NEX ROBOTICS LPC2148 Pro Manual page 5

Specifications:
Microcontroller: LPC2148 with
•
512K on chip memory
Crystal for LPC2148: 12Mhz
•
Crystal for RTC: 32.768KHz
•
50 pin Berg header for external
•
interfacing
Wireless module adapter for
•
2.4GHz ZigBee (Xbee) /
Bluetooth / WiFi connectivity
512 bytes of I2C external
•
EEPROM
USB Type B Connector
•
SD / MMC card holder
•
10pin(2X5) FRC JTAG connector
•
for flashing and debugging
50 Pin Expansion header
•
2x16 Character Alphanumeric
•
LCD
Kit Contains:
1-LPC2148 Pro Development Board
1-USB Cable
1-DB9 Serial Cable
A set of 10 1-1 cables
Documentation CD contains:
I. Schematic
II. Programming Software
III. Example Codes
LPC2148 Features:
16-bit/32-bit ARM7TDMI-S microcontroller in a tiny LQFP64 package.
•
40 kB of on-chip static RAM and 512 kB of on-chip flash memory.
•
In-System Programming/In-Application Programming (ISP/IAP) via on-chip boot
•
loader software.
Embedded ICE RT and Embedded Trace interfaces offer real-time debugging with the
•
on-chip Real Monitor software and high-speed tracing of instruction execution.
USB 2.0 Full-speed compliant device controller with 2 kB of endpoint RAM.
•
Two 10-bit ADCs provide a total of 14 analog inputs
•
Single 10-bit DAC provides variable analog output
•
Two 32-bit timers/external event counters (with four capture and four compare
•
channels each), PWM unit (six outputs) and watchdog.
Low power Real-Time Clock (RTC) with independent power and 32 kHz clock input.
•
NEX Robotics Pvt. Ltd.
www.nex-robotics.com
LPC2148 DEVELOPMENT BOARD
L293D 600mA Dual DC motor
•
Driver
ULN2003 500mA driver
•
Dual RS232 UARTs for external
•
communication
Real-Time Clock with Battery
•
Holder
2 Analog Potentiometers connected
•
to ADC
TSOP1738 IR receiver
•
4 USER Switches
•
4 USER LEDs
•
Reset and Boot loader switches
•
3V button cell for on chip RTC
•
ON/OFF switch
•
Buzzer
•
Schematics and Application
•
examples in KEIL provided in the
documentation CD
