If the RQA-1B is set for KEYFOB operation with Call Clear capability
Quick Talk™ Input Keyfob Message
Input 1 RQT-KEYFOB-1
RQT-KEYFOB-2 used for Call Clear
Input 2 RQT-KEYFOB-3
RQT-KEYFOB-4 used for Call Clear
Input 3 RQT-KEYFOB-5
RQT-KEYFOB-6 used for Call Clear
Input 4 RQT-KEYFOB-7
RQT-KEYFOB-8 used for Call Clear
If the Quick Talk™ input is set for KEYFOB operation it no longer responds
to switch closures or analog signals, the two input messages can only be
activated by the RQA-1B or the two keyfobs associated with that input.
Refer to the RQT Quick Talk™ User Manual and RQT Keyfob Receiver User
Manual for complete programming instructions.
1. Connect the RQT radio to your computer via the USB port and using the
Ritron PC Programmer, read out the radio programming. If the model
indicated is not on the following list, your radio is not equipped with the
RQT-433-RCVR keyfob receiver and cannot be programmed for
KEYFOB operation.
Ritron RCVR Models with RQT-433-RCVR installed:
RQT-151-RCVR RQT-152-RCVR
RQT-152M-RCVR RQT-451-RCVR
2. Select the input(s) you would like to program for KEYFOB operation.
The input(s) you select will depend on the specific Ritron keyfobs or
RQA-1B button programming you use.
3. From the left column of the Input programming screen, set the Input
Type to Keyfob.
4. If Call Clear operation is required, select the Press and Hold Reset
option.
5. Press the Record button and record a unique message for the Ritron
keyfob / RQA-1B button programming indicated. Repeat the process if a
second keyfob / RQA-1B button is to be used.
_________________________________________________________________________________________________________________________________
RQT-151M-RCVR
RQT-452-RCVR
For assistance, call RITRON at 800-872-1872, or go to

Programmable RQT Radio Attributes

Latch On - When Latch On is selected, the RQT will ignore decoded signals from the
keyfob or RQA-1B until after the transmission schedule has been completed. If not
set, the RQT will transmit the recorded message every time it receives the correct
code.
EXAMPLE:
RQT-KEYFOB-1 is scheduled for 2 transmissions, 30 seconds between
transmissions. When RQT-KEYFOB-1 has been decoded the recorded message
will be transmitted twice with 30 seconds in between, and any additional signals
from RQT-KEYFOB-1 will be ignored until 30 seconds after the message is sent the
nd
2 time. Signals from other keyfobs will still be heard, only RQT-KEYFOB-1 will be
ignored.
Input Operation - can be set for 1 of 3 different modes:
Normal operation considers the RQT-KEYFOB code as it is received. If Press and
Hold Reset is selected the Input Operation is fixed in the Normal mode.
Dwell operation requires the keyfob code to be present continuously for a specified
period of time before considering. This is not a recommended mode of operation.
Holdoff operation considers the keyfob code as it is first received, but will ignore
additional signals from the keyfob for the programmed holdoff time.
EXAMPLE:
RQT-KEYFOB-2 set for 1 min. holdoff. When the RQT-KEYFOB-2 code is
received the recorded message will play. Any additional signals from RQT-
KEYFOB-2 will be ignored until after 1 minute has elapsed.
Number of Message Transmissions specifies the number of times a recorded
message will be transmitted after an RQT-KEYFOB code has been received.
Time between Transmissions specifies the length of time between scheduled
transmissions. If it is set to "No Message", the recoded message will not play. If it is
set to "On Changes Only", the recorded message will only play when the keyfob code
is decoded.
Play Message on each Transmission specifies the number of times the recorded
message will be repeated on each transmission.
EXAMPLE:
RQT-KEYFOB-1 is scheduled for 2 transmissions, 30 seconds between
transmissions, 2 messages per transmission. When RQT-KEYFOB-1 has been
decoded the recorded message will be transmitted twice, wait 30 seconds, then the
message is transmitted twice again.
