FIRE PIT
ITM./ART.#: SRGF12101
MODEL#: F210004-B2
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
DANGER
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
Questions, problems, missing parts? Be fore retu rning to your retaile r, call our customer service
department at 1-888-909-3888, 7:30 AM - 4:30 PM PST, Monday - Friday, or e-mail to
customerservice@shinerich.us.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids,in the
vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heatmaxx F210004-B2
Summary of Contents for Heatmaxx F210004-B2
- Page 1 FIRE PIT ITM./ART.#: SRGF12101 MODEL#: F210004-B2 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only. CONSUMER: Retain this manual for future reference. Installation and service must be performed by a qualified installer, DANGER service agency, or the gas supplier.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa). -
Page 3: Specifications
IMPORTANT SAFETY INFORMATION ABOUT PROPANE GAS The propane supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for propane cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. The propane supply cylinder to be used must have a listed overfilling prevention device (See Figure 1). -
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY 1 pc Glass beads (12 lbs / pack) 1 pack 1 pc 1 pc Table top assembly Weather cover 1 pc 1 pc Back panel Door handle 1 pc 1 pc Left panel Battery Door panel 1 pc... - Page 5 ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product. If any part is missing or damaged, do not attempt to assemble the product.
- Page 6 5. Attach back panel (C) to back-left leg (G) and back-right leg (H) with bolts (AA) and washer (CC) using hex screw driver (DD), (see Figure 5). NOTE: DO NOT tighten the screws completely. Hardware Used: Bolts (M6 x 12) Washer (M6) Hex screw driver Figure 5...
- Page 7 9. Open the box of lava rocks, put the glass beads (L) into the fire bowl of the fire table (B), (see Figure 9). A gas fire pit requires 11 lbs glass beads. WARNING: Keep children away during assembly, as this item contains glass bead, which are small pieces and can be swallowed by children.
- Page 8 11. Once the firepit has cooled completely after use, carefully place the lid (A) onto the fire bowl and use the weather cover (M) to protect your fire pit from the elements, (see Figure 11). WARNING: Allow 30 minutes after use for fire pit to cool down before placing the lid to prevent scalding. Figure 11 BATTERY Make sure the control knob is in the “OFF”...
- Page 9 LEAK TEST To prevent fire or explosion hazard when testing for a leak: 1. Always perform the leak test as described below before lighting this appliance or each time the cylinder is connected for use. 2. Do not smoke or allow other sources of ignition in the area while conducting a leak test. 3.
-
Page 10: Lighting Instructions
LIGHTING INSTRUCTIONS 1. Push in gas control knob slightly and turn to “OFF”. 2. Turn gas control knob to “ON/MIN”. 3. Push in gas control knob all the way and hold. Continue to press the ignition button for 15 seconds. 4. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE To enjoy the outstanding performance from your fire pit, make sure you perform the following activities on a regular basis: 1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. 2. While cleaning the fire pit, make sure to keep the area around the burner dry at all times. DO NOT submerge the control valve assembly. -
Page 12: Warranty
WARRANTY Firepits Burner, steel fire pit bowl, all mechanical parts and fittings to control panel and burner assembly, and all fire pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship.
