MDM Sequence 750 Installation And Service Manual

Model
INLET
DISCHARGE
MAX FLOW (GPH)
MAX HEAD (FEET)
MAX POWER (WATTS)
MAX CURRENT (AMPS)
@(VOLTS)
MOTOR HP
MOTOR ENCLOSURE
IMPELLER
Read this manual completely before you install or operate your new pump. This is an external "out-of-pond" pump.
It is not submersible. Do not allow this pump to become submerged. Never run dry. Maximum case pressure - 25 PSI.
PROUDLY MADE
IN THE USA
INSTALLATION AND SERVICE MANUAL
3600SEQ12
2"
1.5"
3600
12'
142
1.25
115
1/8
TEFC
8
Reliable. Efficient.
750
®
®
XXXXSEQXX
S/N: XXXX-
XXXXXX
FILL IN FOR FUTURE REFERENCE:
MODEL: ______________________________
SERIAL NUMBER: _______________________
DATE PURCHASED: ______________________
COMPLETE AND MAIL YOUR WARRANTY REGISTRATION
CARD INCLUDED WITH THIS PRODUCT OR FILE ONLINE AT:
WWW.MDMINC.COM/PUMP-REGISTRATION
TYPE: STRAIGHT CENTRIFUGAL
MOTOR: INDUSTRIAL DUTY 1/8 HP, 1 PHASE, TEFC
1725 RPM (@60HZ), 115 VAC MOTOR
8 FT 3-PRONGED CORD
INLET: 2" FNPT
DISCHARGE: 1-1/2" FNPT
MATERIAL: 40% GLASS-FILLED POLYPROPYLENE
WITH NORYL IMPELLER
®
HARDWARE: STAINLESS STEEL
OPTIONS: SALTWATER SERVICE
ACCESSORIES: 90 CUBIC INCH STRAINER BASKETS (1.5" & 2")
500 CUBIC INCH STRAINER BASKET (2")
SWING CHECK VALVES (1.5", 2", 3")
*MOTORS ARE SUBJECT TO CHANGE DUE TO
AVAILABILITY OR SPECIFICATION REQUIREMENTS.
4200SEQ12
2"
1.5"
4200
12'
154
1.39
115
1/8
TEFC
9
© MDM INCORPORATED
WWW.MDMINC.COM
P.1
