RTKA210130DE0010BU
The
RAA210130
is a 30A synchronous step-down
DC/DC converter power module with integrated digital
PWM controller, smart power stage (SPS), output
inductor and passive components. The
RTKA210130DE0010BU is a socket board used for
programming the RAA210130 (shown in
The RTKA210130DE0010BU socket board is a 4.4in
x 5.0in 6-layer FR4 board with 2oz. copper on all
layers. Use this board together with the
ISLUSBEVAL1Z dongle and USB cable for
connection between the dongle and the computer.
The Renesas PowerNavigator™ can be used
together with this board to configure and program the
RAA210130 device.
This manual highlights the procedure to program the
RAA210130 module using the
RTKA210130DE0010BU socket board. For details
about the RAA210130 power module, see the
RAA210130 Datasheet.
R16UZ0043EU0100 Rev.1.00
May 28, 2022
Features
▪ Socket board for programming the RAA210130
Specifications
The socket board is to be used under the following
Figure
11).
conditions:
▪ V
▪ V
▪ I
OUT-MAX
Evaluation Board Manual
= 4.75V to 15V
IN
= 0.6 - 3.0V
OUT
= 0A
© 2022 Renesas Electronics
Page 1
Advertisement
Related Manuals for Renesas RAA210130
Summary of Contents for Renesas RAA210130
- Page 1 Features RAA210130 is a 30A synchronous step-down DC/DC converter power module with integrated digital ▪ Socket board for programming the RAA210130 PWM controller, smart power stage (SPS), output inductor and passive components. The Specifications RTKA210130DE0010BU is a socket board used for...
-
Page 2: Table Of Contents
RTKA210130DE0010BU Evaluation Board Manual Contents Functional Description ..............3 Setup and Configuration . -
Page 3: Functional Description
(VOUT) and TP4 (PGND) for accurately measuring the output voltage. 4. Ensure the power supply at VIN is off. Open the latch on the socket and place the RAA210130 module in the socket. Location of Pin 1 of module is indicated in Figure 1. - Page 4 7. Observe module part number and I C address(0x60) under the scanned devices as shown in Figure Figure 2. First screen of Power Navigator. Observe RAA210130 Module Part Number and Address 8. Click on Open Existing Project as shown in Figure 2.
- Page 5 RTKA210130DE0010BU Evaluation Board Manual 9. The Power Navigator main page opens up. Double click Rail 0 on the Power Map section as indicated in Figure 4. A configurations window opens up as shown in Figure Figure 4. Power Navigator Main Page Double-Click on Rail 0 Indicated by the Red Box Figure 5.
- Page 6 RTKA210130DE0010BU Evaluation Board Manual 10. In the configurations window, under Memory Config, select Save to NVM. Check that the CRC number shown in Project information section is what is to be written. Under Save Project section, click on Refresh. Under the Configurations section the word Save on the right of every Configuration ID turns blue as shown in Figure The first line under Configurations section shows the number of NVM saves remaining.
- Page 7 RTKA210130DE0010BU Evaluation Board Manual 12. After the project is saved, the word Save on the right of every configuration ID turns blue, as shown in Figure Select a configuration to save to and hit Save. 13. A window pops up (see Figure 8) for the user to confirm the use of 1 of the 28 available OTP banks to write to the NVM.
-
Page 8: Board Design
RTKA210130DE0010BU Evaluation Board Manual 15. Open Power Navigator. Go to Memory Config -> Save to NVM. Check that the CRC number is written correctly to the selected configuration ID as shown in Figure Figure 10. Verifying CRC Number Written to Selected Configuration ID Board Design Enable Switch... - Page 9 RTKA210130DE0010BU Evaluation Board Manual VIN_CONNECTOR Figure 12. Bottom of Board R16UZ0043EU0100 Rev.1.00 Page 9 May 28, 2022...
-
Page 10: Schematic Diagram
RTKA210130DE0010BU Evaluation Board Manual Schematic Diagram The RTKA210130DE0010BU socket board is a 4.5inx5.0in six-layer FR-4 board with 2oz. copper on all the layers. The board schematic is shown in Figure Figure 13. RTKA210130DE0010BU Schematic R16UZ0043EU0100 Rev.1.00 Page 10 May 28, 2022... -
Page 11: Bill Of Materials
RTKA210130DE0010BU Evaluation Board Manual Bill of Materials The following table shows the bill of materials for RTKA210130DE0010BU socket board Manufacturer Part Reference Designator Description Manufacturer Number CONN-DEVICE SOCKET, 13x10mm, 130P, Plastronics 130BHQ10Y01G H-PINS, 1.0mmPITCH, ROHS Socket CO. CAP-TANT.POSCAP, SMD, Panasonic 16TDC150MYF 7.3x4.3mm.150µF, 16V, 20%, ROHS CAP, SMD, 1206, 22µF, 25V, 20%, X6S,... -
Page 12: Board Layout
RTKA210130DE0010BU Evaluation Board Manual Manufacturer Part Reference Designator Description Manufacturer Number CONN-HEADER, 1x3, BREAKAWY 1x36, VIN_CONNECTOR BERG/FCI 68000-236HLF 2.54mm, ROHS CONN-HEADER, 1x3, BREAKAWY 1x36, VIN_CONNECTOR BERG/FCI 68000-236HLF 2.54mm, ROHS VIN_CONNECTOR Pins CONN-JUMPER, SHUNT, 2P, SULLINS SPC02SYAN 2.54mmPITCH, BLK, 6mm, OPEN, ROHS SWITCH-TOGGLE, THRU-HOLE, 5PIN, C&K GT13MCBE... - Page 13 RTKA210130DE0010BU Evaluation Board Manual Figure 15. Top Layer Component Side Figure 16. Inner Layer 2 R16UZ0043EU0100 Rev.1.00 Page 13 May 28, 2022...
- Page 14 RTKA210130DE0010BU Evaluation Board Manual Figure 17. Inner Layer 3 Figure 18. Inner Layer 4 R16UZ0043EU0100 Rev.1.00 Page 14 May 28, 2022...
- Page 15 RTKA210130DE0010BU Evaluation Board Manual Figure 19. Inner Layer 5 Figure 20. Bottom Layer R16UZ0043EU0100 Rev.1.00 Page 15 May 28, 2022...
-
Page 16: Ordering Information
RTKA210130DE0010BU Evaluation Board Manual Figure 21. Silkscreen Bottom Ordering Information Part Number Description RTKA210130DE0010BU RAA210130 Single Socket Board Revision History Revision Date Description 1.00 May 28, 2022 Initial release R16UZ0043EU0100 Rev.1.00 Page 16 May 28, 2022... - Page 17 Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
- Page 18 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Renesas Electronics RTKA210130DE0010BU...
