NEP BDM-300 Installation And Operation Manual
Microinverter
Hide thumbs
Also See for BDM-300:
- Quick installation manual (3 pages) ,
- Quick installation manual (2 pages)
Related Manuals for NEP BDM-300
Summary of Contents for NEP BDM-300
- Page 1 Installation and Operation Manual BDM-300/400 Microinverter Modified 04/13/2023 by JMB...
-
Page 2: Table Of Contents
4.4 Installation Procedure--------------------------------------------------------------------------------------------------------------- 9 4. 5 Install the AC Branch Circuit Junction Box------------------------------------------------------------------------------------10 4.6 Mounting------------------------------------------------------------------------------------------------------------------------------11 4.6.A Attach BDM-300/400 to the Racking--------------------------------------------------------------------------------- 11 4.6.B Attach BDM-300/400 to the Frame------------------------------------------------------------------------------------11 4.7 Connect the BDM-300/400 Wiring Harnesses------------------------------------------------------------------------------- 12 4.8 Ground the System----------------------------------------------------------------------------------------------------------------- 13 4.8A Through Trunk Cable-------------------------------------------------------------------------------------------------------13... - Page 3 8.1.C Error Mode (except for grounding error)-----------------------------------------------------------------------------20 8.1.B NOT communicating with BDG-256, and with no error-----------------------------------------------------------20 8.1.C Grounding Fault------------------------------------------------------------------------------------------------------------ 21 8.2 Troubleshooting An Inoperable BDM-300/400/400------------------------------------------------------------------------ 21 8.3 Disconnecting a BDM-300/400 from the PV Module-----------------------------------------------------------------------21 8.4 Installing a Replacement BDM-300/400---------------------------------------------------------------------------------------21 9. Data Sheets----------------------------------------------------------------------------------------------------------------------------------- 22 9.1 BDM-300------------------------------------------------------------------------------------------------------------------------------ 22 9.2 BDM-400------------------------------------------------------------------------------------------------------------------------------ 23...
-
Page 4: Company Profile
180W to 2000W, and industry leading Rapid Shutdown Devices (RSD). Our field deployment results have demonstrated the high efficiency and reliability of NEP solar inverters. At NEP, we are committed to developing Clean, Reliable, Affordable, and Efficient products for our customers worldwide. -
Page 5: Introduction
Thank you for your business, and please do not hesitate to contact us if you have any questions or concerns. 1.2 Standards Compliance The BDM-300/400 complies with the NEC 2014 and NEC 2017 article 690.12, and CEC 2015 section 64-218. 1.3 How to Use This Manual This manual provides detailed product information and installation instructions for the BDM-300/400. -
Page 6: Safety Instruction
2. SAFETY INSTRUCTION WARNING: PLEASE READ THIS MANUAL BEFORE INSTALLATION. ANY DAMAGE TO THE PRODUCT DUE TO NOT FOLLOWING THIS MANUAL IS NOT COVERED BY THE WARRANTEE. ALL THE INSTALLATION SHOULD BE DONE BY CERTIFIED ELECTRICIAN. IT IS IMPORTANT TO NOTE THAT NOTHING INSIDE THE PRODUCT SHOULD BE MODIFIED, ASIDE FROM THE CABLE CONNECTORS. -
Page 7: Fcc Compliance
3. FCC COMPLIANCE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Installation
Please contact NEP technical support should you need more information on this subject. 4.1 NEP Parts Needed In addition to the micro inverters, PV modules, racking, and associated hardware, you’ll need the BDM-300/400 installation kit. This kit includes the following items: ●... -
Page 9: Lightning Surge Suppression
The finished system should be similar as in the diagram. Detailed installation steps are listed in the following section. DC circuits of BDM-300/400 are isolated and insulated from ground. An integrated grounding protection circuit is included in the micro inverter. Modified 04/13/2023 by JMB... -
Page 10: Install The Ac Branch Circuit Junction Box
PV module junction box or any other obstructions. WARNING: ALLOW A MINIMUM OF .75 INCHES BETWEEN THE TOP OF THE ROOF AND THE BOTTOM OF BDM-300/400. WE ALSO RECOMMEND THAT YOU ALLOW .50 INCHES BETWEEN THE BACK OF THE PV MODULE AND THE TOP OF BDM-300/400. DO NOT MOUNT BDM-300/400 IN A LOCATION THAT ALLOWS LONG-TERM EXPOSURE TO DIRECT SUNLIGHT. -
Page 11: B Attach Bdm-300/400 To The Frame
Ensure that the microinverter is securely fastened and level. 4.6.B Attach BDM-300/400 to the Frame ● BDM-300/400 can be mounted on the frame of the PV modules. Please refer to the manual from the corresponding PC module manufactures that support BDM-300/400. 4.7 Connect the BDM-300/400 Wiring Harnesses ●... - Page 12 WARNING: DO NOT EXCEED THE MAXIMUM NUMBER OF BDM-300/400 IN AN AC BRANCH CIRCUIT, AS DISPLAYED ON THE UNIT-RATING LABEL. For 12AWG trunk cable, EACH BDM-300/400 AC BRANCH CIRCUIT MUST BE SOURCED FROM A DEDICATED BRANCH CIRCUIT PROTECTED BY A 20A MAXIMUM BREAKER.
-
Page 13: Ground The System
4.8A Through Trunk Cable ● Each BDM-300/400 has a built-in ground protection circuit. The grounding wire is connected through the trunk cable and should be securely attached to the ground connector in the junction box to ensure proper grounding of the microinverters. It is important to follow all local electrical codes and regulations. -
Page 14: Commissioning
5. Commissioning WARNING: CONNECT BDM-300/400 TO THE ELECTRICAL UTILITY GRID ONLY AFTER RECEIVING PRIOR APPROVAL FROM THE UTILITY COMPANY. WARNING: BE AWARE THAT ONLY QUALIFIED PERSONNEL CAN CONNECT BDM-300/400 TO THE ELECTRICAL UTILITY GRID. WARNING: ENSURE THAT ALL AC AND DC WIRING IS CORRECT. ENSURE THAT NONE OF THE AC AND DC WIRES IS PINCHED OR DAMAGED. -
Page 15: B Using Usb Barcode Scanner
● NEP offers a barcode scanner that can simplify the process of inputting serial numbers. To use the scanner, plug it into the gateway's USB port and navigate to the COM ID screen as in section 6.1.A. Scan the barcode of the desired module into the Inverter1 cell, and repeat until all serial numbers have been input. -
Page 16: Installer Registration
We recommend providing as much detail as possible to help us better understand your needs. ● Once you have registered, please contact NEP Support via email at support@northernep.com or by calling (888) 598-9901 to have your account upgraded to an installer account. This will allow you to access additional features and resources to help you better manage your NEP products. -
Page 17: Create A Site On Nep Website
5.6 Create a Site on NEP Website ● Access your installer account on the NEP website at https://user.nepviewer.com/pv_manager/login.php using your registered email and log in to your account. Then, click on the "Add Site" button to create a new site. -
Page 18: Verify And Map Site
5.7 Verify and Map Site ● Once you have confirmed the creation of the site on the NEP website, navigate to your dashboard where you should be able to see it. ● Click on the site to access its information and then click on "Open Viewer." The site's production data should now be visible on the first page. -
Page 19: Operating Instructions
6. Operating Instructions When DC voltage from the module is applied, the BDM-300/400 is powered on automatically. Once sufficient DC power is applied, the status LED will begin to flash, indicating that the BDM-300/400 is live. 6.1 Status: Standby ●... -
Page 20: Troubleshooting And Maintenance
WARNING: ALWAYS DISCONNECT AC POWER BEFORE DISCONNECTING PV MODULE WIRES FROM BDM-300/400/400. THE AC CONNECTOR OF THE FIRST BDM-300/400/400 IN A BRANCH CIRCUIT IS SUITABLE AS A DISCONNECTING MEANS ONCE THE AC BRANCH CIRCUIT BREAKER IN THE LOAD CENTER HAS BEEN OPENED. -
Page 21: Disconnecting A Bdm-300/400 From The Pv Module
Connect the positive DC wire from the PV module to the negatively marked DC connector (male pin) of the BDM-300/400. Then connect the negative DC wire from the PV module to the positively marked DC connector (female socket) of the BDM-300/400. Repeat for all remaining PV modules using one BDM-300/400 for each module. -
Page 22: Data Sheets
8. Data Sheets 8.1 BDM-300 Modified 04/13/2023 by JMB... -
Page 23: Bdm-400
8.2 BDM-400 Modified 04/13/2023 by JMB... -
Page 24: Warranty And Production Information
This warranty does not apply to and NEP will not be responsible for any defect in or damage to: a) the product if it has... -
Page 25: Disclaimer Product
PROFITS, LOST REVENUES, FAILURE TO REALIZE EXPECTED SAVINGS, OR OTHER COMMERCIAL OR ECONOMIC LOSSES OF ANY KIND, EVEN IF NEP HAS BEEN ADVISED, OR HAD REASON TO KNOW, OF THE POSSIBILITY OF SUCH DAMAGE, (b) ANY LIABILITY ARISING IN TORT, WHETHER OR NOT ARISING OUT OF NEP'S NEGLIGENCE, AND ALL LOSSES OR DAMAGES TO ANY PROPERTY OR FOR ANY...
