MODEL 51ZC
ZERO CLEARANCE CABINET
FOR USE WITH FIREPLACE MODELS 51, T-51, 74, T-74, 21 ONLY.
MAY BE INSTALLED IN RESIDENTIAL AND MOBILE HOME.
Contact your insurance company for coverage and installation inspection.
BUCK STOVE
WARNING
Do not attempt to build a fire in this product. It has been designed and safety tested for use
only with Models 51,T-51,74,T-74, 21 manufactured by NEW BUCK CORPORATION.
Read and follow the installation and operating instructions for this model.
FEATURES
PREPARATIONS
INSTALLATION
OPERATION
MAINTENANCE
SAFETY
SAFETY NOTICE
IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS. CONTACT
THE AUTHORITY HAVE JURISDICTION (SUCH AS MUNICIPAL BUILDING
DEPARTMENT, FIRE DEPARTMENT, FIRE PREVENTION BUREAU,
ect.) SHOULD BE CONSULTED BEFORE INSTALLATION TO DETERMINE THE
NEED TO OBTAIN A PERMIT. KEEP THESE INSTRUCTIONS FOR FUTURE USE.
LISTED BY:
PFS/TECO, COTTAGE GROVE, WI
MANUFACTURED BY NEW BUCK CORPORATION
200 ETHAN ALLEN DRIVE,
SPRUCE PINE, N.C. 28777
Revised January 2019
www.buckstove.com
