. DIMENSIONAL DRAWINGS: It is built-in model inside cabinet, the cabinet should come with good ventilation space and no backplane, otherwise it will affect the wine cooler working normally.
  • Page 18 XPR W24 models with Hettich hinge for decor panel Installation hole depth ≥ 575m m Decorative pa ne l thickness<22mm 559m m Nail a 20~ 22mm thick wood board at the front of the top. 49mm A 20~22mm thick wood board shall be pla ce d at the bottom.
  • Page 19 XPR W30D Models ≥ Cabinet panel ho le h eig ht 615mm ≥ Installation h ole height 605mm ≥ Insta ll ation hol e depth 575mm Wo od Plate thi ckn ess<22m m Ve ntila tion ope ning width ≥40mm ≥7mm Ventilation o pening width ≥40mm...
  • Page 20 XPR W30 models with Hettich hinge for decor panel Installation h ole depth ≥ 575mm Decorative p anel thick ness <22mm 569m m Nail a 2 0~ 22mm thick wood board at t he front of the top. 49mm A 12~15mm thick wood board shall be placed a t the bottom.
  • Page 21 XPR W48 models ≥ Insta llation h ole depth 575mm Woo d Plat e thi ckn ess<22m m Ve ntila tion o pening w idth ≥40mm ≥7mm Ventilation o pen ing width ≥40mm User Manual Συντηρητές Κρασιών XPR...
  • Page 22 XPR W48 models with Hettich hinge for decor panel Installa tion hole de pth ≥ 575mm Decorative pa ne l thickne ss< 22mm 559m m Nail a 20~22m m thick wood board a t the front of the top. 49m m A 20~ 22mm thick wood board sha ll b e placed a t the bottom.
  • Page 23 Fixing in the niche After installing the door panel, push the appliance into the niche, adjust the position, open the door, and fix the appliance into the niche with 2 screws①from the accessory bag through the holes on the upper and lower hinge . Fix the upper and lower door hinges on the wood board with two screws②.
  • Page 24 XPR W106DT Models User Manual Συντηρητές Κρασιών XPR...
  • Page 25 XPR W106DT Models with door panel User Manual Συντηρητές Κρασιών XPR...
  • Page 26 Fixing bracket installation 1.Level the wine cooler, take 2 fixing brackets ① 2 x 5*16 flat head screws ② and 4 screw covers ③ from the polybag. Remove 4 trunk-nails on the left side frame, fix the brackets ① on the left side of with a Philips screwdriver. 2.Take 4 X 4*12 self-tapping screws ④...
  • Page 27 The wood panel can be adjusted on the door : 1. Take out the bracket ⑦, two 5 * 35 large flat screws and two 5 * 25 large flat screws ⑥ from the accessory bag, fix the bracket on the upper and lower sides of the door panel with 4 * 12 self tapping screws ④...
  • Page 28 XPR W20 Models XPR W35 models User Manual Συντηρητές Κρασιών XPR...
  • Page 29 XPR W46 models XPR W46 Models with Hettich hinge for decor panel After adjusting the door panel, take out 4pcs 5*35 self-tapping screws from the accessory bag, User Manual Συντηρητές Κρασιών XPR...
  • Page 30 open the door seal, drill the screws through the screw holes in door frames, and tighten the door panels. 1.Level the wine cooler, take 2 fixing brackets ① 2 x 5*12 flat head screws ② and 2 screw covers ③ from the polybag. Remove 4 trunk-nails on the left side frame of wine cooler, fix the brackets ①...
  • Page 31 XPR 46 Outdoor If the wheel not be installed, the opening size is the same with XPR W46 models. User Manual Συντηρητές Κρασιών XPR...
  • Page 32 XPR W88 models XPR W120 models User Manual Συντηρητές Κρασιών XPR...
  • Page 33 XPR W180/F180 models XPR W122 models OPEN ANGLE SIZE DRAWINGS: User Manual Συντηρητές Κρασιών XPR...
  • Page 34 XPR W20 Models XPR W24S/ W48 Models User Manual Συντηρητές Κρασιών XPR...
  • Page 35 XPR W24, W30, W48DT/W46DT with Hettich hinge / XPR W106DT Models XPR W35 Models User Manual Συντηρητές Κρασιών XPR...
  • Page 36 XPR W30 Models XPR W40 models User Manual Συντηρητές Κρασιών XPR...
  • Page 37 XPR W46 /46 Outdoor models XPR W88, XPR W120, XPR W180, XPR F180 models User Manual Συντηρητές Κρασιών XPR...
  • Page 38 XPR W300 models XPR W42S Milos / Mykonos / Santorini User Manual Συντηρητές Κρασιών XPR...

  • Page 39: Radiator System Description

    XPR W122 models RADIATOR SYSTEM DESCRIPTION XPR W40, XPR W300, XPR W42S Milos/Mykonos/Santorini models use lateral condensation cooling mode. They need at least 10 cm free space from all sides (back, top, left, right) XPR W20/35/46/88/120/180/122/46 Outdoor/F180 Models use side anti-dew tube and User Manual Συντηρητές...
  • Page 40 Independent cooling system: XPR W24S/W30/W48/W106 Models use back cooling system TURNING ON YOUR WINE CELLAR User Manual Συντηρητές Κρασιών XPR...
  • Page 41 Plug in and switch on the cellar by pressing on the power button for a few seconds. When you use the wine cellar for the first time (or restart the wine cellar after having it shut off for a long time), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout.

  • Page 42: Types Of Regulation

    - Do not over load your wine cellar to facilitate air circulation. - Do not stack more than 1.5 rows of standard 0.75L bottles per shelves to facilitate air circulation - Avoid obstructing the internal fans (located inside on the back panel of the wine cellar). - Do not slide the shelves outwards beyond the fixed position to prevent the bottles from falling.
  • Page 43 In the boot state: short press this button, LED lights on / off switch In the boot state: press the button for 3 seconds, the power is off, the whole machine is closed. XPR W20D/W35D Control Panel Operation Guide User Manual Συντηρητές Κρασιών XPR...
  • Page 44 Ø ① “ON/OFF” the power button : In the standby mode: press 3 seconds, the power is turned on, the whole machine starts In the power-on state: press the power button, window 3 shows the countdown 3 2 1, the power is turned off, the machine is turned off (show 3 2 1 process, the hand cannot leave the button) Ø...
  • Page 45 Energy Saving Mode Ø ① Press the button for 3 seconds into the energy-saving mode, press ⑥⑦ out of energy- saving mode ON/OFF the power button: Ø ② In the standby mode: press 3 seconds, the power is turned on, the whole machine starts In the power-on state: press the power button, window 4 shows the countdown 3 2 1, the power is turned off, the machine is turned off (show 3 2 1 process, the hand cannot leave the button)
  • Page 46 “ON/OFF” the power button : Ø ① Press the button 3 seconds to power off (Window ④ digital countdown displays 3, 2, 1,). Press again (without delay), the power turns on. Upper zone temperature setting up button: Ø ② Press one time, window ④ the set value will increase 1 degree Celsius in the original setting temperature, the setting range according to customer requirements.
  • Page 47 XPR W300 /XPR W122 / XPR W46DT with Hettich hinge Display board control instruction Ø ① Power key: Standby mode: short press the button, the power is switched on, the machine starts Boot state: the duration of 3 seconds, the window 10 shows the countdown 321, power off, the whole machine off.
  • Page 48 Boot state, the keyboard does not operate for more than 15 seconds, automatically locked, continued to press 3 seconds to unlock. Ø ⑦ Child lock status prompt: Indicates the locked state. Indicates the unlocked state. Ø ⑧ Faulty system: Indicates that the fault alarm function is activated. For single zone "S"...
  • Page 49 Ø ① Lamp & Power Button: When power cord connected: press and hold for 3 seconds, power is turned on, the machine starts.In the machine power-on-state: press this button, LED lights on; Press once again, LED lights off. In the machine power-on-state: press and hold for 3 seconds, power is turned off, the machine is off.
  • Page 50 When power cord connected: press and hold for 3 seconds, power is turned on, the machine starts.In the machine power-on-state: press this button, LED lights on; Press once again, LED lights off. In the machine power-on-state: press and hold for 3 seconds, power is turned off, the machine is off.
  • Page 51 Ø ⑥ Lower zone temperature setting up button: Press one time, window ⑤ the set value will increase 1 degree Celsius in the original setting temperature, the setting range accordingly to customer requirements. Ø ⑦ Lower zone temperature setting down button: Press one time, window ⑤...

  • Page 52: Defrosting/Condensation/ Hygrometry/ Ventilation

    IMPORTANT INFORMATION ABOUT TEMPERATURE Your wine cellar has been designed to guarantee optimum conditions for storing and/or serving your wines. Fine wines require long and gentle developments and need specific conditions in which to reach their full potential. All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC.
  • Page 53 ADJUSTABLE WOODEN SHELVES Adjusting & removing the shelves Shelf installation and taking instruction: Common wooden shelf: Shelf taking: According to below instruction drawing to press one side of shelf limit pin①, extract and remove the shelf from the other side of support bracket②, then take off the shelf following the arrow mark ③.

  • Page 54: Reversibility Of The Door

    VENTILATION FRAME INSTALLATION METHOD 1.Take out Ventilation frame from cabinet, then take out 4 pcs screws from accessory bag. 2. Open the door, align the ventilation frame to the four screw holes in the bottom of the cabinet and tighten the screw with Phillips screwdriver. REVERSIBILITY OF THE DOOR REMARK: XPR W300 model can’t be door reversible.
  • Page 55 1.Decorative nail 2. Knife 3. Drop-proof device 4. M5 six angle 5. M5 six angle screwdriver 6. Door spindle core 7. Upper door hinge 8. Lower door hinge Milos / Mykonos / Santorini models Door Installation Method To put the cabinet on open operation place； 1.the door opened to the maximum angle, use small knife(2) to take off the decorative nail (1) on opposite side (Drawing 1) 2.To pry the shaft cover③...
  • Page 56 6.Install the decorative nail① to the other side.(Drawing 7) 180° 1 Decorative nail 3. Shaft cover 2. Knife 4. Screwdriver 5. Shaft core 6. Door hinge 7. M5 Socket Screwdriver User Manual Συντηρητές Κρασιών XPR...
  • Page 57 XPR W24, XPR W30,XPR W48 models 1. Knife 2. Decorative nail 3. Cross screwdriver 4. Door shaft screw 5. Upper door hinge 6. M5 six angle screwdriver 7. Lower door hinge Remark: Before operate the reversibility, need to power off at first, and need at least two persons to work on it! 1.
  • Page 58 complete the door body replacement (see Figure 4 & Figure 5). XPR W24, XPR W48 models Installation Instruction: 1.Put the wine cooler into the cabinet, then adjust the wine cooler to make it steady. Open the door, take out the fixed plate , 2pcs Inner Hexagon Screws ,and Inner Hexagon Screwdriver from accessory bag , then use the inner hexagon screwdriver to tighten the fixed plate on the lower left side of wine cooler.
  • Page 59 XPR W106DT, XPR W46 (with door panel ), XPR W48DT (with door panel) models 1.Put the cabinet in an open operating area, have the door opened to the maximum angle. 2. Use the knife② to remove the decorative nails① from the left side of the cabinet. (Figure 1) 3.
  • Page 60 5. At last, install all decorative nails to the other side of the door①, door installation is all set! (Figure 5) Handle Installation Method 1. Take out handle from cabinet, then take out 2pcs M4 screws from accessory bag. 2. Pull open door seal from the side of door, then insert screws into the 2 handle holes on side of door, then put the screws alignment the hole of handle , tighten the screws by Phillips screwdriver，then compress the door seal User Manual...

  • Page 61: Operation Anomalies

    If the screws holes of the handle don't match perfectly with the holes of the door ,please use the electric drill to drill the holes of the door a bit big ( in surface side) , in order to install the handle perfectly . OPERATION ANOMALIES Ensure that there is power to the electrical supply plug by connecting another electrical appliance to it.

  • Page 62: Troubleshooting Guide

    Irrespective of the cause, if you notice either abnormal temperature or humidity levels inside your wine cellar, be reassured that only long and frequent exposure to these abnormal conditions can cause a detrimental effect on your wines. TROUBLESHOOTING GUIDE Common problems may easily be solved, saving you the cost of a possible service call. Please read carefully the instruction manual and revert to troubleshooting guide chart.
  • Page 63 Standard features: Compressor operated: R600a - Available in rated voltage/frequency (as per country' requirements): 220V/50Hz - Automatic defrost - Humidity : 65% RH +/-10% RH - Black outer and inner finish - Internal light - Adjustable feet x 4 - Two glass door - Optional Common or Seamless stainless steel finish door frame or Full black glass door Before disposal of the appliance.
  • Page 64 R600a WARNINGS: For your safety observe the following recommendations. • This appliance contains a small quantity of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. • During transportation and installation, ensure that the tubing of the refrigerant circuit is not damaged.
  • Page 65 It is hazardous for anyone other than an Authorized Service Person to carry out servicing or repairs to this appliance. • WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction. • WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 66 info@masterzen.gr...
