WWW.BROAN.CA
WWW.NUTONE.CA
RANGE HOOD
Series: BKDD1, BKDF1, BKSA2, BKSF1, BKSM1,
CKSL1, NKDF1, NKSA1 and NKSH1
INSTALLATION, USE
AND CARE MANUAL
Serial number:
99045655-001C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NKSA1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NuTone NKSA1

  • Page 1 WWW.BROAN.CA WWW.NUTONE.CA RANGE HOOD Series: BKDD1, BKDF1, BKSA2, BKSF1, BKSM1, CKSL1, NKDF1, NKSA1 and NKSH1 INSTALLATION, USE AND CARE MANUAL Serial number: 99045655-001C...
  • Page 2: Table Of Contents

    Connect the Wiring ..... . 22 Light Bulbs (BKSA2, BKSM1, CKSL1,NKSA1 and NKSH1 Series only) ....23 Install the Filters .
  • Page 3: Safety

    INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. For Broan range hoods, register your range hood online at www.broan.ca For NuTone range hoods, register your range hood online at www.nutone.ca WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: •...
  • Page 4 WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. b) Always turn hood ON when cooking at high heat or when flambeing food (i.e.: Crêpes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
  • Page 5: Operation

    Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and fresher. Operate the hood as follows: BKSA2 NKSA1 SERIES BLOWER SWITCH LIGHT SWITCH Turns blower on to LOW speed.
  • Page 6 BKDD1, BKDF1 NKDF1 SERIES BLOWER BUTTON When blower is OFF, press this button to turn ON the blower at the last saved speed. If there was no speed saved, the blower will be set on LOW speed. NOTE: When LOW speed is activated from OFF, the blower starts on MEDIUM speed for a very short lapse of time, and then resume to LOW speed.
  • Page 7: Cleaning And Maintenance

    Cleaning and Maintenance Proper maintenance of the Range Hood will assure proper performance of the unit. MOTOR The motor is permanently lubricated and never needs oiling. If the motor bearings make excessive or unusual noise, replace the motor with the exact service motor. The fan blade should also be replaced.
  • Page 8: Installation

    Drill, 1/8” drill bit and 1½” hole saw (to mark holes for ducting and cut electrical access hole) • 7/64” drill bit (to drill holes for EZ1 brackets mounting screws, not for BKSA2 and NKSA1 Series) • Wood shims (2) and wood screws (4) (required for standard installation to framed cabinet) •...
  • Page 9: Contents

    Contents Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: BKDF1 and NKDF1 Series BKSM1, CKSL1 and NKSH1 Series IND INSIDE OF HOOD (2) S HIELDED...
  • Page 10 BKSF1 Series BKDD1 Series IND INSIDE IND INSIDE OF HOOD OF HOOD (1) 3¼” 10” (1) 7” R (1) 3¼” 10” (1) 7” R OUND OUND (2) G (2) G REASE ILTERS REASE ILTERS AMPER ASSEMBLY ONNECTOR AMPER ASSEMBLY ONNECTOR EZ1 C EZ1 C OMPONENTS...
  • Page 11 BKSA2 and NKSA1 Series (1) G REASE ILTER IND INSIDE OF HOOD (1) 3¼” 10” AMPER ASSEMBLY (1) 7” R OUND ONNECTOR (1) P ** C ARTS ONTAINING (5) N 5/8” RD. HD. CREWS (1) B UCTION ** F IND PARTS BAG BEHIND...
  • Page 12: Prepare The Hood

    3 ] Remove the EZ1 brackets from inside the hood by cutting off the tie wrap (no EZ1 brackets in BKSA2 and NKSA1 Series). Remove both screws holding damper assembly to hood. Remove parts bag (captured behind the damper assembly). Remove damper assembly from inside the hood and keep the screws for further use.
  • Page 13 5 ] Remove 7” Round Duct Plate from top/back of hood (see illustration below). 7” ROUND DUCT PLATE 2 SCREWS 6 ] Remove Electrical Power Cable Knockout from top (vertical exhaust) or back (horizontal exhaust) of hood. Install an appropriate strain relief, 1/2” diameter (not included). ELECTRICAL POWER CABLE KNOCKOUT...
  • Page 14 DUCTED INSTALLATION ONLY 8 ] Remove 3¼” x 10” vertical, 3¼” x 10” horizontal, or 7-inch round knockout plate as appropriate for your ducting method (see F 1 A and 1 B). IGURES IGURE IGURE 7” ROUND KNOCKOUT PLATE ( ALSO REMOVE VERTICAL KNOCKOUT PLATE 3¼”...
  • Page 15: Prepare The Hood Location

    EZ1 one-person installation system (using included template and brackets). Please note that the EZ1 one-person installation system is not available for the BKSA2 and NKSA1 Series. However, all Series range hoods can be installed in the standard way. For the standard installation, go to page 20.
  • Page 16 6 ] Install the proper installation brackets according to the type of cabinet (framed or frameless). See below. FRAMED CABINET Refer to the marking on brackets to determine the correct installation side and orientation. 7/64”  Mate the corresponding bracket to the cabinet side frame, while placing rear end of bracket against the wall.
  • Page 17 FRAMELESS CABINET Refer to the marking on brackets to determine the correct installation side and orientation. 7/64”  Align the corresponding bracket to the cabinet side, while placing rear end of bracket against the wall. Draw a line on the outer edge of the bracket (as shown). ...
  • Page 18: Install The Hood (Ez1 Bracket)

    Install the Hood (EZ1 Bracket) OTE: The following procedure applies to both frame or frameless cabinet installations. 1 ] Run house power cable between service panel and hood location. 2 ] There are 2 pairs of recessed holes on each side of the top of the hood (on rear: A and B, on front C and D on illustration below);...
  • Page 19 7 ] For framed cabinet, secure the hood to the EZ1 brackets using four (4) no. 8-18 x 1/2” metal screws with washers. For frameless cabinet, secure the hood to the cabinet using four (4) no. 8 x 5/8” round head wood screws (screws and washers included in parts bag). Insert two (2) screws and washers per side, in the slots (as shown in insets on illustration below).
  • Page 20: Standard Installation

    Standard Installation (without EZ1 brackets) 1 ] Use the proper diagram below for placement of ductwork and electrical cutout in cabinet or wall. For a non-ducted installation, DO NOT cut a duct access hole, only cut the hole for electrical wiring. 3¼"...
  • Page 21: Install The Hood (Standard Installation)

    Install the Hood (Standard Installation) 1 ] Run house power cable between service panel and hood location. Run the house power cable into the hood through the strain relief previously installed in step 6 on page 13. 2 ] Hang hood from (4) mounting screws previously installed. Slide hood back towards wall until mounting screw heads are engaged in narrow end of keyhole slots in top of hood.
  • Page 22: Connect The Wiring

    Connect the Wiring WARNING Risk of electric shock. Electrical wiring must be done by qualifi ed personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from being switched on accidentally.
  • Page 23: Light Bulbs (Bksa2, Bksm1, Cksl1,Nksa1 And Nksh1 Series Only)

    (BKSA2, BKSM1, CKSL1, NKSA1 and NKSH1 Series only) The BKSA2, BKSM1, CKSL1, NKSA1 and NKSH1 Series range hoods require two shielded Halogen Bulbs (120 V, 50 W max., MR16 or PAR16 with GU10 base) (included only with BKSM1, CKSL1 and NKSH1 Series range hoods).
  • Page 24: Wiring Diagram

    BKDD1, BKDF1 NKDF1 SERIES...
  • Page 25 BKSM1 CKSL1 SERIES...
  • Page 26 BKSF1 SERIES...
  • Page 27 BKSA2, NKSA1 NKSH1 SERIES...
  • Page 28: Service Parts

    EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 29 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 30 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 31 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 32 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 33 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 34 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 35 EPAIRS In order to ensure your unit remains in good working condition, you must use Broan-NuTone Canada ULC genuine replacement parts only. Broan-NuTone Canada ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
  • Page 36: Warranty

    Company’s most current written limited warranty for your particular product will control. The most current limited written warranties for the Company’s products can be found at www.broan.ca or www.nutone.ca. Broan-NuTone Canada ULC, 1140 Tristar Drive, Mississauga, Ontario, Canada L5T 1H9 www.broan.ca...
