1 - Draw around template & cut hole
3 - Pinch clips & remove Quik-Link terminal
5 - Connect Quik-Link terminal to speaker
7 - Tighten Tri-Grip II screws
Tri-Grip x 6 = 5Kgf/cm; 4.34 lbf/inch; 0.5 NM
2 - Run cabling to cut-out hole
4 - Connect cable to Quik-Link terminal
6 - Guide speaker into cut-out hole
8 - Attach grille
PZ2 driver head
