BuckMaster 51 Manual

Zero clearance cabinet non-catalyst room heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL 51 ROOM HEATER AND MODEL 51ZC
ZERO CLEARANCE CABINET
NON-CATALYST
SAFETY NOTICE
FEATURES
PREPARATIONS
INSTALLATION
OPERATION
MAINTENANCE
SAFETY
IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
FOR YOUR SAFETY, FOLLOW THE
INSTALLATION
INSTRUCTIONS.
CONTACT
LOCAL
BUILDING
OR
FIRE
OFFICIALS
CONCERNING
RESTRICTIONS AND INSTALLATION INSPECTIONS IN YOUR AREA.
TESTED AND LISTED BY: ITS/WARNOCK HERSEY, MIDDLETON, WI
MANUFACTURED BY
NEW BUCK CORPORATION - SPRUCE PINE, NC 28777
Revised 6/2001
