MDM Sequence TITAN Installation And Service Manual

Model
INLET
DISCHARGE
MAX FLOW (GPH)
MAX HEAD (FEET)
MAX POWER (WATTS)
MAX CURRENT (AMPS @ 115 VOLTS)
MAX CURRENT (AMPS @ 230 VOLTS)
PHASE
MOTOR HP
MOTOR ENCLOSURE
Read completely before you install or operate your new pump. Do not allow the motor to become submerged.
Never run dry. Never reverse rotation. Never exceed an internal case pressure of: 100 PSI.
PROUDLY MADE
IN THE USA
INSTALLATION AND SERVICE MANUAL
XXXXXXXXX
S/N: XXXX-XXXXXX
12000SEQ21
3"
2"
12,500
21'
845
9.6
6
SINGLE
3/4
TEFC
Reliable. Efficient.
TITAN
®
FILL IN FOR FUTURE REFERENCE:
MODEL: ________________________________________
SERIAL NUMBER: _________________________________
DATE PURCHASED: ________________________________
COMPLETE AND MAIL YOUR WARRANTY REGISTRATION CARD INCLUDED WITH
THIS PRODUCT OR FILE ONLINE AT: WWW.MDMINC.COM/PUMP-REGISTRATION
TYPE: END-SUCTION CENTRIFUGAL
MOTOR: NEMA 143JM-215JM
PORT SIZE: 3" FLANGED INLET, 2" FLANGED DISCHARGE
HORSEPOWER: 3/4 HP, 3 HP
MATERIAL: PHENOLIC RESIN BRACKET AND VOLUTE, NORYL
HARDWARE: STAINLESS STEEL
SEAL OPTIONS: IMPENATRA
®
CARBON GRAPHITE/VITON/SILICON CARBIDE
SILICON CARBIDE/VITON/SILICON CARBIDE, ETC.
OTHER OPTIONS: EXTENSION COUPLED, PEDESTAL MOUNTED AND LONG-COUPLED
WITH PEDESTAL MOUNTED PUMP ON POLYMER BASEPLATE
PUMP ENDS INSERT: AND SEAL FLUSH PLANS AVAILABLE
ACCESSORIES: 500 CUBIC INCH BASKET STRAINER
*MOTORS ARE SUBJECT TO CHANGE DUE TO
AVAILABILITY OR SPECIFICATION REQUIREMENTS.
18000SEQ45
3"
2"
18,400
45'
2110
27.1
10.8
SINGLE
3
TEFC
®
II NON-METALIC MECHANICAL SEAL:
®
