WORKSHOP MANUAL
TRACTOR
L3008,L3608
KiSC issued 06, 2009 A

Advertisement

Table of Contents
loading

Related Manuals for Kubota L3008

Summary of Contents for Kubota L3008

  • Page 1 WORKSHOP MANUAL TRACTOR L3008,L3608 KiSC issued 06, 2009 A...
  • Page 2 TO THE READER This Workshop Manual tells the servicing personnel about the mechanism, servicing and maintenance of the L3008 and L3608. It contains 4 parts: "Information", "General", "Mechanism" and "Servicing". Information This section contains information below. • Safety First • Safety Label •...
  • Page 3 INFORMATION KiSC issued 06, 2009 A Find manuals at https://best-manuals.com...

  • Page 4: Table Of Contents

    INFORMATION CONTENTS 1. SAFETY FIRST ..........................I-1 2. SAFETY DECALS .......................... I-4 3. SPECIFICATIONS.......................... I-6 4. TRAVELING SPEEDS........................I-7 5. DIMENSIONS ..........................I-8 KiSC issued 06, 2009 A Find manuals at https://best-manuals.com...

  • Page 5: Safety First

    INFORMATION L3008,L3608, WSM 1. SAFETY FIRST SAFETY FIRST • This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully.
  • Page 6 INFORMATION L3008,L3608, WSM OPERATE SAFELY • Do not use the machine after you consume alcohol or medication or when you are tired. • Put on applicable clothing and safety equipment. • Use applicable tools only. Do not use alternative tools or parts.
  • Page 7 INFORMATION L3008,L3608, WSM KEEP A GOOD AIRFLOW IN THE WORK AREA • If the engine is in operation, make sure that the area has good airflow. Do not operate the engine in a closed area. The exhaust gas contains poisonous carbon monoxide.

  • Page 8: Safety Decals

    INFORMATION L3008,L3608, WSM 2. SAFETY DECALS The following safety decals (pictorial safety labels) are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list.
  • Page 9 INFORMATION L3008,L3608, WSM 9Y1210284INI0002US0 (TH) KiSC issued 06, 2009 A Find manuals at https://best-manuals.com...

  • Page 10: Specifications

    INFORMATION L3008,L3608, WSM 3. SPECIFICATIONS L3008 L3608 Model PTO power* 19.5 kW (26.5 PS) 23.2 kW (31.5 PS) Maker KUBOTA Model D1503-M-DI D1703-M-DI Type Direct injection, Vertical, Water-Cooled 4 cycle diesel Number of cylinder Bore and stroke 83 x 92.4 mm (3.3 x 3.6 in.) 87 x 92.4 mm (3.4 x 3.6 in.)

  • Page 11: Traveling Speeds

    INFORMATION L3008,L3608, WSM 4. TRAVELING SPEEDS Manual Transmission Type (At rated engine rpm) Model L3008 L3608 Shuttle shift Range gear Main gear shift km/h (mph) km/h (mph) lever shift lever lever 1.7 (1.1) 1.8 (1.1) 2.3 (1.4) 2.4 (1.5) 4.3 (2.7) 4.6 (2.9)

  • Page 12: Dimensions

    INFORMATION L3008,L3608, WSM 5. DIMENSIONS 9Y1210284INI0005US0 (TH) KiSC issued 06, 2009 A...
  • Page 13 GENERAL KiSC issued 06, 2009 A...
  • Page 14 GENERAL CONTENTS 1. TRACTOR IDENTIFICATION....................... G-1 [1] MODEL NAME AND SERIAL NUMBERS ................G-1 [2] E2 ENGINE ..........................G-3 [3] CYLINDER NUMBER ......................G-3 2. GENERAL PRECAUTIONS......................G-4 3. HANDING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING ........G-5 [1] WIRING ..........................G-5 [2] BATTERY ..........................

  • Page 15: Tractor Identification

    GENERAL L3008,L3608, WSM 1. TRACTOR IDENTIFICATION [1] MODEL NAME AND SERIAL NUMBERS When contacting your local KUBOTA distributor, always specify engine serial number, tractor serial number and hour meter reading. (1) Tractor Identification Plate (2) Tractor Serial Number 9Y1210284GEG0001US0 (TH)
  • Page 16 GENERAL L3008,L3608, WSM Engine Serial Number When contacting the manufacture, always specify your engine model number and serial number. The engine model and its serial number need to be identified before the engine can be serviced or parts replaced. Engine Serial Number The engine serial number is an identified number for the engine.

  • Page 17: E2 Engine

    The time to enforce the regulations differs depending on the engine output classifications. KUBOTA has been supplying the diesel engines conforming to the emission regulations in respective countries. exhaust emissions regulations shift to the second stage. KUBOTA executed the improvement of the engine according to this regulation.

  • Page 18: General Precautions

    Screws, bolts and nuts should be installed in their original position to prevent reassembly errors. • When special tools are required, use KUBOTA genuine special tools. Special tools which are not frequently used should be made according to the drawings provided.

  • Page 19: Handing Precautions For Electrical Parts And Wiring

    GENERAL L3008,L3608, WSM 3. HANDING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING To ensure safety and prevent damage to the machine and surrounding equipment, heed the following precautions in handling electrical parts and wiring. IMPORTANT • Check electrical wiring for damage and loosened connection every year.
  • Page 20 GENERAL L3008,L3608, WSM • Securely clamp, being careful not to damage wiring. (1) Clamp (3) Clamp (Wind Clamp Spirally) (4) Welding Dent (2) Wire Harness WSM000001GEG0067US0 • Clamp wiring so that there is no twist, unnecessary sag, or excessive tension, except for movable part, where sag be required.

  • Page 21: Battery

    GENERAL L3008,L3608, WSM [2] BATTERY • Take care not to confuse positive and negative terminal posts. • When removing battery cables, disconnect negative cable first. When installing battery cables, check for polarity and connect positive cable first. • Do not install any battery with capacity other than is specified (Ah).

  • Page 22: Handling Of Circuit Tester

    GENERAL L3008,L3608, WSM • Use sandpaper to remove rust from terminals. • Repair deformed terminal. Make certain there is no terminal being exposed or displaced. (1) Exposed Terminal (3) Sandpaper (2) Deformed Terminal (4) Rust WSM000001GEG0075US0 • Make certain that there is no female connector being too open.

  • Page 23: Color Of Wiring

    GENERAL L3008,L3608, WSM [6] COLOR OF WIRING • Colors of wire are specified to the color codes. • This symbol of "/" shows color with stripe(s). (An example) Red stripe on white color : W/R Color of wiring Color code...

  • Page 24: Lubricants, Fuel And Coolant

    Multipurpose grease Until grease overflows NLGI-2 or NLGI-1 Lift rod (GC-LB) Tie-rod ends Steering joint Range gear shift lever Synchro-shuttle shift lever Hydraulic arm shaft NOTE • * KUBOTA original transmission hydraulic fluid. 9Y1210284GEG0005US0 G-10 (TH) KiSC issued 06, 2009 A...
  • Page 25 • The oil used to lubricate the transmission is also used as hydraulic fluid. To insure proper operation of the hydraulic system and to complete lubrication of the transmission, it is important that a multi-grade transmission fluid is used in this system. We recommend the use of KUBOTA UDT or SUPER UDT fluid for optimum protection and performance.

  • Page 26: Tightening Torques

    GENERAL L3008,L3608, WSM 5. TIGHTENING TORQUES [1] GENERAL USE SCREWS, BOLTS AND NUTS Screws, bolts and nuts whose tightening torques are not specified in this Workshop Manual should be tightened according to the table below. Indication on top of bolt...

  • Page 27: Metric Screws, Bolts And Nuts

    GENERAL L3008,L3608, WSM [3] METRIC SCREWS, BOLTS AND NUTS Grade Property class 8.8 Property class 10.9 Unit N·m kgf·m lbf·ft N·m kgf·m lbf·ft 24 to 27 2.4 to 2.8 18 to 20 30 to 34 3.0 to 3.5 22 to 25 48 to 55 4.9 to 5.7...

  • Page 28: Maintenance

    GENERAL L3008,L3608, WSM 6. MAINTENANCE Service Interval Refer- After Item ence since 50 100 150 200 250 300 350 400 450 500 550 600 650 700 page 1 Greasing – every 20 Hr G-20 every 50 2 Engine start system...
  • Page 29 GENERAL L3008,L3608, WSM IMPORTANT • The jobs indicated by must be done after the first 50 hours of operation. • *1 : Air cleaner should be cleaned more often in dusty conditions than in normal conditions. *2 : Every year or every 6 times of cleaning.

  • Page 30: Check And Maintenance

    GENERAL L3008,L3608, WSM 7. CHECK AND MAINTENANCE CAUTION • Be sure to check and service the tractor on a level surface with engine shut off and the parking brake "ON" and implement lowered to ground. 9Y1210284GEG0008US0 [1] DAILY CHECK To prevent trouble from occurring, it is important to know the condition of the tractor. Check the following items before starting.
  • Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
