Summary of Contents for ViewSonic VS12276-1G
- Page 1 ® ViewSonic N2690w LCD TV - 使用手冊 - User Guide Model No. : VS12276-1G...
-
Page 2: Table Of Contents
Antenna Installation Instructions ... 3 Cleaning the LCD TV ... 4 Getting Started Package Contents ... 5 Mounting ViewSonic LCD TV to the wall... 5 Place the TV on a solid Install the wall mount plate to the LCD TV... 6 Connecting the power... -
Page 3: Important Safety Instructions
21. Please plug the TV’s power plug into a nearby power outlet that is the most convenient for connection. 22. Warning: To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture. ViewSonic N2690w... -
Page 4: Copyright Information
Copyright Information Copyright © ViewSonic ® Corporation, All rights reserved. ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. Disclaimer:ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein;... -
Page 5: Antenna Installation Instructions
When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. Ground clamp Electric service equipment Ground clamps ViewSonic Antenna Antenna discharge unit Grounding conductors Power service grounding electrode system N2690w... -
Page 6: Cleaning The Lcd Tv
LCD TV screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD TV. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 7: Getting Started
Do not install in a moist or wet environment. This equipment is intended for indoor use. Do not install near heat source, or strong magnetic fields. Use only ViewSonic approved wall-mounting brackets to support the LCD TV weight. Before attaching the wall mount plate to the back cover, ensure the product is working. -
Page 8: Place The Tv On A Solid Surface
If the unit is not turned off and in the standby state, the TV set will always consume a certain electric power. When the TV set will not be used for a long period of time, it is recommended to unplug it from the power outlet. ViewSonic N2690w... -
Page 9: Turn The Tv On & Off
OSD menu appears, use to change channels in TV mode. When the OSD menu appears, press these two buttons to Vol: confirm the selected item; when no OSD menu appears, use to adjust the volume. ViewSonic N2690w... -
Page 10: Signal Source Interface From Rear View
Component Input port. VGA Signal Input / Audio Input: Use the VGA signal cable to connect signals from a PC to the TV Input. Connect the PC audio cable supplied with the TV to the TV’s PC Audio Input. ViewSonic N2690w... -
Page 11: Signal Source Interface From Side View
There are several source devices that can connect to your TV. Here is how to connect various devices. Tips: When connecting the external equipment with the TV, please ensure that the TV power is turned off. When connecting the external equipment, please connect the cable to the terminal with the same color. ViewSonic N2690w... -
Page 12: To Use Remote Control
To select input source. ∧∨＜＞ Press these buttons to navigate the OSD menus. ∧∨＜＞are for function select, and is for function adjustment. ViewSonic Enter Press the button to confirm selection. POWER Press to turn on/off. HDMI To select HDMI input. -
Page 13: Remote Control Battery Installation
7. If the battery fluid leaks inside the remote control, clean the battery compartment carefully and insert new batteries. 8. Improper battery changing may cause explosion. 9. Dispose of the used batteries in accordance with the instructions on the battery. ViewSonic N2690w... -
Page 14: To Use The Osd Menu
S-Video, YPbPr, HDMI1 & VGA. Adjustable items for TV mode includes: Picture, Sound, Advance, System and TV channel. Adjustable items for AV, S-Video, YPbPr, HDMI Input modes includes: Picture, Sound, Advance, System. Adjustable items for VGA mode includes: Picture, Sound, PC, System. ViewSonic N2690w... - Page 15 4. Sharpness: Adjustment picture sharpness, range is from 0 to 10.（Not support for PC, HDMI mode.） 5. Color Temperature: You can select or adjust the color temperature according to your requirements. Selection: Cool Warm & Middle. 6. MEMORY RECALL: To reset the video settings back to the factory default settings. ViewSonic N2690w...
- Page 16 3. Balance: Adjustable ranges are from -10～10. Right channel sound fades out as adjusting from 0 to -10 and the left channel fades out as adjusting form 0 to 10. 4. Memory Recall: To reset the Sound settings back to the factory default settings ViewSonic N2690w...
- Page 17 2. High contrast: To enhance the color saturation and color effect. 3. Aspect ratio: Use wide, Normal, 16:9 Zoom-Up modes to select the screen ratio. Memory Recall: To reset the Advance Settings back to the factory default settings ViewSonic N2690w...
- Page 18 Auto after choosing Auto Save.) (5) Sound system: To display the sound standard of the current TV signal (display as Auto after choosing Auto Save.) (6) Fine tuning: Use left/right buttons to fine tune the frequency. The range is from- 50～50 ViewSonic N2690w...
- Page 19 (8) Save: Save each setting for manual tuning.。 3. Channel list: Press the Left/Right button to enter the submenu; see the figure below. You can edit the channel list according to the instructions at the bottom of the menu. ViewSonic N2690w...
- Page 20 6. Reset: To reset the settings back to the factory default settings. PC settings（under PC mode） 1. Auto Adjust: Automatically adjust VGA input to the optimal screen size. 2. V Position, H Position: Adjustable ranges are from 50～50 3. Clock or Phase: Adjustable ranges are from 50～50 ViewSonic N2690w...
-
Page 21: Other Information
Power Consumption (Standby) Dimensions (W)x(H)x(D) (mm) (with stand) Wall Mount Kits Wall Mount dimension Environmental Considerations Operating Temperature Operating Humanity Storage Temperature Storage Humanity ViewSonic N2690w 660mm 1360x768 5Wx2 D/K, I, B/G AC100-240V 50/60Hz 150W ≤1W 652mmx482mmx189mm Not Include 200x200mm M6x10mm, 4 pcs (Screw) 0ºC~35ºC（32ºF~95ºF）... -
Page 22: Troubleshooting
There is no sound. The remote control does not function. ViewSonic Troubleshooting Make sure the LCD is properly connected. Make sure the AC power cord is properly connected. Make sure the AC power is ON, DC power button is ON (Blue LED). - Page 23 TV. Images are cropped / with sidebar screen. ViewSonic The external influences such as lightning or static electricity will result in failure to work properly. In this case, turn on the power of LCD TV and then perform the operation, or disconnect the AC power cord for 1-2 minutes, and then re-plug the power cord.
-
Page 24: Customer Support
For technical support or product service, see the table below or contact your reseller. Note: You will need the product serial number. Country/ Region China www.viewsonic.com.cn 800 820 3870 Hong Kong www.hk.viewsonic.com +852-310-22-900 service.cn@cn.viewsonic.com Declaration of RoHS Compliance The toxic and hazardous substances or elements of this product are shown as below:... -
Page 25: Limited Warranty
How long the warranty is effective: ViewSonic LCD TV are warranted for one (1) year for all parts excluding the light source and one (1) year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 26 ViewSonic ®...
