Board Demo - NEX ROBOTICS LPC2148 Pro Manual

LPC2148 DEVELOPMENT BOARD
" Nex Robotics PVT LTD
ARM7LPC214x Development Board
Communication Test
Send any character to continue"
As instructed in the last line of the above message, please type any character in transmit
window of terminal software. This character is received by the development board via Xbee
module present on board. The development board will reply by sending the message as "Test
Passed" to the terminal software running on PC. This message can be observed in receive
window of terminal software.

4.14 BOARD DEMO

Hardware Setup:
Fig. 4.1
1. Insert jumpers as highlighted in fig. 4.1
2. Insert any SD/MMC card of size up to 2GB in the SD/MMC slot.
3. Load hex file using flash magic and follow the instructions on LCD display.
Load the BOARD_DEMO.hex file from LPC2148>codes>BOARD DEMO folder using flash
magic on the microcontroller flash memory.
Description: The Demo program is used to test all the peripherals on the development board.
After loading the hex file refer instructions on the LCD display.
NEX Robotics Pvt. Ltd. 56
www.nex-robotics.com
