- Page 1 960701 BLACKMER GEAR PUMP INSTRUCTIONS NO. 1902-a00 Section 1902 INSTALLATION OPERATION AND MAINTENANCE INSTRUCTIONS Effective October 2022 MODELS: G-SERIES Replaces September 2022 G Series Sealed Internal Gear Pumps Where Innovation Flows 1902-a00...
- Page 2 Always read the most current version of this manual before performing any work on or around this pump. The most current version of this manual is freely available on the web at www.blackmer.com Blackmer pumps are specifically configured for your unique application conditions. Those application conditions and the details of the pump configuration were documented during the ordering process.
-
Page 3: Table Of Contents
Table of Contents SECTION 1 CAUTIONS—READ FIRST! ........................4 SECTION 2 PUMP DESIGNATION SYSTEM ......................5 SECTION 3 HOW IT WORKS—INTERNAL GEAR TECHNOLOGY ............9 SECTION 4 SUGGESTED INSTALLATION & OPERATION ................ 10 SECTION 5 MAINTENANCE ............................15 SECTION 6 DISASSEMBLY ............................. -
Page 4: Cautions-Read First
S E C T I O N 1 Cautions—Read First! CAUTION: Only personnel who are familiar with the CAUTION: Do not run the pump dry. This can cause operation and repair of mechanical products should perform damage to internal components and generate heat, creating the necessary maintenance. - Page 5 S E C T I O N 2 Designation System EXAMPLE: G1-133SNB/4ALT/C9TCN/N/NNNN/000 SEAL TYPE / SEAL RELIEF JACKET SPECIALTY JACKET MODEL EXTERNALS INTERNALS CLEARANCE PORTS ORIENTATION BUSHINGS MATERIAL FACES VALVE OPTIONS CODE 1.5A CANR N = NO XXXX RELIEF VALVE 1.5N CASC CACR...
- Page 6 RELIEF VALVE (G1-2/4): RELIEF VALVE (G1-24/32): STAINLESS STEEL RELIEF VALVE (G1-55/69/82): JACKETED OPTIONS CAST IRON /CARBON STEEL STAINLESS STEEL N = NO RELIEF VALVE NNNN = NO JACKETING N = NO RELIEF VALVE N = NO RELIEF VALVE 05 = 1.0 to 3.5 bar (15 to 50 psi) B = Bracket 07 = 2.1 to 5.2 bar (30 to 75 psi) 06 = 1.4 to 4.1 bar (20 to 60 psi)
- Page 7 EXAMPLE: CXXXX_BSDCSXXX_GYYYYRZZ_MXXXZHPYYYY_ZZZV XXHz_AAA/B/WEG G 1- 55WW A/2NRT /CP G NA/20/NNNN/000_ CERT BASEPLATE GEAR CERTIFIED BASEPLATE GEARBOX MOTOR MOTOR MOTOR MOTOR MOTOR MATERIAL PERFORMANCE BASEPLATE REDUCER MOTOR MOTOR INVERTER HYDRO LENGTH FRAME FRAME SPEED FREQ. ENCLOSURE CERT CERT TESTS SELECTED VOLTAGE DUTY TEST SIZE...
- Page 8 PUMP NOMINAL RATINGS Nominal Pump Max. Discharge Max. Nominal Pump Max. Discharge Max. Nominal Max. Discharge Max. Rating Pressure Temperature Rating Pressure Temperature Pump Rating Pressure Temperature CAST IRON CARBON STEEL STAINLESS STEEL Fahrenheit Fahrenheit Fahrenheit Model PSIG (bar) PSIG (bar) RPM GPM (m3/h) PSIG (bar) (m3/h)
-
Page 9: How It Works-Internal Gear Technology
S E C T I O N 3 How It Works—Internal Gear Technology The G SERIES GEAR PUMP is a rotating, positive displacement pump. These drawings show the flow pattern through the pump upon its initial rotation. It is assumed that the pump has no fluid in it prior to its initial rotation. The shaded area indicates the liquid as it is As the rotor continues to turn, the liquid is drawn into the liquid inlet port of the pump. -
Page 10: Suggested Installation & Operation
S E C T I O N 4 Suggested Installation and Operation G Series gear pumps are designed to meet the performance requirements of even the most demanding pumping applications. They have been designed and manufactured to the highest standards and are available in a number of different sizes to meet your pumping needs. - Page 11 BASE INSTALLATION AND GROUTING NOTE: Before the baseplate is installed, it is advisable to thoroughly clean the underside to enable the grouting to adhere to it. Do not use oil-based cleaners since grout will not bond to it. Once the concrete pad has cured, the baseplate can be carefully lowered over the anchor bolts. Place shims or tapered wedges under the baseplate at each of the anchor bolt positions to provide about 0.75"...
- Page 12 ALIGNMENT OF PUMP/DRIVER SHAFTS WARNING! NOTE: Driver power must be locked out before beginning any alignment procedure. Failure to lock out driver power may result in serious physical injury. NOTE: Proper alignment is the responsibility of the installer and user of the equipment. NOTE: Check alignment if process temperature changes, piping changes and/or pump service is performed.
- Page 13 Since the G-Series pump is foot-mounted, its shaft centerline will rise when handling pumpage at elevated temperatures. Similarly, the motor shaft centerline will rise as it reaches its operating temperature. Therefore, we will often purposely misalign shafts vertically during cold alignment to allow for thermal growth, thus bringing the shafts into alignment at operating temperature. This is shown in the “COLD SETTING OF PARALLEL VERTICAL ALIGNMENT”...
- Page 14 PORT ORIENTATION AND SHAFT ROTATION COLD SETTING OF PARALLEL VERTICAL ALIGNMENT PUMPAGE TEMPERATURE SET DRIVER SHAFT, INCHES 10°C (50°F) 0.002" LOW 66°C (150°F) 0.001" HIGH 121°C (250°F) 0.005" HIGH 177°C (350°F) 0.009" HIGH 232°C (450°F) 0.013" HIGH 288°C (550°F) 0.017" HIGH 343°C (650°F) 0.021"...
-
Page 15: Maintenance
S E C T I O N 5 Maintenance GENERAL MAINTENANCE WARNING: For G Series pumps equipped with jacketed casing, ensure pump is fully cooled prior to conducting inspection, repair, or maintenance. CLEANING: G Series pumps must be maintained and kept as clean as possible. This will allow for quick inspection, adjustment and repair work. - Page 16 INSTALLATION NOTE: Never touch mechanical seal faces with anything except clean hands or a clean cloth. Small particles can scratch and damage the seal faces, resulting in seal leakage. Clean the rotor shaft and the seal housing bore. Make sure they are free of dirt, burrs and scratches. Using emery paper, gently smooth the leading edge of the shaft’s diameter.
-
Page 17: Disassembly
S E C T I O N 6 Disassembly BEARING HOUSING REMOVAL Insert a length of brass through the port opening and in-between the rotor teeth in order to lock the pump and secure the shaft from turning. Bend the lock washer tang upwards. Using a spanner wrench, remove lock nut and lock washer from shaft. - Page 18 PRESSURE RELIEF VALVE DISASSEMBLY Place a mark on the valve and head prior to disassembly in order to ensure proper reassembly. Remove the pressure relief valve cap. Measure and record the extension length of the adjusting screw. Loosen the pressure relief valve lock nut and then back out pressure relief valve bonnet and adjusting screw until the spring pressure is released.
-
Page 19: Reassembly
S E C T I O N 7 Reassembly BEARING HOUSING ASSEMBLY Clean all parts thoroughly. Install the bearing housing lip seal. Refer to Figure G and Figure H for proper orientation. Insert the bearings into the housing. It is best practice to pack the bearings with NLGI #2 multi-purpose grease (or equivalent) before installation. - Page 20 Install the idler bushing. Carbon graphite bushings require additional precautions during installation to prevent cracking**: Use a press for installation. Lightly lubricate the bushing and the bore. Ensure bushing is aligned straight before starting. Do not stop the pressing operation until bushing is in the proper position; starting and stopping will result in a cracked bushing.
- Page 21 Stake one (1) tang of lock washer into the slot of lock nut after torquing. Failure to properly torque the lock nut or engage the lock washer tang could result in premature bearing failure and damage to the pump. Finally, remove the length of the brass from the gear teeth.
- Page 22 CAST IRON/CARBON STEEL EXTERNALS (G1-W, G1-C) Additional Length on Radial Distance on OD OD Brg. of Bearing Housing Housing for .001" End Pump Model Clearance Viscosity (cSt) TEMP C (F) mm (inches) Cl. (inches) Thru 107 (Thru 225) 19.1 (0.75) Up to 540 108-232 (226-450) 41.4 (1.63)
- Page 23 STAINLESS STEEL EXTERNALS (G1-S) Radial Distance on OD Additional Length on OD Brg. of Bearing Housing Housing for .001" End Cl. Pump Model Clearance Viscosity (cSt) TEMP C (F) mm (inches) (inches) Thru 107 (Thru 225) 28.4 (1.12) Up to 540 G1-2/4 108-149 (226-300) 56.4 (2.22)
-
Page 24: Troubleshooting
S E C T I O N 8 Troubleshooting PUMP RUNS, BUT LITTLE PRODUCT FLOWS • Pump speed is too slow. • Suction piping strainer is too small or obstructed. • Suction pipe or port is not immersed deep enough within the liquid. •... - Page 25 Notes 1902-a00...
- Page 26 Notes 1902-a00...
-
Page 27: Warranty
S E C T I O N 9 Warranty ® Each and every product manufactured by Blackmer is built to meet the highest standards of quality. Every pump is functionally tested to insure integrity of operation. Blackmer warrants that internal gear pumps, accessories and parts manufactured or supplied by it to be free from defects in material and workmanship for a period of five (5) years from date of installation or six (6) years from date of manufacture, whichever comes first. - Page 28 PSG Grand Rapids 1809 Century Avenue SW Grand Rapids, MI 49503 USA P: +1 (616) 241-1611 • F: +1 (616) 241-3752 info@blackmer.com blackmer.com Where Innovation Flows ® reserves right to modify information and illustrations contained this document without prior notice. This is non-contractual document.
