MDM Sequence Alpha Primer 5000PRM18 Installation And Service Manual

Model 3200PRM15
INLET 2"
DISCHARGE 2"
MAX FLOW (GPH) 3200
MAX HEAD (FEET) 15
MAX POWER (WATTS) 228
MAX CURRENT (AMPS) 2.68 @120V
VOLTS 120
MOTOR HP 1/2, 1/3
MOTOR TYPE 56Y
MOTOR ENCLOSURE TEFC
Read this manual completely before you install or operate your new pump. This is an external "out-of-pond" pump.
PROUDLY MADE
IN THE USA
INSTALLATION AND SERVICE MANUAL
5000PRM18
2"
2"
5000
18
310
3.27 @120V
120
1/2, 1/3
56Y
TEFC
It is not submersible. Do not allow this pump to become submerged. Never run dry.
Reliable. Efficient.
ALPHA PRIMER
®
HORSEPOWER: 1/3, 1/2 (1750 RPM), 2
®
XXXXPRMXX
S/N: XXXX-XXXXXX
6800PRM19
2"
2"
6800
19'
369
3.93 @115V
115/230
1/2, 1/3
56Y
TEFC
FILL IN FOR FUTURE REFERENCE:
MODEL: ______________________________
SERIAL NUMBER: _______________________
DATE PURCHASED: ______________________
COMPLETE AND MAIL YOUR WARRANTY REGISTRATION
CARD INCLUDED WITH THIS PRODUCT OR FILE ONLINE AT:
WWW.MDMINC.COM/PUMP-REGISTRATION
TYPE: STRAIGHT CENTRIFUGAL
MOTOR: NEMA 56Y
INLET: 2" FNPT WITH 2" SLIP ADAPTERS
DISCHARGE: 2" & 2 1/2" SLIP ADAPTERS
MATERIAL: GLASS-FILLED POLYPROPYLENE
HARDWARE: STAINLESS STEEL
OPTIONS: SALTWATER SERVICE
ACCESSORIES: SWING CHECK VALVES (1.5", 2", 3")
*MOTORS ARE SUBJECT TO CHANGE DUE TO
AVAILABILITY OR SPECIFICATION REQUIREMENTS.
7800PRM24 6000PRM60 (HIGH-SPEED)
2" 2"
2" 2"
7800 6000
24' 60'
504 1418
5.02 @115V 8.74 @230V
115/230 230
1/2, 1/3 2
56Y 56Y
TEFC ODP
© MDM INCORPORATED
WWW.MDMINC.COM
P.1
