Wine Cellar Model Dimensions and installation Guide
Thanks for buying our Wine Cooler, Hope our advanced product will give your wine a
different joyful taste. Before use, please read and follow all safety rules and operating
instructions.
Wine Cellars & Coolers
XPR W7S
XPR W24S
XPR W48DT
XPR W40S/
XPR W46SD
XPR W88S/D
XPR W180S/D
XPR W300S/D
Advertisement
Related Manuals for Masterzen XPR W7S
Summary of Contents for Masterzen XPR W7S
- Page 1 Wine Cellars & Coolers Wine Cellar Model Dimensions and installation Guide XPR W7S XPR W24S XPR W48DT XPR W40S/ XPR W46SD XPR W88S/D XPR W180S/D XPR W300S/D Thanks for buying our Wine Cooler, Hope our advanced product will give your wine a different joyful taste.
- Page 2 WARNING The information in this document is subject to modification without any prior notice. Some models are available in dedicated countries only. offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed.
- Page 3 R600a WARNINGS: For your safety observe the following recommendations. This appliance contains a small quantity of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. During transportation and installation, ensure that the tubing of the refrigerant circuit is not damaged.
- Page 4 BEFORE LOADING & PLUGGING IN THE WINE CELLAR Important: All models without front venting (air opening) are strictly for free standing only. (See technical chart) Recommendations: The location you have selected for your wine cellar should: - be unencumbered and well ventilated; - be well away from any heat source and direct sunlight;...
-
Page 5: Installing Your Wine Cellar
INSTALLING YOUR WINE CELLAR Unpack and remove all of the protection and adhesive strips from the packaging around and inside the wine cellar. The wine cellar must be positioned such that the plug is accessible. Release the power cord. Move your wine cellar to its final location. The wine cellar should be installed in a suitable place where the compressor will not be subject to physical contact. - Page 6 In Hot climate zone, an air vent or grid, with a minimum ventilation size of 200mm x 40mm MUST be cut out at the rear top of the back partitioning or at the top of either side of the partitioning, allowing cool fresh air full access to flow into the 30mm gap located at the rear of the cabinet.
- Page 7 Dimensions and type of installation Masterzen XPR Χωρητικότητα Zώνες Αριθμός Τύπος Πλάτος x Βάθος x Product Line σε φιάλες θερμοκρασί Ξύλινων Εγκατάστασης Υψος (cm) ας Ραφιών Ελεύθερη & 14,7 x 54 x 82 Εντοιχιζόμενη W24S Πλήρως 59,2 x 55,5 x 45,5 Εντοιχιζόμενη...
-
Page 8: Dimensional Drawings
INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY Note: The appliance must be positioned so that the plug is accessible after installed. DIMENSIONAL DRAWINGS: It is built-in model inside cabinet, the cabinet should come with good ventilation space and no backplane, otherwise it will affect the wine cooler working normally. - Page 9 XPR W24S Installation Dimension W564*H453*D550 The back without a plate XPR48DT Installation Dimension W564*H878*D550 The back without a plate...
- Page 10 XPR W46 XPR W88...
- Page 11 XPR W180 XPR W7S...
- Page 12 OPEN ANGLE SIZE DRAWINGS: XPR W24S XPR W40...
- Page 13 XPR W46 XPR W88 / XPR W180...
- Page 14 XPR W300 XPR W7S...
-
Page 15: Radiator System Description
RADIATOR SYSTEM DESCRIPTION XPR W40,XPR W300,models use lateral condensation cooling mode XPR W46/88/180 Models use side anti-dew tube and Independent cooling system:... - Page 16 XPR W7S Model use Air cooling system...
