NOTE: The connector dock in a 32-bit PCI slot is shorter than in a 64-bit PCI slot.
Although the adapter is designed to fit in either slot type, when installed in a 32-bit PCI
slot, part of the adapter's connector edge will remain undocked. This is perfectly normal.
5. Applying even pressure at both corners of the card, push the adapter card until it is firmly
seated in the PCI slot. When properly seated, the adapter's port connectors are aligned with the
slot opening, and its faceplate is flush against the system chassis.
CAUTION: Do not use excessive force when seating the card, as this may
damage the system or the adapter. If the card resists seating, remove it from
the system, realign it, and try again.
6. Secure the adapter with the adapter clip or screw.
7. Replace the system cover and disconnect any personal antistatic devices.
8. Power the system on.
After the system returns to proper operation, the adapter hardware is fully installed. Go to
the network cables.

Connecting the Network Cables

The adapter has one RJ-45 connector used for attaching the system to an Ethernet copper-wire
segment. When automatic link negotiation is disabled, the port can be configured for 10 Mbit/s or 100
Mbit/s, signaling either half-duplex or full-duplex operation.
Perform the following procedure for connecting a network cable to the Broadcom 440X 10/100
Integrated Controller:
1. Prepare an appropriate cable. The table lists the cable requirements for connecting to
10/100BASE-T ports:
10/100BASE-T Cable Specifications
Port Type Connector
10BASE-T
100BASE-T RJ-45
2. Connect one end of the cable to the Broadcom 440X 10/100 Integrated Controller.
3. Connect the other end of the cable to an RJ-45 Ethernet network port.
RJ-45 Category 3, 4, or 5 UTP 100 meters (328 feet)
Category 5 UTP
Media Maximum Distance
100 meters (328 feet)
