DC814 QUICK START GUIDE
Table 2. Buffer Board Part Numbers
*
Buffer Board
DC814A2-A
DC814A2-B
DC814A2C
DC814A2-D
DC814A2-E
DC814A2-F
DC814A2-G
DC814A2-H
DC814A2-I
DC814A2-J
DC814A2-K
*
A DC814A2-X is version two of the Buffer Board.
The first release of the Buffer Board is DC814A-X
and is compatible with a DIP-8 Clock Board.
Figure 1. DC814B-X DIP-8 Clock Board
(Top side view)
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
Clock IC
LTC6905
LTC1799
LTC6900
LTC6905-133
LTC6905-100
LTC6905-96
LTC6905-80
LTC6906
LTC6907
LTC6908-1
LTC6908-2
Figure 2. DC814C-X DIP-8 Clock Board
(Top side view)
Figure 3. DC814D-X DIP-8 Clock Board
(Top side view)
