Setup - Network Setup
RTSP Information
Target Stream - Select the channel you want to set.
Time out - Set the RTSP time out.
The session is disconnected after the specified time out.
RTP Multicast - Check RTP Multicast On/Off. To activate RTP Multicast.
1. Click "On" button
2. Enter accessible RTP Multicast IP, port for video stream control, RTP packet TTL
3. Click "Apply" button.
It is possible to set each RTP Multicast for CH1~3.
Click 'Apply' to make above setting effective.
Click this button when completed setup each channels.
It shows RTSP Connection information.
