Marshall Major II Bluetooth - Headphones Manual
- User manual (8 pages) ,
- User manual (9 pages)
Advertisement
DEVICE LAYOUT
- POWER BUTTON.
- CONTROL KNOB.
- MICRO USB SOCKET FOR CHARGING.
- 3.5 MM INPUT/ OUTPUT SOCKET.
- MICROPHONE.
CONTROLS
ANSWER INCOMING CALL:
SINGLE CLICK THE CONTROL KNOB.
REJECT OR END CALL:
DOUBLE CLICK THE CONTROL KNOB.
PLAY OR PAUSE A SONG:
SINGLE CLICK THE CONTROL KNOB.
NEXT SONG:
PUSH THE CONTROL KNOB TO THE RIGHT.
PREVIOUS SONG:
PUSH THE CONTROL KNOB TO THE LEFT.
TURN VOLUME UP:
PUSH THE CONTROL KNOB UPWARD.
TURN VOLUME DOWN:
PUSH THE CONTROL KNOB DOWNWARD.
POWER ON/OFF
PUSH AND HOLD THE POWER BUTTON FOR 4 SECONDS TO TURN ON.
PUSH AND HOLD THE POWER BUTTON FOR 4 SECONDS TO TURN OFF.
NOTE: IF NOT CONNECTED TO A SOUND SOURCE THE HEADPHONE WILL AUTOMATICALLY TURN OFF AFTER 10 MINUTES.
BLUETOOTH® PAIRING
WHEN POWERED ON, DOUBLE CLICK THE POWER BUTTON ON THE HEADPHONES. THE BLUETOOTH® PAIRING INDICATOR STARTS FLASHING BLUE. ENABLE BLUETOOTH® IN YOUR DEVICE. SELECT "MAJOR II BLUETOOTH" IN THE BLUETOOTH® LIST AND ACCEPT PAIRING. THE INDICATOR TURNS OFF WHEN THE PAIRING IS COMPLETED.
NOTE: AFTER THE INITIAL PAIRING, THE HEADPHONE WILL AUTOMATICALLY CONNECT TO THE DEVICE WHEN TURNED ON AGAIN.
CHARGING
THE RED BATTERY INDICATOR STARTS BLINKING WHEN THE BATTERY LEVEL IS LOW. PLUG THE INCLUDED USB CABLE INTO THE MICRO USB SOCKET ON THE HEADPHONE. PLUG THE USB END OF THE CABLE INTO A USB POWER SOURCE. THE RED BATTERY INDICATOR STAYS LIT WHEN CHARGING. WHEN THE BATTERY IS FULLY CHARGED, THE BATTERY INDICATOR TURNS WHITE.
NOTE: CHARGE THE BATTERY BEFORE USING THE HEADPHONES THE FIRST TIME. 2 HOURS CHARGE GIVES APPROXIMATELY 8 HOURS OF PLAYBACK AT MEDIUM VOLUME.
PHONE FUNCTIONALITY
WIRELESSLY ANSWER, REJECT OR END A CALL USING THE CONTROL KNOB.
SHARING
USE THE EMPTY 3.5MM SOCKET TO SHARE YOUR AUDIO.
COLLAPSIBLE
COLLAPSIBLE DESIGN FOR EASY STORAGE AND TRANSPORTATION.
REMOVABLE EAR CUSHIONS
HOLD EAR CUSHION AND TURN COUNTER-CLOCKWISE.
TECHNICAL INFO
- TRANSDUCER: 40 MM, DYNAMIC
- IMPEDANCE: 64 OHM
- FREQUENCY RANGE: 10 HZ-20 KHZ
- SENSITIVITY: 100 MV @ 1 KHZ = 99 DB SPL
DETACHABLE 3.5 MM CORD
IF YOUR BATTERY DIES, SIMPLY PLUG IN THE DOUBLE-ENDED CORD WITH BUILT IN MIC AND REMOTE. COMPATIBLE WITH ANY MUSIC PLAYER THAT RECEIVES A 3.5 MM JACK.
- 3.5MM MICROPHONE:
![]()
THE BUILT-IN MICROPHONE ALLOWS YOU TO TAKE CALLS OR RECORD VOICE MEMOS THROUGH YOUR DEVICE. - 3.5MM REMOTE:
![]()
CLICK ONCE TO ANSWER INCOMING CALLS OR HANG UP, AS WELL AS PLAY AND PAUSE YOUR MUSIC. CLICK TWICE TO FAST FORWARD YOUR MUSIC. CLICK THREE TIMES TO REWIND.
TROUBLESHOOTING
| PROBLEM | ACTION |
| NOT POWERING ON | CHARGE THE HEADPHONE USING THE USB CABLE. |
| NOT CHARGING | MAKE SURE THE USB POWER SOURCE IS SWITCHED ON. |
| NOT PAIRING | MOVE THE DEVICES CLOSER TO EACH OTHER AND AWAY FROM ANY INTERFERENCE OR OBSTRUCTION. MAKE SURE THE HEADPHONE IS NOT CONNECTED TO A DIFFERENT SOUND SOURCE WHEN ENTERING THE PAIRING MODE. DISABLE AND ENABLE BLUETOOTH® COMMUNICATION ON YOUR SOUND SOURCE. |
| NO SOUND | MAKE SURE THE HEADPHONE IS ON AND CONNECTED. MAKE SURE THE SOUND SOURCE IS PLAYING. |
| POOR SOUND QUALITY | MOVE THE DEVICES CLOSER TO EACH OTHER AND AWAY FROM ANY INTERFERENCE OR OBSTRUCTION. |
| NOT RESPONSIVE | LOCATE RESET BUTTON INSIDE THE 3.5MM INPUT AND PRESS FOR AT LEAST TWO SECONDS USING A PAPERCLIP OR SIMILAR NARROW OBJECT. |
MARSHALL IS A TRADEMARK OF MARSHALL AMPLIFICATION PLC. PERMISSION GRANTED. DESIGN OF PRODUCT AND PACKAGING ARE INTELLECTUAL PROPERTIES OF ZOUND INDUSTRIES INTERNATIONAL AB. © 2016 ZOUND INDUSTRIES. ALL RIGHTS RESERVED. PRODUCED IN CHINA. THE MANUFACTURER OF THIS PRODUCT MAKES NO CLAIMS OF COMPATIBILITY OF THE MICROPHONE AND REMOTE WITH ANY MOBILE DEVICE. FOR USE WITH CELLPHONE USING 3.5 MM PLUG UNPROTECTED TWO-WAY STANDARD. ZOUND INDUSTRIES INTERNATIONAL AB • CENTRALPLAN 15 • 111 20 STOCKHOLM • SWEDEN
THE BLUETOOTH® WORD MARK AND LOGOS ARE REGISTERED TRADEMARKS OWNED BY BLUETOOTH SIG, INC. AND ANY USE OF SUCH MARKS BY ZOUND INDUSTRIES INTERNATIONAL AB IS UNDER LICENSE.
