S
M
ERVICE
ANUAL
for
Benchmark Series
Built-in Wall Ovens
HBLP451LUC / HBLP451RUC
HBLP451UC
HBLP651LUC / HBLP651RUC
HBLP651UC
HBLP751UC
HBLP751UCC
HSLP751UCC
This manual contains information that is necessary for
servicing the following Bosch electric built-in wall ovens:
HBLP451LUC, HBLP51RUC, HBLP451UC,
HBLP651LUC, HBLP651RUC, HBLP651UC,
HBLP751UC, HBLP751UCC, HSLP751UCC
This manual is designed to be used by qualified service
personnel only. Due to the complexity and the risk of
high-voltage electrical shock, Bosch does not recommend
that customers service their own units.
This material is intended for the sole use of BSH
authorized persons and may contain confidential and
proprietary information. Any unauthorized review, use,
copying, disclosure, or distribution in any format is
prohibited.
