Summary of Contents for ViewSonic N2600w
-
Page 2: Table Of Contents
Side View of the Product ...8 Rear View of the Product...9 Remote Control ...11 Installation ...13 Basic Operation ...22 OSD Functions OSD style and operation tips ...23 OSD Operation ...23 Other Information Specifications ...32 Troubleshooting...33 Customer Support ...35 Limited Warranty ...36 ViewSonic N2600w... -
Page 3: Compliance Information
89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to amended by 93/68/EEC Art.13 with regard to User Information for all Countries Notice: Use the cables which are included with the unit or specified. Electromagnetic compatibility ViewSonic and 73/23/EEC as Safety. N2600w... -
Page 4: Important Safety Instructions
ViewSonic N2600w... -
Page 5: Copyright Information
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 6: Antenna Installation Instructions
LCD TV screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD TV. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. ViewSonic... -
Page 7: Getting Started
Getting Started Congratulations on your purchase of a ViewSonic Important!Save the original box and all packing material for future shipping needs. Package Contents Your LCD TV package includes: LCD TV Power Cable RF Cable ® LCD TV. Universal Remote Control with batteries... -
Page 8: The Wall Type Is Installed
Setting the LCD TV on the wall Hanging the LCD TV on the wall requires special skill that only be performed by qualified service personnel. Please contact ViewSonic or your local distributor for the installation instruction. Hanging the LCD TV on the wall requires special skill that only be performed by qualified service personnel. -
Page 9: Move Loudspeaker Secure
Move loudspeaker secure It please arrange with ViewSonic or your local distributor to move it except the loudspeaker. Please carry out and operate following: Cut off the power to join. Face LCD TV below on the towel or the woolen blanket. -
Page 10: Side View Of The Product
Increase volume or adjust a highlighted increasingly control while in OSD menu. Volume Down Decrease volume or adjust a highlighted control decreasingly while in OSD menu. CH Up Channel up/ Scroll up. CH Down Channel down/ Scroll down. MENU Turn OSD menu ON/OFF. Power Turn the power ON/OFF. ViewSonic N2600w... -
Page 11: Rear View Of The Product
Rear View of the Product ViewSonic N2600w... - Page 12 Connect the scart socket of the VCR to the SCART2 socket on the LCD TV SCART1 Connect the scart socket of the VCR to the SCART1 socket on the LCD TV Audio output Connect this port to your external speaker ViewSonic N2600w...
-
Page 13: Remote Control
Mute On/Off. Select the teletext pages color coded in green along the bottom of the screen. Switch Teletext On/Off. Select the teletext pages color coded in red along the bottom of the screen. Displays the sources and time. ViewSonic N2600w... - Page 14 TELETEXT Function Key (Yellow) WIDE PIP/SWAP PIP/POS ViewSonic N2600w Set timer to turn off TV. Activate PIP or POP feature. Press to toggle the Sub picture between PIP and POP. Power ON/OFF. Use this button to select the channel number with “-/—”.
-
Page 15: Installation
Dispose of the battery in accordance with local laws and regulations. Keep the battery away from children and pets. When the remote control will not to be used for an extended period, remove the batteries. ViewSonic N2600w... - Page 16 2. Connecting with the antenna Make sure the power is off before installing N2600w. Connect the LCD TV to TV antenna terminal or CATV box by 75-ohm coaxial cable. RF Cable 3. Connect Audio Cable To connect an external amplifier, connect the L/R RCA cable from the TV AUDIO OUT port to the appropriate AUDIO IN port on a compatible amplifier as shown on the right.
- Page 17 4. Connect AV, S-Video, YCbCr, YPbPr, HDMI to Video Devices Connect Video/Audio cables from compatible devices into the right side of N2600w. AV Mode: RCA A/V Cable (Cable not supplied) S-Video Mode: S-Video Cable (Cable not supplied) Audio in Cable...
-
Page 18: Ypbpr Mode
YCbCr Mode: YCbCr Cable (Cable not supplied) Audio in Cable (Cable not supplied) DVD Player or VCR YPbPr Mode: YCbCr Cable (Cable not supplied) Audio in Cable (Cable not supplied) DVD Player or VCR ViewSonic N2600w... - Page 19 SCART Cable (Cable not supplied) SCART2 Mode: Connect the scart socket of the VCR to the SCART2 socket on the LCD TV. Note: In SCART2 socket, the video output is not available. SCART Cable (Cable not supplied) ViewSonic N2600w...
- Page 20 (DVD Player should have the HDMI output terminal) HDMI Cable (Cable not supplied) Note: To receive the sound from DVD, please turn on Sound Menu of OSD for selecting HDMI audio to HDMI. However, the input source should be in HDMI. ViewSonic N2600w...
- Page 21 5. Connect to the PC VGA (15pin D-Sub): Connect the VGA cable from VGA output of PC to the VGA terminal input of N2600w. PC up to 1280 x 1024, or 1360 x 768 is the preferred resolution. VGA 15 Pin Cable...
- Page 22 HDMI: Connect the HDMI cable from HDMI output of PC to the DVI terminal input of N2600w. HDMI Cable (Cable not supplied) Earphone: Connect Earphone from compatible devices into the earphone input at the left side of N2600w. Earphone (Cable not supplied)
- Page 23 6. Connect power cable Connect the power cord to the N2600w then to a properly grounded AC outlet. Turn on the AC Switch on the back of N2600w AC Switch Switch to ON AC wall socket 7. Turn Power ON Press the Power button under the LCD TV, or press the Power On (red) button on the Remote Control.
-
Page 24: Basic Operation
Use the button to select the channel number with dash. “-/—” Return to the previous channel, press RECALL on your remote control. ViewSonic N2600w and Vol and Vol on the remote... -
Page 25: Osd Functions Osd Style And Operation Tips
Press the “Menu” button on your remote control or right side of the LCD TV again to close the OSD Main Menu. The 5 icons at the left of the OSD Main menu stand for the 6 sub menus (Picture, Sound, TV, Option, PC, and OSD). to enter the sub menu. or OK to ViewSonic N2600w... - Page 26 Aspect Ratio 14:9, 4:3, Panorama) Set the picture mode to Picture Standard, Movie, Vivid, or User Mode ViewSonic N2600w Operation to increase the contrast. to decrease the contrast. to brighten the display. to darken the display. to increase the greenish tone.
- Page 27 Operation to select Main or sub. to increase lower-pitched sound. to decrease lower-pitched sound. to increase higher-pitched sound. to decrease higher-pitched sound. to emphasize the right speaker. to emphasize the left speaker. : select Mono, Stereo or SAP. ViewSonic N2600w...
- Page 28 Set TV Channel Country Auto Scan/Fully Scan all the TV channels. Search TV Reset Reset Default Value ViewSonic N2600w Operation : select current Channel Number. Default Current Channel Number OK: modify Name MENU: leave Modify Mode :change the char value...
- Page 29 Sleep Timer options are OFF, 15 Min, 30 Min, 45 Min, and 60 Min. Multi Picture Adjust sub picture functions Operation to select OFF, 15 Min, 30 Min, 45 Min, and 60 Min. enter Multi Picture sub menu. ViewSonic N2600w...
- Page 30 Adjust the vertical position of the sub picture. Border color Sub picture Border color setup Change Main source and PIP Swap source. ViewSonic N2600w Operation to select input source to move toward the right. to move toward the left. to move downward. to move upward.
- Page 31 Color Mode sub menu. to activate the function ViewSonic N2600w...
- Page 32 You can adjust G to change color User-G temp. You can adjust B to change color User-B temp. ViewSonic N2600w Operation to select color. to increase the color temp. to decrease the color temp to increase the color temp. to decrease the color temp to increase the color temp.
- Page 33 : move toward the left. : move upward. : move downward. : increase the OSD display time. : decrease the OSD display time. : increase the transparency. : decrease the transparency. : display information. : activate the function. ViewSonic N2600w...
-
Page 34: Other Information
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the LCD TV. Note: Product Specifications are subject to change without notice. ViewSonic N2600w 26” view able 0.4215(H) x 0.4215(V) mm pixel pitch RGB vertical stripe Anti-Glare RGB analog (0.7/1.0 Vp-p, 75 ohms) -
Page 35: Troubleshooting
External influences such as lightning or static electricity may cause improper operation. In this case, operate the unit after first turning on the power of the LCD TVand the AVC System, or unplug the AC cord for 1 to 2 minutes, then replug again. ViewSonic N2600w... - Page 36 CATV is connected improperly or not connected; please check all the CATV connections. The cable TV service is interrupted; please contact your cable operator. Picture is cut off/with sidebar screen Is the image positioned correctly? Are screen mode adjustments such as picture size set correctly? ViewSonic N2600w...
-
Page 37: Customer Support
35 25 65 12 09 2311 3413 03 8717 1616 0696 630 8051 01 411 8936 02 4527 9033 40 6661 5618 053 484 9308 22 57 77 38 21359 1423 800-200-8439 913 496 534 08 5792 9045 0207 949 0307 ViewSonic N2600w... -
Page 38: Limited Warranty
How long the warranty is effective: ViewSonic LCD TV’s are warranted for one (1) year for all parts excluding the light source and one (1) year for labor from the date of the first consumer purchase.
