BUCK STOVE MODEL 24
COAL STOVE
OWNER'S MANUAL
SAFETY NOTICE
IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR
SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS. THE AUTHORITY HAVING
JURISDICTION
( SUCH
AS
MUNICIPAL BUILDING
DEPARTMENT,
FIRE
DEPARTMENT, FIRE PREVENTION BUREAU, ect.) SHOULD BE CONSULTED BEFORE
INSTALLATION
TO DETERMINE THE NEED TO OBTAIN A PERMIT.
KEEP THESE
INSTRUCTIONS FOR FUTURE USE.
TESTED AND LISTED TO UL 1482 BY:
ITS/WARNOCK HERSEY, MIDDLETON, WI
MANUFACTURED BY NEW BUCK CORPORATION
200 ETHAN ALLEN DRIVE
PO BOX 69
SPRUCE PINE, N.C. 28777
REVISED AUGUST 2010
www.buckstove.com
Advertisement
Table of Contents
Related Manuals for BuckMaster Buck Stove 24
Summary of Contents for BuckMaster Buck Stove 24
-
Page 1: Safety Notice
BUCK STOVE MODEL 24 COAL STOVE OWNER'S MANUAL SAFETY NOTICE IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS. THE AUTHORITY HAVING JURISDICTION ( SUCH MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE PREVENTION BUREAU, ect.) SHOULD BE CONSULTED BEFORE INSTALLATION TO DETERMINE THE NEED TO OBTAIN A PERMIT. -
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ...................... 2 Assembly ......................3 Installation .....................4-6 Operation .......................7-9 Clearance to Combustible Wall Single Wall Pipe........10 Clearance to Combustible Wall Single Wall Pipe (Optional Rear Shield) ................... 11 Methods of Installation................12-13 Alternatives For Wall Protection..............14 New Buck Warranty ..................15-17 Page 1... -
Page 4: Introduction
INTRODUCTION The Keystone Coal Stove is a highly efficient heating unit. Proper installation will ensure years of heating satisfaction. Read the manual carefully. For more information, contact your local Buck Stove dealer. Safety is a vital factor in installing your stove. Without correct installation and operation, a house fire may result. -
Page 5: Assembly
ASSEMBLY 1. LEGS, CHIMNEY CONNECTOR AND BOTTOM SHIELD A. To install legs on your stove, place the unit at least 12" off the floor using blocks for support. Bolt each leg to the bottom of the unit using four (4) 3/8 - 16 bolts (furnished). After legs are in place, position the unit for use. -
Page 6: Installation
INSTALLATION FLOOR PROTECTION 1. If the floor is constructed of a combustible material, it must be placed on a floor protector. 2. Floor protector must be a listed floor protector of 1-1/2" thick or any combination to consist 3 or more R factor. -
Page 7: Chimney Connector
CHIMNEY CONNECTOR 1. Chimney connector must be 6" diameter 24 gauge minimum steel. 2. Do not use aluminum or galvanized steel. 3. Do not use chimney connector pipe as a chimney. 4. Connect stove to a chimney comparable to those illustrated in this manual. Chimney connector sections must be attached to stove and to each other with the crimped end toward the stove. - Page 8 THIMBLE Listed prefabricated 2100 degree metal thimbles can be purchased for use. (See figure 8). Installation instructions from the manufacturer must be strictly followed to ensure the safety of the system. Clearances to combustible materials must be maintained. Confirm local building codes for restrictions when connecting stove to masonry thimble through a combustible wall.
-
Page 9: Operation
OPERATION The Model 24 Coal Stove is designed to burn a variety of coals. Because of it's high carbon content and smokeless combustion, anthracite (hard) coal is the preferred fuel. The best size for this unit is chestnut. Use coal only. Do not use any other fuel. TO START A FIRE: Open air draft control on ash door to the "Open"... -
Page 10: Maintaining A Fire
MAINTAINING A FIRE After a fire has been started in your Keystone Coal Stove, it is possible to keep it burning for long periods of time. Simply use a minimum draft setting. Normally, you should remove the ashes and refuel twice a day. As the ash builds up, it is necessary to periodically remove it to make room for more fuel and to allow an unrestricted flow of air through the fuel bed. - Page 11 CREOSOTE AND SOOT The Model 24 Keystone Coal Stove has been designed specifically to burn coal. This conforms to United States Governmental Protection Agency regulations for coal stoves. Wood should not be used in your stove except as kindling to start the coal fire. When coal is burned, products of combustion combine with moisture to form soot residue.
-
Page 12: Clearance To Combustible Wall / Single Wall Pipe
CLEARANCE TO COMBUSTIBLE WALL SINGLE WALL PIPE FIGURE 1 FIGURE 2 Page 10... -
Page 13: Clearance To Combustible Wall Single Wall Pipe (Optional Rear Shield)
CLEARANCE TO COMBUSTIBLE WALL SINGLE WALL PIPE (With Optional Rear Shield) FIGURE 3 FIGURE 4 Page 11... -
Page 14: Methods Of Installation
METHODS OF INSTALLATION FIGURE 5 FIGURE 5.5 FIGURE 6 Page 12... - Page 15 METHODS OF INSTALLATION FIGURE 7 FIGURE 8 Page 13...
-
Page 16: Alternatives For Wall Protection
ALTERNATIVES FOR WALL PROTECTION FIGURE 9 Page 14... -
Page 17: New Buck Warranty
NEW BUCK CORPORATION (NBC) LIMITED WARRANTY KEYSTONE COAL STOVE PLEASE READ THIS WARRANTY CAREFULLY PRODUCTS COVERED This warranty covers the New Buck Stove heating unit, long as it is owned by the original purchaser, including optional and standard accessories purchased at the same time, subject to terms, limitations, and conditions herein set out. - Page 18 PROCEDURE Should you feel that your Buck Stove is defective, you should contact any Buck Stove dealer for the name of your nearest authorized Buck Stove service representative, who will instruct you on the proper procedure, depending on which Warranty Time Period (Period 1 or Period 2) applies. If for any reason you are dissatisfied with the suggested procedures, you may contact us in writing at: New Buck Corporation P.
- Page 19 OWNER REGISTRATION CARD The attached owner registration card must be completed in its entirety and mailed within 30 days from the date of installation in order for warranty coverage to begin to: New Buck Corporation P. O. Box 69 Spruce Pine, NC 28777 PLEASE NOTE: The Owner Registration Card must contain the Authorized Buck Stove Dealer Number and the Certified Installer's number (if applicable) for warranty coverage to begin.
