- Page 1 S S 0 0 ACTIVE SUBWOOFER digital power MANUALE d’USO - Sezione 1 USER MANUAL - Section 1 BEDIENUNGSANLEITUNG - Abschnitt 1 CARACTERISTIQUES TECHNIQUES - Section 1 Made in Italy COD. 420120164 Rev. 5...
-
Page 2: Controls And Functions
CONTROLS AND FUNCTIONS "MAINS FUSE" FUSE CARRIER Mains fuse housing. “FULL RANGE MAINS INPUT" POWER SOCKET For connecting the power cable provided. The connector used for mains connection is a POWER CON® (blue) “LINK” RELAUNCH POWER SOCKET For relaunching the mains power. The output is connected in parallel with input (2) and can be used to power another amplified speaker. -
Page 3: Technical Specification
signal to other subwoofers. By using a single delay module it is possible to delay several subwoofers at the same time. This module can also be used to create cardioid configuration systems. The cardioid configuration provides a remarkable attenuation of the low frequencies radiated by the rear side of the subs, without changing the direct radiated signal on the fronside. -
Page 4: Installation
INSTALLATION DVA system has obtained the TÜV certification for suspension of DVA T4 and DVA S10dp speakers through flybar stirrup DRK 10. The report certifies that the maximum weight applying to DRK 10 flybar is 250Kg. DVA T4 configuration The DRK 10 flybar attests that the maximum number of DVA T4 is 16. Refer to table 1 to determine the total weight borne by flybar according to the different DVA T4 configurations. - Page 5 Always install parts in accordance with these installation instruction! Compile and store all DVA system documents in a safe place! Warning If the security norms and total weight calculations are not observed, dB Technologies is not responsible for any possible damage to people and things. Note During installation ensure that carrying structure of the system has added in the total weight also the DRK 10 flybar weight, chain hoists, motors, cables and further weights.
- Page 6 SCHEMA A BLOCCHI BLOCK DIAGRAM BLOCKSCHALTBILD DIAGRAMA EM BLOQURES...
- Page 7 COLLEGAMENTI CABLE CONNECTIONS VERKABELUNG CABLAGE BALANCED BALANCED LINK X-OVER MAIN INPUT OUTPUT PUSH 1 = GND 2 = HOT 3 = COLD MIXER FULL RANGE OUTPUT BALANCED INPUT 1 = GND 2 = HOT 3 = COLD Digital Vertical Array BALANCED LINK / OUT BALANCED...
- Page 8 INSTALLAZIONE INSTALLATION INSTALLATIONEN INSTALLATIONS In appoggio In appoggio - impilato Groundstack Groundstack - stacked...
- Page 9 In appoggio con flybar (opzione DRK 10) Groundstack with flybar (DRK 10 option)
- Page 10 Kit staffe- opzione SRK 10 Kit stirrups - SRK-10 option In appoggio con kit staffe Groundstack with kit stirrups...
- Page 11 Appeso con kit staffe (opzione SRK-10) e flybar (opzione DRK-10) Hang with stirrups kit (SRK-10 option) and flybar (DRK-10 option)
- Page 12 Opzione DSA 4 DSA 4 Option In appoggio Floor stack Per supporto asta Stand adaptor In appoggio son supporto su asta per Groundstack with stand adaptor...
- Page 13 In appoggio a pavimento con supporto asta provvisto di piedi Groundstack to floor with stand adaptor with feet Set di 4 ruote - opzione DWK 20 Set of 4 wheels - DWK 20 option...
- Page 14 BALANCED BALANCED X-OVER TECHNOLOGIES TECHNOLOGIES LINK MAIN INPUT OUTPUT PUSH SUB-WOOFER 120Hz 0° LEVEL 90Hz 180° ON SGN LIM XOVER PHASE 1 = GND 2 = HOT 3 = COLD S S 0 0 Digital Delay subwoofer - opzione SDD Subwoofer Digital Delay - SDD option ALLINEAMENTO SEGNALE AUDIO ALIGNAMENT AUDIO SIGNAL...
- Page 15 CONFIGURAZIONE CARDIOIDE CARDIOID CONFIGURATION 0° 180° Ruotare la fase di 180° Rotate 180° phase BALANCED BALANCED X-OVER LINK TECHNOLOGIES MAIN INPUT OUTPUT PUSH SUB-WOOFER 120Hz 0° PUSH LEVEL 90Hz 180° ON SGN LIM XOVER PHASE 1 = GND 2 = HOT S S 0 0 3 = COLD PHASE...
- Page 16 A.E.B. INDUSTRIALE s.r.l. Via Brodolini, 8 - 40056 Crespellano (Bo) - ITALIA Tel. + 39 051 969870 - Fax. + 39 051 969725 Internet: www.dbtechnologies.com E-mail: info@dbtechnologies-aeb.com...
