Summary of Contents for Mitsubishi MELSEC-GOT F940

  • Page 1 HARDWARE MANUAL F940GOT-SWD-E/LWD-E [Connection System Manual] JY992D79201A(MEE9903)
  • Page 2 F940GOT-SWD-E/LWD-E F940GOT-SWD-E/LWD-E F940GOT-SWD-E/LWD-E Manual number : JY992D79201 HARDWARE MANUAL Manual revision : Date March 1999 (Connection System Manual)
  • Page 3 F940GOT-SWD-E/LWD-E Guidelines for the safety of the user and protection of the F940GOT-SWD-E/LWD-E This manual provides information for the installation and use of the Graphic Operation Terminal F940GOT. The manual has been written to be used by trained and competent personnel. The definition of such a person or persons is as follows;...
  • Page 4 F940GOT-SWD-E/LWD-E Note’s on the symbology used in this manual At various times through out this manual certain symbols will be used to highlight points of information which are intended to ensure the users personal safety and protect the integrity of the equipment. Whenever any of the following symbols are encountered, its associated note must be read and understood.
  • Page 5 F940GOT-SWD-E/LWD-E MEMO...
  • Page 6: Table Of Contents

    F940GOT-SWD-E/LWD-E Table of Contents 1. System configuration................1-1 When the GOT is directly connected to the PLC ..........1-1 When built-in two-port interface function is used ..........1-3 2. Connection to personal computer ............2-1 Pin assignment and connection diagram of transfer cables ......2-2 3.
  • Page 7 F940GOT-SWD-E/LWD-E...
  • Page 8: System Configuration

    F940GOT-SWD-E/LWD-E System configuration 1. System configuration The system configuration to use the GOT is described below. When the GOT is directly connected to the PLC (When the GOT is connected via a computer link unit, refer to Section 2.) Data transfer cable FX-232CAB-1 (when the RS-232C connector in the personal F940GOT-SWD-E/LWD-E computer is 9-pin type) or Data transfer cable FX-232CAB-2 (when the RS-232C connector in the personal computer is half-pitch,14-pin type)
  • Page 9 F940GOT-SWD-E/LWD-E System configuration 1. Peripheral units for GOT General-purpose personal computer (screen creation software) Screen creation software for DU Data transfer cable F2-232CAB-1 FX-PCS-DU/WIN-E (V2.10 or later) (when the RS-232C connector in the Screen creation software for A900GOT personal computer is 25-pin type) D5C-GOTRE-PACK Connected to RS-232C connector in GOT ("...
  • Page 10: When Built-In Two-Port Interface Function Is Used

    F940GOT-SWD-E/LWD-E System configuration 1. The figure below shows connection to peripheral units used to create sequence programs. When built-in two-port interface function is used F940GOT-SWD-E/LWD-E When the two-port interface function is used, the operation environment should be set. (Refer to the description on "SERIAL PORT" on the SET-UP MODE screen.) Data transfer cable FX-232CAB-1 (when the RS-232C connector in the personal computer is 9-pin type) Data transfer cable F2-232CAB-2...
  • Page 11 F940GOT-SWD-E/LWD-E System configuration 1. Peripheral unit to create sequence programs General-purpose personal computer * A general-purpose computer can be directly connected, and both the GOT and the personal computer can be used at the same time (without using the FX-2PIF). When the two-port interface function is used using the software package SW D5C(F)-GPPW-E, make sure to use the...
  • Page 12 F940GOT-SWD-E/LWD-E System configuration 1. When the two-port interface FX-2PIF is used F940GOT-SWD-E/LWD-E Two-port interface Connection cable FX-40DU-CAB/EN FX-2PIF Program cable FX-20P-CAB Data transfer cable AC30R4 Data transfer cable FX-422CAB or Data transfer cable FX-422CAB-150 Data transfer cable FX-422CAB0 FX/FX / Series A Series (except QnA) Series...
  • Page 13 F940GOT-SWD-E/LWD-E System configuration 1. Peripheral unit to create sequence programs Handy programming panel FX-10P-E/20P-E (A Series cannot be used.) A7PHP/A7HGP A6GPP/A6PHP The FX Series can be used in the instruction/device range of the FX Series. Note: The two-port interface FX-2PIF is available in CPU port connection (via the RS-422). This interface is not available in computer link connection (via the RS-422 or the RS-232C) and CPU port connection (via the RS-232C).
  • Page 14: Connection To Personal Computer

    F940GOT-SWD-E/LWD-E Connection to personal computer 2. Connection to personal computer Use the following cable to connect a personal computer. a) F940GOT b) Personal computer c) FX-232CAB-1, FX-232CAB-2 or F2-232CAB-1...
  • Page 15: Pin Assignment And Connection Diagram Of Transfer Cables

    F940GOT-SWD-E/LWD-E Connection to personal computer 2. Pin assignment and connection diagram of transfer cables - Transfer cable FX-232CAB-1 D-sub Personal D-sub (female) computer GOT side (female) 9-pin side 9-pin - Transfer cable FX-232CAB-2 Half Personal D-sub pitch computer GOT side (female) 9-pin side...
  • Page 16 F940GOT-SWD-E/LWD-E Connection to personal computer 2. - Transfer cable F2-232CAB-1 D-sub Personal D-sub (male) computer (female) side 25-pin side 9-pin...
  • Page 17 F940GOT-SWD-E/LWD-E Connection to personal computer 2. MEMO...
  • Page 18: Cpu Port Connection

    F940GOT-SWD-E/LWD-E CPU port connection 3. CPU port connection Use either of the following cables to connect the PLC directly. Connection to FX/A Series 1) When connecting the FX/FX /A Series 2) When connecting the FX Series e), g) * When the screen mode is selected while a cable is not connected, a communication error occurs.
  • Page 19 F940GOT-SWD-E/LWD-E CPU port connection 3. a) F940GOT b) FX-40DU-CAB, FX-40DU-CAB-10M or FX-50DU-CABL c) FX-50DU-CAB0, FX-50DU-CAB0-1M, FX-50DU-CAB0-10M, FX-50DU-CAB0-20M, FX-50DU-CAB0-30M or FX-50DU-CAB0L d) FX/FX Series PLC e) A Series PLC AnN, AnA, AnS, AnSJ, AnSH, A1SJH, A2C, A2CJ, A0J2H, AnU, AnUS, A2USH or A1FX f) FX Series PLC g) Motion controller...
  • Page 20: Connection Diagram

    F940GOT-SWD-E/LWD-E CPU port connection 3. Connection diagram Pin assignment and connection diagram of connection cables (The connection cables are offered as options.) - Connection cable FX-40DU-CAB (L, -10M) or FX-50DU-CABL D-sub D-sub (male) (male) side side 25-pin 25-pin - Connection cable FX-50DU-CAB0 (L, -1M, -10M, -20M, -30M) MINI-DIN D-sub (male)
  • Page 21: Connection Of Two Or More Got Units

    F940GOT-SWD-E/LWD-E CPU port connection 3. Connection of two or more GOT units • When the CPU in the FX/A Series PLC is directly connected, up to four GOT units can be connected to one PLC (1-to-N connection). As the connection type, select "CPU PORT (RS232C)" or "CPU PORT (RS422)" in "CON- NECTION"...
  • Page 22 F940GOT-SWD-E/LWD-E CPU port connection 3. Connection cable examples: Connection diagram 1st GOT: FX-50DU-CAB0 (equivalent to connection cable for PLC) 2nd GOT: FX-232CAB-1 3rd GOT: Cable created by user (Refer to the connection diagram.) 4th GOT: FX-232CAB-1 Communication speed: The communication speed with the PLC becomes slower as the number of connected GOT units becomes larger.
  • Page 23 F940GOT-SWD-E/LWD-E CPU port connection 3. • In the case of the FX Series, communication can be performed by CPU port connection (RS-232C communication) using the FX -232-BD. In this case also, In the case of the FX Series, communication can be performed by CPU port connection (RS-232C communication) using the FX -232-BD.
  • Page 24 F940GOT-SWD-E/LWD-E CPU port connection 3. Connection cable examples: Connection diagram 1st GOT: FX-232CAB-1 2nd GOT: Cable created by user (Refer to the connection diagram.) 3rd GOT: FX-232CAB-1 4th GOT: Cable created by user (Refer to the connection diagram.) Communication speed: The communication speed with the PLC becomes slower as the number of connected GOT units becomes larger.
  • Page 25 F940GOT-SWD-E/LWD-E CPU port connection 3. MEMO...
  • Page 26: Computer Link Port Connection (Melsec A Series)

    F940GOT-SWD-E/LWD-E Computer link port connection (MELSEC A Series) 4. Computer link port connection (MELSEC A Series) The GOT can be connected to the MELSEC A Series via a computer link unit as shown below. • Applicable PLC units and computer link units <...
  • Page 27: Connection Diagram

    F940GOT-SWD-E/LWD-E Computer link port connection (MELSEC A Series) 4. Connection diagram • Connect the GOT to the computer link unit (PLC) as shown below. < For RS-422 communication > Computer link D-sub Terminal unit side (male) block side (PLC side) 9-pin <...
  • Page 28 F940GOT-SWD-E/LWD-E Computer link port connection (MELSEC A Series) 4. < For RS-232C communication > Computer link D-sub D-sub unit side (female) 9-pin side (PLC side) 9-pin...
  • Page 29 F940GOT-SWD-E/LWD-E Computer link port connection (MELSEC A Series) 4. MEMO...
  • Page 30: Connection To Sysmac C Series

    F940GOT-SWD-E/LWD-E Connection to SYSMAC C Series 5. Connection to SYSMAC C Series The GOT can be connected to the SYSMAC C Series manufactured by OMRON via a host link unit as shown below. • Applicable PLC units and host link units <...
  • Page 31: Connection Diagram

    F940GOT-SWD-E/LWD-E Connection to SYSMAC C Series 5. Connection diagram • Connect the GOT to the host link unit (SYSMAC C Series) as shown below. For connection of a model not shown in the examples below, refer to the manual of the C Series link unit.
  • Page 32 F940GOT-SWD-E/LWD-E Connection to SYSMAC C Series 5. < For RS-232C communication > Example of connection to CQM1 (in which RS-232C port is built in) D-sub D-sub COM1 (female) 9-pin side side 9-pin...
  • Page 33 F940GOT-SWD-E/LWD-E Connection to SYSMAC C Series 5. MEMO...
  • Page 34: Connection To Flex-Pc N Series

    F940GOT-SED-E/LWD-E Connection to FLEX-PC N Series 6. Connection to FLEX-PC N Series The GOT can be connected to the FLEX-PC N Series manufactured by FUJI Electric via a link unit shown below. • Connection type Link port connection (RS-422) Select the connection type using Link port connection (RS-232C) the operation environment setting CPU port connection (RS-232C)
  • Page 35: Connection Diagram

    F940GOT-SED-E/LWD-E Connection to FLEX-PC N Series 6. • Link unit - NB Series NB-RS1-AC, NB-RS1-DC - NJ Series NJ-RS2, NJ-RS4 - NS Series NS-RS1 - CPU in which RS-232C interface is built in NJ-CPU-B16 Connection diagram Connect the GOT and the link unit (PLC) as shown below. <...
  • Page 36 F940GOT-SED-E/LWD-E Connection to FLEX-PC N Series 6. < For link port connection (RS-232C) > D-sub D-sub Link unit side (female) 25-pin (PLC side) side 9-pin < For connection of built-in RS-232C interface > D-sub D-sub PLC side (female) 15-pin side 9-pin...
  • Page 37 F940GOT-SED-E/LWD-E Connection to FLEX-PC N Series 6. MEMO...
  • Page 38: Connection By General-Purpose Communication

    F940GOT-SWD-E/LWD-E Connection by general-purpose communication 7. Connection by general-purpose communication The GOT can be connected to a general controller such as micro computer board. (The connected controller is hereafter referred to as "host (unit)".) Outline In genera-purpose communication, the host unit is connected to the GOT via the RS-232C and functions as the parent station in communication.
  • Page 39 F940GOT-SWD-E/LWD-E Connection by general-purpose communication 7. Accordingly, to display the data stored in the host unit on the screen, the host unit should transfer the data to the data area inside the GOT using write commands. The transfer des- tination is a location specified by the screen data. The data change result by manipulation of keys can be transferred from the data area inside the GOT to the host unit if the host unit gives read commands.
  • Page 40: Connection Diagram

    F940GOT-SWD-E/LWD-E Connection by general-purpose communication 7. Connection diagram Connect the GOT and the host unit as shown below. D-sub Host side (male) side 9-pin * The control lines RTS, CTS, DTR and DSR are not used.
  • Page 41: Communication Setting

    F940GOT-SWD-E/LWD-E Connection by general-purpose communication 7. Communication setting The setting related to communication can be performed using the screen creation software or the GOT main body. To use general-purpose communication, - Screen creation software: Set the connected personal computer to "General-Purpose Communication".
