1.3.

LEAD PAINT WARNING!

1.3.1. Paint once contained lead as a traditional ingredient. Contact with the dust from the removal of such paint is toxic and must therefore
be avoided. The following action must be taken before using the sander on a surface that you suspect may contain lead paint.
1.3.2. User must determine potential hazard relating to age of paint to be removed (modern paints do not have lead content).
▲ DANGER! Keep all persons and pets away from the work area.
1.3.3. We recommend personal protection by using the following safety items:
Paint Spray Respirator (Our ref SSP16EN)
PE Coated Hooded Coverall (Our ref SSP266).
Latex Gloves (Our ref SSP24).
1.3.4. Take adequate measures to contain the paint dust, flakes and scrapings.
Continue to wear safety equipment as in 1.3.3. above and thoroughly clean all areas when task is complete. Ensure paint waste is
disposed of, in sealed bags or containers, according to local regulations.

2. INTRODUCTION

For all types of curved sanding both in deep and wide work pieces. All sanding parts and accessories have allocated slots in the
housing for storage. A vacuum hose can be attached to the back of the spindle for dust extraction. Includes six sanding sleeves,
five bobbin drums and six table inserts. Bobbin sizes range from 13-76mm. No-load speed 2000rpm. Supplied with a 2m mains
cable.

3. SPECIFICATION

Model No: ..................................................................SM1200
Belt Size(s): ...............................Sizes: 13/19/26/38/51/76mm
Bobbins Included:............................................................. Yes
External Diameter: ...................................................... 38mm
Motor Power: .................................................................450W
No-Load Speed: ....................................................... 2000rpm
Oscillations: ................................................................. 58/min
Supply: ..........................................................230v (AC) 50Hz
Spindle Height: ........................................................... 115mm
Table Size: ........................................................370 x 290mm
Table Tilt: ........................................................................... No

4. CONTENTS

fig.1
Sanding
Sleeves

5. PREPARATION

NOTE: Disconnect from power supply before carrying out repairs or maintenance.
5.1.

TOOL HOLDERS

The sander comes supplied with two sets of holders, one for the sanding sleeves and rubber drums when not in use, the other for
the table inserts. There is also a space for the spindle spanner (supplied) to fit into (fig.2).
5.2. SAFETY ON/OFF SWITCH (fig.1)
This machine is fitted with a safety on/off switch. In the event of a power outage, the machine will require manually restarting
once power has been returned. To switch the machine on, press the green button marked 'I'.To switch the machine off, press the red
button marked 'O'. (NOTE: after a power disruption you will have to reset the sander by simply turning off then on again as the green
button will remain in but not operate the machine).
5.3. DUST EXTRACTION (fig.2)
5.3.1. Ingestion of dust particles can be detrimental to health. The dust outlet is required to be connected to a dust extraction machine.
NOTE: The outlet diameter connection may vary on the extraction machine so a size adaptation may be necessary.
5.3.2. All forms of wood dust is hazardous to health. For work activities involving exposure to fine wood dust, a dust mask should be used.
5.4.

SPINDLE SET-UP

5.4.1. Remove the nut and washer on the spindle, slide the selected rubber drum over the spindle (fig.3).
5.4.2. Attach the washer retaining ring and loosely screw on the nut (fig.3).
5.4.3. Slide the required sleeve over the rubber drum and tighten nut using spanner (fig.2).
© Jack Sealey Limited
Spindle with
nut and washer
Sanding
drums
Table inserts
Original Language Version
fig.2
