Vaisala WMT700 Technical Notes

RESTRICTED
Technical note
Connecting WMT700 cables
CAUTION!
to tighten the connector properly voids the warranty.
CAUTION!
not use tools.
If you have a cable tightening tool supplied by Vaisala in the past, do not use it with the current cable
connector.
There are 3 WMT700 cable types:
• The hybrid cable designed for the fully heated WMT700. You can use it with all versions.
• The standard cable for non-heated, transducer-heated, and transducer-and-arm-heated
WMT700.
• The RS-485 cable for RS-485 connections only. You can use it for non-heated, transducer-heated,
and transducer-and-arm-heated WMT700.
Table 1 WMT700 Cable Types
Cable type
Hybrid cable
Standard cable
RS-485 cable
CAUTION!
4-mm Allen key
Connecting WMT700 cables
WMT700
Tighten the connector properly to avoid water leakage and damage to the sensor. Failure
WMT700 cables have an easy-to-use cable connector. Tighten the connector by hand. Do
Fully-heated Transducer-
WMT700 and-arm-
heated
WMT700
✓ ✓
✓
✓
Do not use the standard cable and the RS-485 cable with the fully heated WMT700.
PUBLISHED BY
All rights reserved. Any logos and/or product names are trademarks of Vaisala or its individual partners.
Vaisala Oyj
Any reproduction, transfer, distribution or storage of information contained in this document is strictly
Vanha Nurmijärventie 21 prohibited. All specifications — technical included — are subject to change without notice.
FI-01670 Vantaa, Finland
© Vaisala Oyj 2020
Transducer- Non-heated
heated WMT700
WMT700
✓ ✓
✓ ✓
✓ ✓
M212210EN-C
RS-485
Connections
✓
