- Page 1 INSTALLATION AND CARE GUIDE 30” VENTO VANITY E094130...
- Page 2 • Secure the 2x6 backing material to the studs with framing nails. • Rough-in the water supply and drain lines into the rough-in plumbing areas of the vanity. INSTALLATION SHEET ronbow.eu | ronbow.com 161018...
- Page 3 Figure 2. Step 4: Remove the drawer from the vanity. Refer to page 5 to remove and install the drawer. Slide the vanity over the wall brackets. Verify the vanity is level. See Figure 2. INSTALLATION SHEET ronbow.eu | ronbow.com 161018...
- Page 4 30” Vanity Model : E094130 Designed By: PININFARINA | ITALY Step 5: Figure 3. Secure the vanity to the wall bracket using the wood screws provided. Each bracket requires five wood screws. See Figure 3. INSTALLATION SHEET ronbow.eu | ronbow.com 161018...
- Page 5 Step 3: Install the faucet and drain per Figure 5. manufacturer’s instructions. Attach the drawer to the vanity by following the instructions on page 5. See Figure 5. INSTALLATION SHEET ronbow.eu | ronbow.com 161018...
- Page 6 Step 2: Figure 7. Slide and lift up the drawer box. See Figure 7. REINSTALL DRAWER Step 1: Figure 8. Slide drawer box in until secured by rail hook. See Figure 8. Hook https://youtu.be/4DdK3cj3sTU INSTALLATION SHEET ronbow.eu | ronbow.com 161018...
- Page 7 These variations are considered to be the nature of the material in relation to their environmental exposure and may be significant over a long period of time. The effectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture, household cleaners and/or amount of cleaning product used over time.
- Page 8 161018 40650 Encyclopedia Circle T 510.713.1188 Fremont, CA 94538 F 510.657.9388 ronbow.eu | ronbow.com...
