  • Page 1 Συντηρητές Κρασιών INSTRUCTION MANUAL XPR W7S models XPR W20S models XPR W24S models XPR W30S/D models Milos / Mykonos / Santorini models XPR W48S / W48DT models XPR W40S/D/DT models XPR W46S/D/DT models XPR W88S/D/DT models PRM 88, PRM 180 models...
  • Page 2 Σας ευχαριστούμε που επιλέξατε το Συντηρητή Κρασιών Masterzen. Η τέχνη του Ευ Ζην. Το πάθος μας είναι το κρασί. Το κρασί τοποθετείται στους συντηρητές Μasterzen και αναδεικνύεται ως έργο τέχνης. User Manual Συντηρητές Κρασιών XPR...
  • Page 3 ΤΟΥ ΣΥΝΤΗΡΗΤΗ Σκανάρετε με το κινητό σας τηλέφωνο και βρείτε συγκεντρωμένες όλες τις οδηγίες χρήσης και ασφαλείας Εναλλακτικά μπορείτε να επισκεφτείτε το site μας στο ακόλουθο σύνδεσμο: h�ps://www.masterzen.gr/content/115/start- ή www.masterzen.gr Τοποθετείστε το συντηρητή στην τελική του θέση. Πριν τη σύνδεση του...
  • Page 4 ΠΡΙΝ ΑΡΧΙΣΕΤΕ ΝΑ ΓΕΜΙΖΕΤΕ ΚΑΙ ΝΑ ΘΕΤΕΤΕ ΣΕ ΛΕΙΤΟΥΡΓΕΙΑ ΤΟΝ ΣΥΝΤΗΡΗΤΗ ΠΡΟΣΟΧΗ: • Τα μοντέλα XPR W7, W24, W48 είναι αποκλειστικά για εγκατάσταση πλήρους εντοίχισης. Παρακαλούμε να ακολουθήσετε πιστά τις οδηγίες για την σωστή εγκατάσταση και εξαερισμό του συντηρητή. Αποτυχία να προβλεφθεί εξαερισμός σύμφωνα...
  • Page 5 ΕΓΚΑΤΑΣΤΑΣΗ ΤΟΥ ΣΥΝΤΗΡΗΤΗ • Αφαιρέστε όλη τη συσκευασία και τα προστατευτικά μέρη (εσωτερικά και εξωτερικά του συντηρητή) που χρησιμοποιούνται κατά την μεταφορά. • Ο συντηρητής πρέπει να τοποθετηθεί σε τέτοια θέση ώστε να είναι εύκολη η πρόσβαση σε μπρίζα ρεύματος. Ελευθερώστε το καλώδιο ρεύματος. Μετακινείστε και...
  • Page 6 ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ • Μην τοποθετείτε καλύμματα ή εμπόδια πάνω στα ράφια που αποτρέπουν την σωστή κυκλοφορία του αέρα ανάμεσα από τα ράφια • Το φίλτρο ενεργού άνθρακα να αλλάζεται μια φορά το χρόνο • Αν ο συντηρητής μείνει αρκετό διάστημα εκτός χρήσης, θα πρέπει να καθαριστεί με επιμέλεια...
  • Page 7 Thank you for purchasing a Masterzen Wine Cooler Wine is our passion. Zen. Masterzen. BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Scan with your mobile phone to get access to all the opera�ng instruc�ons Alterna�vely you can find all the necessary informa�on on the following link h�ps://www.masterzen.gr/content/115/start-...

  • Page 8: Important Safety Instructions

    WARNING The informa�on in this document is subject to modifica�on without any prior no�ce. IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precau�ons. Before connec�ng the wine cooler to power source, let it stand upright for approximately 6 hours.
  • Page 9 Masterzen offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed. We cannot be held responsible for any error in this manual. Masterzen is not responsible or liable for any spoilage or damage to wines or any other contents incidental or consequen�al to possible defects of the wine cellar.
  • Page 10 Climate Pa�ern Climate pa�ern is the room temperature in which you can operate the device to maximum the cooling func�on. Lower or higher room temperature may influence the device performance resul�ng in temperature fluctua�on and failure to reach the desired temperature. 32ºC±2ºC on appliances of clima�c class 0,1,2,3,4, 6 or 8;...

  • Page 11: Installing Your Wine Cellar

    Notes: XPR W7, W24, W48 model is for built-in ONLY ● XPR W40, W300, Milos, Mykonos, Santorini models are for free standing ONLY. ● XPR W20, W46, W88, W120, W180,W122, 46 Outdoor, F180 models are Both built-in ● and free-standing type as per the drawings therea�er. Wine cellar should be placed where the ambient temperature is proper (Please view the end of Manual).
  • Page 12 Leveling your wine cellar Wine cellar must be leveled BEFORE loading your wines. Your wine cellar is equipped with 4 adjustable feet to facilitate easy leveling. We recommends that you �ghten the back feet to the maximum and adjust the front feet to level the wine cellar.
  • Page 13 INSTALLATION INSTRUCTIONS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY. XPR W40, XPR W300, Milos, Mykonos, Santorini models are free standing only. Any built in voids the warranty 1. “Built in” wine cellars are front ven�ng but are not designed to be fully integrated behind a joinery door.
  • Page 14 For XPR 46 Outdoor Precau�ons for use of outdoor unit: 1. The normal opera�ng environment is 0-35 ℃ (the ideal opera�ng environment temperature). It is forbidden to use it in an environment more than 43 ℃ or lower than - 20 ℃.

  • Page 15: Dimensional Drawings

    INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY Note: The appliance must be posi�oned so that the plug is accessible a�er installed. DIMENSIONAL DRAWINGS: It is built-in model inside cabinet, the cabinet should come with good ven�la�on space and no backplane, otherwise it will affect the wine cooler working normally.
  • Page 16 XPR W48 models Insta llation h ole depth≥575mm Woo d Plat e thi ckn ess<22m m Ve ntila tion o pening w idth ≥40mm ≥7mm Ventilation o pen ing width ≥40mm User Manual Συντηρητές Κρασιών XPR...
  • Page 17 XPR W20S Models User Manual Συντηρητές Κρασιών XPR...
  • Page 18 XPR W30S/D Models Cabinet panel ho le h eight ≥615mm Installation h ole height≥605mm Insta ll ation hol e depth≥575mm Wo od Plate thi ckn ess<22m m Ve ntila tion ope ning width ≥40mm ≥7mm Ventilation o pening width ≥40mm User Manual Συντηρητές...
  • Page 19 XPR W46 models XPR 46 Outdoor If the wheel not be installed, the opening size is the same with XPR W46 models. User Manual Συντηρητές Κρασιών XPR...
  • Page 20 XPR W88 models XPR W120 models User Manual Συντηρητές Κρασιών XPR...
  • Page 21 XPR W180/F180 models XPR W122 models User Manual Συντηρητές Κρασιών XPR...
  • Page 22 XPR W7S models User Manual Συντηρητές Κρασιών XPR...
  • Page 23 OPEN ANGLE SIZE DRAWINGS: XPR W20S XPR W24S /W48 Models User Manual Συντηρητές Κρασιών XPR...
  • Page 24 XPR W30 Models XPR W40 models User Manual Συντηρητές Κρασιών XPR...
  • Page 25 XPR W46 /46 Outdoor models XPR W88 , XPR W120 , XPR W180 ,XPR F180 models User Manual Συντηρητές Κρασιών XPR...
  • Page 26 XPR W300 models Milos / Mykonos / Santorini models User Manual Συντηρητές Κρασιών XPR...
  • Page 27 XPR W7S models XPR W122 models User Manual Συντηρητές Κρασιών XPR...

  • Page 28: Radiator System Description

    RADIATOR SYSTEM DESCRIPTION XPR W40, XPR W300, Milos / Mykonos / Santorini models use lateral condensa�on cooling mode XPR W20/46/88/120/180/122/46 Outdoor/F180 Models use side an�-dew tube and Independent cooling system: User Manual Συντηρητές Κρασιών XPR...
  • Page 29 XPR W7S Model use Air cooling system XPR W24S/W30/W48 Models use back cooling system User Manual Συντηρητές Κρασιών XPR...
  • Page 30 TURNING ON YOUR WINE CELLAR Plug in and switch on the cellar by pressing on the power bu�on for a few seconds. When you use the wine cellar for the first �me (or restart the wine cellar a�er having it shut off for a long �me), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout.

  • Page 31: Types Of Regulation

    - Do not over load your wine cellar to facilitate air circula�on. - Do not stack more than 1.5 rows of standard 0.75L bo�les per shelves to facilitate air circula�on - Avoid obstruc�ng the internal fans (located inside on the back panel of the wine cellar). - Do not slide the shelves outwards beyond the fixed posi�on to prevent the bo�les from falling.

  • Page 32: ② Cycle Button

    If you want the light to stay on, just turn it on. The door lamp switch will not be controlled. XPR W7S/W20S/W24S DISPLAY BOARD OPERATING INSTRUCTION: ➢ ① Display Window: Display the measured temperature inside the wine cooler;...
  • Page 33 XPR W40/46/48/88/120/180S/46 outdoor/F180 Single temperature Display Board Control Instruction: ➢ ① Energy SavingMode Press the bu�on for 3 seconds into the energy-saving mode, press ⑥⑦ out of energy-saving mode ➢ ② ON/OFF the power bu�on: In the standby mode: press 3 seconds, the power is turned on, the whole machine starts In the power-on state: press the power bu�on, window 4 shows the countdown 3 2 1, the power is turned off, the machine is turned off (show 3 2 1 process, the hand cannot leave the bu�on)
  • Page 34 XPR W40/46/48/88/85/120/180D Dual Temperature Display Board Control Instruc�on: ➢ “ON/OFF” the power bu�on : Press the bu�on 3 seconds to power off (Window ④ digital countdown displays 3, 2, 1,). Press again (without delay), the power turns on. ➢ Upper zone temperature se�ng up bu�on: Press one �me, window ④...
  • Page 35 XPR W300 /XPR 122 Display Board Control Instruction ➢ Power key: Standby mode: short press the button, the power is switched on, the machine starts Boot state: the duration of 3 seconds, the window 10 shows the countdown 321, power off, the whole machine off. ➢...
  • Page 36 locked, continued to press 3 seconds to unlock. ➢ Child lock status prompt: Indicates the locked state. Indicates the unlocked state. ➢ Faulty system: Indicates that the fault alarm function is activated. For Single temperature "S" "B"series ➢ Display the current setting temperature. ➢...
  • Page 37 XPR W30S Double temperature display board opera�on instruc�ons: ➢ Lamp & Power Bu�on: When power cord connected: press and hold for 3 seconds, power is turned on, the machine starts.In the machine power-on-state: press this bu�on, LED lights on; Press once again, LED lights off.

  • Page 38: Wine Serving Temperature Chart

    ➢ Lamp & Power Bu�on: When power cord connected: press and hold for 3 seconds, power is turned on, the machine starts.In the machine power-on-state: press this bu�on, LED lights on; Press once again, LED lights off. In the machine power-on-state: press and hold for 3 seconds, power is turned off, the machine is off.

  • Page 39: Defrosting/Condensation/ Hygrometry/ Ventilation

    IMPORTANT INFORMATION ABOUT TEMPERATURE Your wine cellar has been designed to guarantee op�mum condi�ons for storing and/or serving your wines. Fine wines require long and gentle developments and need specific condi�ons in which to reach their full poten�al. All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC.
  • Page 40 ADJUSTABLE WOODEN SHELVES Adjus�ng & removing the shelves For easy access to the storage content, you must pull the shelves approximately 1/3 of its depth out of the rail compartment. These wine cabinets, however, are designed with a notch on each side of the shelf tracks to prevent bo�les from falling. When removing any of these shelves out of the rail compartment, �lt the shelf as per the diagram and simply pull out, or push in the shelf un�l it sits on the support brackets securely.
  • Page 41 To prevent damaging the door gasket, make sure that the door is fully opened when pulling out the shelves. 1.Take out Ventilation frame from cabinet, then take out 4 pcs 4 * 12 screws from accessory bag. 2. Open the door, align the ventilation frame to the four screw holes in the bottom of the cabinet and tighten the screw with Phillips screwdriver.

  • Page 42: Reversibility Of The Door

    REVERSIBILITY OF THE DOOR REMARK: XPR W300 model can’t be door reversible. Warning: To avoid accidents during the process of changing the door, we recommend that you get assistance. The glass door is heavy and may cause injury if dropped. - Depending on to the model and the type of handle your wine cabinet is equipped with, you may have to rotate the door through 180 degrees.
  • Page 43 1.Decora�ve nail 2. Knife 3. Drop-proof device 4. M5 six angle 5. M5 six angle screwdriver 6. Door spindle core 7. Upper door hinge 8. Lower door hinge User Manual Συντηρητές Κρασιών XPR...
  • Page 44 Milos / Mykonos / Santorini models Door Installa�on Method To put the cabinet on open opera�on place； 1.the door opened to the maximum angle, use small knife(2) to take off the decora�ve nail (1) on opposite side (Drawing 1) 2.To pry the sha� cover③ out by a screwdriver④ (Drawing 2) 3.To pry the sha�...
  • Page 45 XPR W24, XPR W30, XPR W48 models Tools need to prepare: Knife Hexagon wrench Remark: Before operate the reversibility, need to power off at first, and need to cooperate with two people! 1.Open the door, twist off the screws from upper hinge and lower hinge by hexagon wrench, remove the door.( as picture FIG.A and picture FIB.B) Upper hinge Lower hinge...
  • Page 46 Trunk-nail FIG.C FIG.D Trunk-nail FIG.E 3.To rotate the door 180 degrees, and to align the upper and lower hinges with the hinge holes of the le� side. To adjust the door, and �ghten the screws with hexagon wrench, and then complete the door replacement. (as picture FIG.F, FIG.G and FIG.H) FIG.F FIG.G FIG.H...
  • Page 47 1. Knife 2. Decora�ve nail 3. Cross screwdriver 4. Door sha� screw 5. Upper door hinge 6. M5 six angle screwdriver 7. Lower door hinge Remark: Before operate the reversibility, need to power off at first, and need to cooperate with two people! 1.
  • Page 48 4. Rotate the removed door 180 degrees, align the upper and lower ends directly with the door hinge hole on the le� side of the box, adjust the door body, �ghten the upper and lower screws(4) with a cross screwdriver, and install the removed Decora�ve nail(2) to the right to complete the door body replacement (see Figure 4 &...

  • Page 49: Operation Anomalies

    Handle Installa�on Method 1. Take out handle from cabinet, then take out 2pcs M4 screws from accessory bag. 2. Pull open door seal from the side of door, then insert screws into the 2 handle holes on side of door, then put the screws alignment the hole of handle , �ghten the screws by Phillips screwdriver，then compress the door seal If the screws holes of the handle don't match perfectly with the holes of the door ,please use the electric drill to drill the holes of the door a bit big ( in surface side) ,...

  • Page 50: Power Failures

    warranty being considered as null and void. POWER FAILURES In the event of a power interrup�on, all previous temperature se�ngs are automa�cally preserva�on and it will revert to a preset temperature se�ng. (See preset chart) Most power failures are corrected within a short period of �me. An hour or two’s loss of power will not affect wine cellar’s temperatures.
  • Page 51 Vibra�ons. Check to assure that the Wine cellar is level. The Wine cellar The ra�ling noise may come from the flow of the refrigerant, which is seems to make normal. too much noise. As each cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your Wine cellar.
  • Page 52 R600a WARNINGS: For your safety observe the following recommenda�ons. • This appliance contains a small quan�ty of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. • During transporta�on and installa�on, ensure that the tubing of the refrigerant circuit is not damaged.
  • Page 53 WARNING: Keep ven�la�on openings in the appliance enclosure or in the built-in ● structure clear of obstruc�on. WARNING: Do not use mechanical devices or other means to accelerate the defros�ng ● process, other than those recommended by the manufacturer. WARNING: Do not damage the refrigerant circuit. ●...
