Summary of Contents for TECE Uni

  • Page 1 Sanitary systems TECE FLUSHING TECHNOLOGY TECHNICAL INFORMATION...
  • Page 2 All data contained in the Technical Information has been compiled with the utmost care. However, the correctness of the data presented cannot be guaranteed. TECE assumes no liability for damage resulting from the use of this information. Text and images are protected by copyright law.
  • Page 3: Table Of Contents

    Filling valve F 1 Drain valve A 3 Throttle set 4-10 Installation 4-11 Toilet flush plates 4-12 U 1 TECE urinal flush valve 4-13 Mechanical flush valve 4-13 U 1 electronic flush valve 4-14 Urinal flush valve assembly instructions 4-16 Programming the urinal infrared electronics 4-17 Flush plates for the new U 1 urinal valve...
  • Page 4: Uni Cistern

    Tank As the tank volume is 10 litres, there is always plenty of The Uni cistern from TECE is a universally usable stand- water for flushing. Even after flushing with the large flush ard cistern. By using different frames, the cistern can be volume, water is always available for a follow-up flush.
  • Page 5 Uni cistern Setting the flush volumes Increasing the flushing pressure: The flush volume is adjusted centrally via an adjustment If the toilet ceramics are not being cleaned correctly, the slide on the back of the drain valve. The adjustable flush flushing pressure for standard cisterns can be subse- quantities are clearly marked on the valve.
  • Page 6: F 10 Filling Valve

    F 10 filling valve 42 mm The F 10 replacement filling valve (item no. 9820353) universally fits in all TECE cisterns and in many competing cisterns. 36 mm Conversion set 9820223, scope of delivery The TECE cistern drain valve can be easily replaced.
  • Page 7 Uni cistern Filling level setting (filling valve) The filling level in the cistern can be set by turning the adjustment spindle on the filling valve. The height should be set so that the water reaches the upper mark on the overflow of the drain valve and the upper mark in the cistern (see illustration).
  • Page 8: Cistern 8 Cm

    Thanks to the high technical quality standard of the filling The concealed cistern from TECE is a universally usable system (valve, hose and F1 valve) the TECE cistern is char- 8 cm cistern. By using different frames, the cistern can be acterised by the lowest sound level on the market - Lap ≤...
  • Page 9: Drain Valve A 3

    Here, the intelligent solu- The large flush volume can be set to 4.5 / 6.0 or 9.0 litres. tions from TECE can make an active contribution to saving water. With dual-flush technology the small flush volume is The default setting is 6 litres.
  • Page 10: Throttle Set

    Installation To reduce the default large volume to 4.0 and the small Throttle set volume to 2.5 litres, the tank water level lever above the If the flushing of a toilet ceramic is not adequate, the flush- filling valve must also be moved to the lowest mark on the ing pressure can be reduced or increased with the help of overflow.
  • Page 11: Installation

    A damaged seal shows A special feature of the TECE cistern is the actuation block that the cistern has already been opened. mounted on the splash guard. When the cistern is opened, it is completely removed.
  • Page 12: Toilet Flush Plates

    Installation Toilet flush plates All manual TECE flush plates fit the Uni and 8 cm cisterns. The electronic actuators can only be used on the Uni cis- tern with front actuation and an actuation height of 1 m. TECEambia Overview of TECE toilet flush plates...
  • Page 13: U 1 Tece Urinal Flush Valve

    The shut-off valve is located in the valve housing and is adjusted by means of an Allen key (size 3 mm). Turn 90° The TECE U 1 urinal flush valve is based on a further anti-clockwise to close, 90° clockwise to open the shut-off development of tried and tested flush valve technology.
  • Page 14: U 1 Electronic Flush Valve

    (connector with white marking) and one to an electronic cartridge (connector with black marking). Adjusting the volume on the mechanical cartridge All TECE manual urinal flush plates can be used together with the U 1 mechanical urinal flush valve. U 1 electronic flush valve Touch-free electronics are often required particularly in the public sector.
  • Page 15 Series installation of 5 urinal electronics, schematic diagram item number 9810003, please order separately). It is recommended that only TECE original products are The electronics has one connection to the transformer used for the installation. Make sure that the polarity is cor- (connector with white marking) and one to an electronic rect when connecting the cables.
  • Page 16: Urinal Flush Valve Assembly Instructions

    U 1 TECE urinal flush valve Technical data 230 V/12 V mains transformer Urinal flush valve assembly instructions Note: This section provides instructions for the essential points of installation. The notes are thus explained sections from the overall assembly procedure. The entire installa- tion procedure is shown in the assembly instructions for the corresponding items.
  • Page 17: Programming The Urinal Infrared Electronics

    Approximately five seconds after being connected to the power supply, TECE electronics can be programmed in the first 60 minutes. Each configurable function is assigned a The mechanical cartridge is simply screwed into the hous- position.
  • Page 18: Flush Plates For The New U 1 Urinal Valve

    See the whole range online Hold the program Count the individual beeps until Remove the program- at www.tece.com/en. All urinal flush plates are shown in ming key in front the desired position is reached ming key of the sensor this overview.
  • Page 19 The TECEfilo urinal electronics are available with a metal, glass or plastic surface. As a result, their look harmonis- es perfectly with various TECE toilet flush plates such as with the TECEsquare metal, TECEsquare glass or with the TECEnow toilet flush plate. The TECEfilo urinal electronics with a glass or plastic surface can also be mounted flush to the surface with the TECEfilo installation frame.
  • Page 20: U 2 Urinal Flush Valve Assembly Instructions

    U 2 TECEfilo urinal flush valve The U 2 TECE urinal flusher is suitable for installation in dry U 2 urinal flush valve assembly instructions and brick-wall constructions. For dry-wall constructions, Note: This section provides instructions for the essential installation is performed together with the TECE urinal points of installation.
  • Page 21: Programming The U2 Urinal Electronics

    To program the TECEfilo urinal electronics, the program- ming key provided in the scope of delivery is required. The TECE electronics can be programmed during the first 30 minutes after connection to the power supply. In the event of a power failure, the last settings saved are retained.
  • Page 22 U 2 TECEfilo urinal flush valve How to program the TECE electronics: Adjustable functions: • Hold the programming key in front of the red diode (see Pause function/stadium function illustration). The programming mode starts with a quick When the pause function is activated, the flushing time is series of short beeps.
