FIRE PIT
ITM./ART.#: SRGF12111
MODEL#: ET-F-003-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
DANGER
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
Questions, problems, missing parts? Be fore retu rning to your retaile r, call our customer service
department at 1-888-909-3888, 7:30 AM - 4:30 PM PST, Monday - Friday, or e-mail to
customerservice@shinerich.us.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids,in the
vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ET-F-003-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatmaxx ET-F-003-A1

Summary of Contents for Heatmaxx ET-F-003-A1

  • Page 1 FIRE PIT ITM./ART.#: SRGF12111 MODEL#: ET-F-003-A1 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only. CONSUMER: Retain this manual for future reference. Installation and service must be performed by a qualified installer, DANGER service agency, or the gas supplier.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).

  • Page 3: Specifications

    IMPORTANT SAFETY INFORMATION ABOUT PROPANE GAS The propane supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for propane cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. The propane supply cylinder to be used must have a listed overfilling prevention device (See Figure 1).

  • Page 4: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire table 1 pc 1 pc Door 1 pc Weather cover Lava rock (4.18 Ibs) 1 box Battery 1 pc ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
  • Page 5 3. Place the gas cylinder into the gas cylinder support and connect the regulator by turning the black handle clockwise to tighten. To remove the regulator, turn the black handle counter-clockwise. Secure the gas cylinder by tightening clockwise the retention point found on gas cylinder support (see Figure 3), so that the gas cylinder cannot move from side to side or fall down.
  • Page 6 BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery, (see Figure 6). WARNING: 1.

  • Page 7: Lighting Instructions

    gas valve / regulator hose connection (Figure 9) inlet tube / bellows connection (Figure 10) To perform a leak test: 1. Make 2~3 oz. of leak solution by mixing one part liquid dishwasher detergent and three parts water. Noted: make sure control knob is “OFF”.

  • Page 8: Care And Maintenance

    Observe Flame Height When Lit: The burner will display blue and yellow flames. These flames should be a blue / yellow color between 1~2 in. height, (see Figure 12). These flames should not be yellow or produce thick smoke. This would indicate an obstruction of airflow through the burners. The flames should be blue with straight yellow tops. Good Yellow Yellow...

  • Page 9: Warranty

    WARRANTY Firepits Burner, steel fire pit bowl, all mechanical parts and fittings to control panel and burner assembly, and all fire pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship.
