- Page 1 How to use 1200KI& 1006KI 485 control back-end GUI4.0 HIKVISION EU PRODUCT TEAM 2019-5-13...
- Page 2 How to use 485 control back-end GUI4.0 How to use 1200KI & 1006KI 485 control back-end GUI4.0 This document is intended to introduce the method of how to use 1200KI & 1006KI 485 control back-end GUI4.0 (NVR version 4.21.000 is recommended). We will start from hardware connection 1.
- Page 3 485 parameters of backend KB interface are fixed, so you always need to configure Baud Rate 9600, Bit Rate 8, Stop Bit 1, and Parity None, click OK button to save the settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 4 (sometimes you need to press ESC for several times, you can move joystick to see if device’s under top menu, there will be blue icon when you push the stick) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 5 2) Or push joystick left/right to change camera to last/next one 3) You can press FOCUS-/MULT button to create window division one by one, 2,4,6, etc…, and use joystick to switch between pages © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 6 9. To control playback 1) Press NUM button to select the camera you want playback 2) And PATTERN/PLAY button to select date (use joystick to make switch), click OK to make selection © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 7 How to use 485 control back-end GUI4.0 3) You can push joystick up/down to speed up/slow down playback 4) And joystick left/right to move backward/forward 30s Below function list for your reference © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 8 How to use 485 control back-end GUI4.0 Note the function may be different regarding NVR firmware version, pls make sure to use latest to achieve best compatibility © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
- Page 9 How to use 485 control back-end GUI4.0 See Far, Go Further © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
